Conmec CRP30-1 User manual

Operator's Manual
Reversible Plate Compactor
CRP30 Series

2
Manufacturer Conmec Engineering Co., Ltd
No.88, 2# Industrial Avenue, An Wu Road,
Wu Qiao County, Feng Xian, Shanghai, P.R.C
Tel: [phone] Fax: [phone]
www.conmec.cn
Original instructions This Operator’s Manual presents the original instructions. The original
language of the Operator’s Manual is English.

3
Foreword
This manual contains important instructions for this machine. These instructions must be followed
during installation, operation, and maintenance of the machines.
This manual provides information and procedures to safely operate. For your own safety and to
reduce the risk of injury, carefully read, understand, and observe all instructions described in this
manual.
We reserves the right to change any of the contents in this manual without notice.
Warranty
Our products are covered by warranty for a period of twelve (12) months from the date of purchase
against defects in material or workmanship provided that:
The product concerned has been operated and maintained in accordance with the operating
instructions.
Has not been damaged by accident, misuse or abuse.
Has not been tampered with or repaired by any unauthorized person.
Any evidence of failure to meet these conditions may result in a denial of the warranty claim.
The owner is responsible for the cost of transportation to and from the authorized repairer and the
unit is at the owners risk while in transit to and from the repairer.
Impact damage is not covered under warranty. Clutches are not covered under any warranty.
Engines are officially guaranteed by engine manufacturer. Please refer to the annex for engine
warranty.

4
Table of Contents
Foreword 3
Warranty 3
1. SAFETY INFORMATION 5
1.1 Operating Safety………………………………………………………………………….....5
1.2 Operator Safety while using Internal Combustion Engines……………………………..6
1.3 Service Safety ……………………………………………………………………………….6
1.4 Label Locations………………………………………………………………………………7
1.5 Labels Meaning …………….……………………………….…………………………….8-9
2. OPERATION 10
2.1 Start Preparation ……………………………………………………..………….…..………..10
2.2 To Start ..………………………..…………………………………………………………….10-11
2.3 Application ………………………………..………………………….……………….…….…….11
2.4 Operation ……………………………………………………..……………………….…………..11
2.5 To Stop ……………….……………..…………………….……………………………….……..11
3. MAITENANCE 12
3.1 Periodic Maintenance Schedule………………………………………..………………..…12
3.2 Exciter Oil …………………………………………………………………………..…..…….12
3.3 Lifting and Transporting Trowels………………………………………………….…......……....13
3.4 Trouble Shooting …………………………………………………..……………….…………….13
3.5 Engine will not start ……………………………………………………………………………… 13
4. TECHNICAL DATA 14
4.1 Technical Specification…………………………………………………………………………….14
4.2 Dimension …………………………………………………………………………….……………14
4.3 Sound and Vibration Specification ……………………………………………………………….14
EC Declaration of Conformity 15

5
1. SAFETY INFORMATION
1.1 Operating Safety
Only trained personnel are permitted to start, operate, and shut down the machine.
They have received instruction on how to properly use the machine and are familiar
with required safety devices.
Read, understand, and follow procedures in the Operator’s Manual before attempting
to operate the machine.
The machine must not be accessed or operated by children and people impaired by
alcohol or drugs.
NEVER operate this machine in application for which it is not intended.
NEVER operate the machine with the belt guard missing. Exposed drive belt and
pulleys create potentially dangerous hazards that can cause serious injuries.
NEVER allow anyone to operate this equipment without proper training. People
operating this equipment must be familiar with the risks and hazards associated with it.
Do not operate the machine with unapproved accessories or attachments.
Do not allow anyone to stank or lean on the unit during operation.
Do not run the machine indoors or in an enclosed area such as a deep trench unless
adequate ventilation, through such items as exhaust fans or hoses, is provided. Engine
exhaust contains carbon monoxide. This is a poison you cannot see or smell. Exposure
to carbon monoxide can cause loss of consciousness and CAN KILL YOU IN
MINUTES.
Do not touch the engine or muffler while the engine is on or immediately after it has
been turned off. These areas get hot and may cause burns.
ALWAYS wear protective clothing, safety glassed, hearing protection, safety-toed
footwear to the job site while operating the machine.
ALWAYS close fuel valve on engines equipped with one when machine is not being
operated.
ALWAYS store the machine properly when it is not being used. The machine should be
stored in a clean, dry location out of the reach of children.

6
1.2 Operator Safety while using Internal Combustion Engines
Do not smoke when refueling the engine or during any other fuel handling operation.
Do not run the engine near sparks or open flames.
Do not start the engine if fuel has spilled or a fuel odor is present. Move the machine
away from the spill and wipe the machine dry before starting.
Do not refuel a hot or running engine.
Do not refuel the engine near sparks or open flames.
Do not spill fuel when refueling the engine.
Do not touch the engine or muffler while the engine is on or immediately after it has
been turned off. These areas get hot and may cause burns.
If fuel is spilled during refueling, wipe it off from the engine immediately and discard the
rag in a safe place. Do not operate the unit if fuel or oil leaks exist-repair immediately.
NEVER operate this equipment in an explosive atmosphere.
NEVER operate any gas powered equipment in a poorly ventilated or enclosed area.
NEVER perform any work on the unit while it is running. Before working on it, stop the
engine and disconnect the spark plug wire to prevent accidental starting.
Avoid prolonged breathing of exhaust gases. You may be hurt by harmful exhausted
gases.
Avoid contact with hot exhaust systems and engine parts.
Allow engine to cool before performing any repairs or service.
ALWAYS transport and handle fuel only when contained in approved safety containers.
ALWAYS keep the area around the muffler free of debris such as leaves, paper, cartons,
etc. A hot muffler could ignite the debris and start a fire.
1.3 Service Safety
Read and understand the instructions contained in the manual delivered with the
machine before servicing or maintaining
Familiarize yourself with the location and proper use of all controls and safety devices
before servicing or maintaining.
Contact local dealer for additional training if necessary.
Do not allow improperly trained people to service or maintain the machine. Personnel
servicing or maintaining the machine must be familiar with the associated potential
risks and hazards.
Do not attempt to clean or service the machine while it is running. Rotating parts can
cause severe injury.
Do not remove blades while the machine is hanging overhead.
Disconnect the spark plug on machines equipped with gasoline engines, before
servicing, to avoid accidental start-up.
When replacement parts are required for this machine, use only our replacement parts
or those parts equivalent to the original in all types of specifications, such as physical
dimensions, type, strength, and material.

7
1.4 Label Location

8
1.5 Label Meanings
Our machines use international pictorial labels where needed. These labels are described
below:
Label
Meaning
DANGER!
Engines emit carbon monoxide; operate only in
well-ventilated area. Read the Operator’s Manual
for machine information. No sparks, flames, or
burning objects near the machine. Shut off the
engine before refueling. Use only clean, filtered
unleaded gasoline.
Guaranteed sound power level.
`
CAUTION!
Read and understand the supplied Operator’s
Manual before operating the machine. Failure to
do so increase the risk of injury to yourself or
others.
WARNING!
Always wear hearing and eye protection when
operating this machine.

9
Label
Meaning
WARNING!
Hand injury if caught in moving belt.
Always replace belt guard.
CAUTION!
Lifting point.
Start-Stop.
CAUTION!
Use only clean, filtered fuel.
WARNING!
Hot surface!
A nameplate listing the model number
and serial number is attached to each
unit. Please record the information
found on this plate so it will be
available if the nameplate lost or
damaged. When requesting service
information, the serial number should
be specified of the unit.

10
2. OPERATION
2.1 Start Preparation
Before starting the engine, check the following:
Fuel level – the tank should be at least half full.
Motor oil level.
Air filter.
Fuel lines for leaks.
External screw connections for tightness.
2.2 To Start
2.2.1 Starting the petrol engine
Open the fuel tap (a1).
Cold start: Close the choke (d2).
Warm start: Open the choke (d1).
Note: The engine is hand warm or hotter with warm start.
Set the engine switch to "ON" (b2).
Push the throttle lever to the left (c2).
Pull out the starter rope (e) until compression resistance can be felt and then let it roll back in
again.
Pull the starter rope with force, but not suddenly.
The engine starts.
Let starter rope slowly roll back in.
Open the choke while the engine is warming up.
Open the throttle lever completely for operation (c1).

11
2.2.2 Starting for Diesel Engine
Open the fuel cock.
Move throttle lever to start position.
Slowly pull out starter rope until the engine’s compression resistance can be felt. At this point
let starter rope slowly return into starter housing.
Press the decompression lever to “Non-compression” position. The lever will return back
automatically after the engine started.
Now start the engine. Pull out the rope and turn the engine with ever increasing speed. Use
complete length of starter rope.
2.3 Application
Trench compaction Earthworks
Road maintenance Landscaping
Brick paving Driveway topping
2.4 Operation
Press the control handle in the direction of travel.
Note: The forward and reverse speed can be continuously varied.
2.5 To Stop
1. Push the throttle lever to “O” position.
2. Turn the key switch to “O” (off).
3. Close the fuel valve.

12
3 MAINTENANCE
3.1 Periodic Maintenance Schedule
The chart below lists basic trowel and engine maintenance. Refer to engine manufacturer’s
Operator's Manual for additional information on engine maintenance. A copy of the engine
Operator's Manual was supplied with the machine when it was shipped. To service the engine,
tilt the seat forward.
Daily
Every
20
hours
Every
50
hours
Every
100
hours
Every
200
hours
Every
300
hours
Check fuel level.

Check engine oil level.

Inspect air filter. Replace as needed.

Check for damage and leaks

Clean air filter

Clean air filter

Check drive belt for wear.

Change engine oil.

Check fuel filter.

Clean and check spark plug.

Check valve clearance

Replace oil filter.

Replace spark plug.

Replace fuel filter.

3.2 Exciter Oil
When changing the exciter oil, place the exciter on a flat, horizontal surface, remove the
drain plug located at the bottom-right of the vibrator, and simply tip the compactor to
drain the oil. Note that the oil will drain more easily while it is hot. DO NOT pour in too
much oil.

13
3.3 Lifting and Transporting the machine
3.3.1 Lifting the compactor
Use and lifting hook when lifting machine. Make sure lifting device has enough capacity to hold
machine (see identification plate on machine for weight).
3.3.2 Use the trolley wheel (if equipped) for short distance transportation.
3.4 Trouble Shooting
SYMPTOM
POSSIBLE CAUSES
SOLUTION
The V-belt slipping.
Adjust or change the V-belt.
The clutch is slipping.
It does not advance.
Check or change the clutch.
It vibrates, but does
not move.
The vibrator maybe on a slippery
surface.
Try on the right surface.
Travels reverse very
slowly.
Air in the circuit.
Check and purge the circuit.
3.5 Engine will not start
Cause
Remedy
Fuel tank empty.
Refill with fuel.
Fuel tap closed.
Open.
Air filter dirty.
Clean.
Engine switch set to "OFF".
Set the engine switch to "ON".
Recoil starter defective.
Repair.
Oil level warning system turned off.
Top off with engine oil.
a

14
4. TECHNICAL DATA
4.1 Technical Specification
Model
CRP30-1
CRP30-2
CRP30-3
CRP30-4
Engine type
Chinese Diesel
KM178F
Chinese Petrol
Engine
Robin EX17
Honda GX160
Power kw(hp)
4.4(6.0)
4.8(6.5)
4.2(5.7)
4.0(5.5)
Operating weight kg(lb)
170(374)
150(330)
150(330)
149(328)
Frequency rpm
4000
Centrifugal Force kN
30.5
Travel Speed cm/s(in/s)
25(10)
Compaction Depth cm(in)
50(19)
Efficiency m2/hr(ft2/hr)
570(6100)
Plate Size cm(in)
73*45(28*18)/73*36(28*14)
4.2 Dimension (L x W x H): 86x37x83 cm
4.3 Sound and Vibration Specification
Sound Specification
CRP30-1
CRP30-2/3/4
The sound pressure level at operator’s location (LpA)
105dB(A)
102dB(A)
The guaranteed sound power level (LWA)
108dB(A)
108dB(A)
Vibration Specification (According to ISO 2631 and EN 1033) :
CRP30 Series: 4.5 m/s2

15
EC DECLARATION OF CONFORMITY
CE-KONFORMITÄTSERKLÄUNG
DECLARACIÓN DE CONFORMIDAD DE LA CE
DÉCLARATION DE CONFORMITÉ C.E.
CONMEC ENGINEERING CO., LTD
NO.88, 2# INDUSTRIAL AVENUE, AN WU ROAD, WU QIAO COUNTY,
FENG XIAN, SHANGHAI, P.R.C
hereby certifies that the construction equipment specified hereunder /bescheinigt, da. das Bauger.t/
certifica que la máquina de construcción/atteste que le matériel :
1. Category / Art / Categoría / Catégorie:
Plate Compactor
2. Type / Typ / Tipo / Type:
CRP30-1, CRP30-2, CRP30-3, CRP30-4
has been produced in accordance with the following standards:/in übereinstimmung mit folgenden
Richtlinien hergestellt worden ist:/ha sido fabricado en conformidad con las siguientes normas: / a été
produit conformément aux dispositions des directives européennes ci-après :
2005/88/EC
2006/42/EC
2004/108/EC/EN55012:2007
EN500-1
EN500-4
03.09.13 John Lee
--------------------------------------------------- Manager of Engineering
Date / Datum / Fecha / Date

16
CONMEC ENGINEERING CO., LTD
Add: No.88, 2# Industrial Avenue, An Wu Road,
Wu Qiao County, Feng Xian, Shanghai, P.R.C
Tel: [phone]
Fax: [phone]
E-mail: [e-mail]
www.conmec.cn
Version: 20131118-01
