Weber mt CR 8 Operating instructions

CR 8 1
CR 8
Hatz 1 D 81 Z
Operating and
Maintenance Manual
Weber Maschinentechnik GmbH
Im Boden 5 - 8, 10
57334 Bad Laasphe-Rückershausen / Germany
Telephone [phone] / 398-0
Fax [phone] / 398-101
E-Mail: [email protected]
Web: www.webermt.de
0114/englisch/Übersetzung der Original-Betriebsanleitung

2 CR 8

CR 8 3
Table of contents
Introduction 4
Safety guidelines 5
Graphic presentation 8
Device description 9
Technical data 10
Activities prior to starting work 12
Starting 13
Compacting 14
Taking out of operation 15
Maintenance overview 16
Maintenance work 17
Operating uids and ll levels 20
Troubleshooting 21
Storage 22
Contact addresses 27

4 CR 8
Introduction
This operating and maintenance manual is designed to facilitate familiarization with your soil
compactor, and to enable you to maintain the compactor and use it for its intended purpose.
When complying with the instructions in the operating and maintenance manual you help
avoid hazards, reduce repair and downtime costs, and increase the reliability and service
life of your compactor.
This operating and maintenance manual must always be available at the implementation site
of the soil compactor.
If necessary you can obtain additional information from your authorized WEBER dealer,
or you can obtain information from one of the contact addresses on the last page.
The valid conformity declaration is enclosed with every machine delivery.
You can obtain information on the assembled Hatz diesel engine at www.hatz-diesel.com

CR 8 5
Safety guidelines
General
All safety instructions must be read and complied with, non-compliance results in
– danger to life and limb of the user
– impairments to the machine or other property.
In addition to the operating manual, the accident-prevention regulations in the country
where the appliance is used must be complied with.
Intended use
The soil compactor should only be used in technically faultless condition, as intended,
in a safety-conscious and hazard-conscious manner, in compliance with the instructions in
the operating manual. Malfunctions that impair safety must be eliminated without delay.
The CR 8 soil compactor is designed exclusively for compacting
– sand
– gravel
– crushed rock
– semi-cohesive mixed material
– concrete paving stone.
Any other use of the soil compactor is considered to be improper use for which the owner shall be
exclusively responsible. All liability is rejected if damage occurs due to non-compliance with this
provision. This risk is borne solely by the user.
Operation
Soil compactors should only be operated by suitable personnel of at least 18 years of age.
Personnel must be instructed in how to guide the compactor by the owner or by the owner’s
assigned personnel.
The machine operator must comply with trafc regulations. If instructions that affect safety are given
by third persons, then the operator must be authorized to reject these instructions.
Protective equipment
Easily foreseeable misuse
Any use for which the machine is not intended.
Unauthorized persons are forbidden from being in the area of the soil compactor during the
compacting process.
Protective equipment includes:
Hearing protection
Hard hat
Safety shoes
This machine is capable of exceeding the permissible sound level of 80 dB(A). The owner might also
face additional dangers when using the machine. Precautionary action must, therefore, be taken.
Protective gloves

6 CR 8
Maintenance and repair work
Only use original Weber spare parts to ensure reliable and safe operation for maintenance or
repair work.
Hydraulic hose lines must be checked at regular intervals in accordance with standard engineering
practice, or they must be replaced at appropriate intervals, even if no signs of safety-relevant defects
are present.
Adjusting tasks, maintenance tasks, and inspection tasks must be executed on schedule as specied
in this operating and maintenance manual. These activities should only be executed by instructed
personnel.
For repair, maintenance, or inspection work the engine of the compactor must be safeguarded
against unintentional starting.
All pressurized lines, particularly hydraulic lines and lines of the injection system of the drive motor
must be depressurized before performing maintenance or repair tasks.
For maintenance and repair tasks the compactor must be parked on a level and stable substrate
and must be secured from rolling off or tipping over.
Heavy components and subassemblies must be secured on hoisting machines with adequate bearing
capacity when they are replaced. Ensure that no hazard exists related to the raised components or
subassemblies.
Do not position yourself or work under suspended loads.
Operation under difcult conditions
Never inhale the exhaust gas; it contains carbon monoxide, a colorless and odorless gas that is
extremely hazardous, which if inhaled even briey can cause unconsciousness and death.
Never operate the engine in enclosed areas or in areas that are poorly ventilated (tunnels, caves,
etc.) Exercise particular caution when operating the engine in the vicinity of people and livestock.
Always maintain adequate clearance to the edges of pits and embankments.
Do not drive at ninety degrees to slopes to prevent the compactor from tipping over.
After work has been concluded secure the compactor in accordance with statutory regulations,
particularly in the area of public trafc surfaces.
Operation
Prior to starting work the owner of the compactor must be familiar with the work environment.
The work environment includes obstacles in the work and trafc area, the bearing capacity of the
ground, as well as the necessary safeguarding of the construction site in the area adjacent to
public trafc; and it includes compliance with trafc regulations.
The soil compactor should only be operated when the protective xtures are mounted.
The protective xtures must all be in functional condition.
At least once per shift the compactor must be checked for apparent defects. If there are apparent
defects then operation of the compactor must be stopped immediately and the responsible person
must be informed. Prior to restarting, compactor malfunctions that have occurred must be corrected.
If lubricating oils and fuel come into contact with skin, they can cause skin cancer. Upon contact
with the skin, clean affected skin with suitable cleaning agent without delay.

CR 8 7
Inspection
Compactors must be inspected in accordance with appropriate implementation conditions and
operating conditions, as needed; however an inspection to ensure operationally safe status must be
performed by an expert at least once a year. The results of the inspection must be recorded in writing
and must be stored at least until the next inspection.
Cleaning work
Prior to cleaning the compactor with a high-pressure cleaner, protect all accessible energized
switches, cable connections, etc. against water penetration by masking them off.
Cleaning tasks should only be executed in areas that are suitable and have been approved for
this purpose (oil separator amongst others).
Disposal
All operating uids and auxiliary materials must be disposed of in an environmentally-compatible
manner in accordance with country-specic regulations.
Important information for operating and maintenance personnel is marked by pictograms.
Warning against irritants or materials hazardous to health
Warning against a hazardous place
Warning against a suspended load
Wear ear protection
General regulation
Environmental protection
Hard hat
Safety shoes
Protective gloves

8 CR 8
4
9
5
2
12
68
10
3
74
Graphic presentation
Overall view CR 8
1 Engine (no image) 9 Gas lever
2 Drive lever 10 Attachment plates
3 Manual guidance rod 11 Tie-down straps (or similar items)
4 Lifting ring 12 Hearing protection (sticker)
5 Ignition module
6 Base plate
7 Protective frame
8 Exciter

CR 8 9
Device description
The CR 8 compactor is used for road building and landscaping compaction tasks.
Drive
The compactor is propelled by an air-cooled Hatz diesel engine.
Force is transferred to the exciter mechanically via a V-belt.
Operation
Start the Hatz diesel engine via the electrical start device.
After starting, vibration is switched on via the centrifugal clutch attached to the engine.
Use the gas lever to vary the engine speed between idle and full throttle.
Forward and reverse is variably controlled via the handle attached to the manual guidance rod.

10 CR 8
Technical data
CR 8
Weight
Operating weight CECE in kg w/o AP 608
Dimensions
Overall length (in mm) 1830
Width without attachment plates (in mm) 700
Width with attachment plates (in mm) 850
Height with folded manual guidance rod (in mm) 1160
Base plate length (base in mm) 450
Drive
Engine manufacturer Hatz
Type 1 D 81 Z
Performance at operating speed in accordance
with ISO 3046-1 (kW) 9.7
Combustion process 4-stroke diesel
Operating speed (1/min) 2800
Operating speed (ground-dependent in m/min) 28
Incline capacity (ground-dependent in %) 30
Area capacity (in m²/h) 1176
Vibration
System Two-wave vibrator
Drive concept mechanical
Frequency (in Hz) 70
Centrifugal force (in kN) 75
CR 8
Noise emissions in accordance with 2000/14/EC
Sound pressure level LPA
ascertained in accordance with EN 500, in dB (A) 97
Sound power level LWA
ascertained in accordance with EN ISO 3744 and
EN 500, in dB (A)
109
Vibration values
Root-mean-square acceleration value
for hand-arm vibration
ascertained in accordance with EN 500 in m/s² 3,0
In accordance with directive 2006/42/EC,
complying with the vibration values is the
owner’s responsibility.

CR 8 11
2
1
3 4
56
1 Description 2 TYPE
.................................................... ...................................................
3 Serial number 4 Year of manufacture
.................................................... ...................................................
5 Weight 6 Rated power kW
.................................................... ...................................................

12 CR 8
1
1
1
2
1
1
Transport
Fit the crane hook into the lifting ring (1) and lift the
machine onto the desired means of transport.
Only use lifting machines with a minimum bearing
capacity of 1000 kg.
Adjust the desired work height of the manual guidance
rod with the set screw (1).
Adjusting the manual guidance rod
Checking the engine oil level
Pull the oil dip stick (1) out of the crankcase.
Arrest the manual guidance rod (1) with the spring bolt (2).
Activities prior to starting work
When transporting the soil compactor on a vehicle,
secure it with suitable restraints.
Do not step under suspended loads.
Open the maintenance cover (1) (fold forward).
min max
The correct oil level is between the min. and max. marks.

CR 8 13
1
2
1
1
Check the hydraulic oil level when the machine is at
operating temperature. The correct oil level is reached
when the oil is in the middle of the view glass.
Tighten the screws of the attachment plates with a torque of
425 Nm.
Check the hydraulic uid level
Mounting the attachment plates
Installing the protective mat
Fasten the protective mat with holder, screws, spring-lock
washers and nuts on the base plate front and rear.
Ensure that the protective mat rests under the base plate.
Open the cover (1), remove the gas cap (2), check the ll
level and, if necessary, top off with clean fuel to the lower
edge of the ller neck in accordance with the specication.
Check the fuel level
For work at the fuel system, have a suitable re-
extinguishing agent at the ready.
Fire, naked light, and smoking is forbidden!
Starting
Open the vandalism ap (1).
Bring the gas lever (1) into full-throttle position.

14 CR 8
1
1
3
24
5
After turning on the ignition, you will be shown the time
remaining until the next maintenance inspection in eld
5 for 10 s.
Compacting
Control drive speed and direction of travel with the handle (1).
Insert the ignition key (1) and turn to position 1.
Turn the ignition key (1) to position 2.
The ignition key must bounce back to pos. 1 and remain
in this position during operation. The charge level indi-
cator (4) and the oil pressure indicator (3) must go out
immediately after starting.
The indicator lamp (2) lights up, indicating that the engine is
in operation.
The operating hours counter (5) will keep counting the operat-
ing hours as long as the ignition is switched on.
Release the ignition key as soon as the engine starts.
If the ignition key does not bounce back to pos. 1 – turn
off the machine immediately – danger of starter damage
due to the starter also running during operation.
Start for a maximum of twenty seconds without interrup-
tion. If the engine does not start, repeat starting process
after a minute. If the motor does not start after two start
processes, seek cause in fault table.
Only run machine within reach of the manual guidance
rod.

CR 8 15
1
1
1
Shutting down
Close the vandalism ap (1) and lock with a padlock.
Turn the ignition key (1) from position “1” to position “0”.
Pull out the ignition key.
Push back gas lever (1) (pull towards the operator) and
let engine run idle for a few minutes.
During breaks – even if they are short – the machine
must be shut down.
Parked devices that represent an obstacle must
be safeguarded against through conspicuous
measures.

16 CR 8
Maintenance overview
The regulations of the engine manufacturer must be complied with in addition to the
above maintenance overview!
Work must be carried out using regulation tools and the operating and maintenance
manual must be complied with for all work.
All maintenance work: Select a collection vessel that is large enough to prevent oil from
spilling onto the ground. Dispose of waste oil in an environmentally friendly manner
(regulation on waste oils).
Dispose of oils, greases, cloths soaked in oil, and replaced parts with oil on them in an
environmentally friendly manner.
If lubricating oils and fuel come into contact with skin, they can cause skin cancer.
Upon contact with the skin, clean affected skin with suitable cleaning agent without delay.
If accessible during maintenance, check the condition and stability of all screws.
Maintenance interval Maintenance point Maintenance activity
After the rst
25 operating hours
Engine – Changing the engine oil
– Re-tighten all accessible
threaded connections
Every 8 operating hours /
daily Air lter
–Clean air lter insert,
check for damage,
replace if necessary
Every 150 operating
hours / every 6 months
Engine – Changing the engine oil
–Change the fuel lter
–Change oil lter
Battery –Check acid level,
ll up with distilled water
if necessary
Every 150 operating
hours / every year
Transmission – Change oil
Exciter – Change oil

CR 8 17
1
1
1
2
2
Changing the engine oil
Open the cover cap (1) of the oil lter.
Screw the oil drain pipe (1) onto the engine drain valve (2)
and drain off the oil.
After emptying completely, unscrew the oil drain pipe from the
drain valve and screw the cover cap back onto the drain valve.
Fill with oil in accordance with the specication.
When working in the area of the engine compartment
there is a danger of being burnt!
Maintenance work
Only drain engine oil when at operating temperature.
Danger of scalding due to hot oil.
Remove V-belt guard (1) and maintenance cover (2)
(fold forward).

18 CR 8
1
1
1
1
1
2
2
1
Clean / change air lter cartridge
Checking the battery / acid level
Unscrew the air lter cover (1).
Remove the air lter insert (1) from the air lter enclosure.
Clean air lter insert as specied by the engine manufacturer
if there is damage or if it is extremely dirty.
Battery acid is extremely caustic. Protect hands and eyes
with suitable protective goggles and gloves.
Remove the cover cap (1).
Check acid level. If insufcient, ll to max. mark with distilled
water.
If lubricating oils and fuel come into contact with skin,
they can cause skin cancer. Upon contact with the
skin, clean affected skin with suitable cleaning agent
without delay.
Select a collection vessel that is large enough to pre-
vent oil from spilling on the ground. Dispose of waste
oil in an environmentally friendly manner (regulation
on waste oils).
Wipe up/off oil slick and oil residue and dispose of
fuel-soaked cleaning cloths in an environmentally re-
sponsible manner.
Completely drain the engine oil as previously described.
Remove the cover cap (1).
Replace oil lter (2) with a new element.
After replacing the lter element seal the lter enclosure
with the cover cap (1).
Changing the engine oil lter
When working in the area of the engine compartment
there is a danger of being burnt!
Danger of scalding due to hot oil.
Pay attention to the “TOP” marking on the oil lter!
Pull the fuel line (2) off the fuel lter (1) on both sides.
Replace the lter with a new lter element.
Change the fuel lter
Open the maintenance cover (1) (fold forward).

CR 8 19
1
1
1
1
Changing the fuse
Remove the protective cap (1) of the fuse holder.
Insert a new fuse with rated value of 20 Amp.
Changing the oil in the exciter
Remove the oil drain screw (1) and drain oil.
To ll – tilt the machine slightly and ll with fresh oil through
the drain opening in accordance with the ll level table.
Checking the V-belt
Remove the V-belt guard (1).
Check the V-belt (1) for cracks, damaged anks, and wear.
If there is excessive wear – replace the V-belt as specied
in the repair manual.
Select a collection vessel that is large enough to pre-
vent oil from spilling on the ground. Dispose of waste
oil in an environmentally friendly manner (regulation
on waste oils).
Wipe up/off oil slick and oil residue and dispose of
fuel-soaked cleaning cloths in an environmentally re-
sponsible manner.
The fuses are housed behind the side panel on the
left in the direction of travel.

20 CR 8
Operating uids and ll levels
Assembly Operating material Quantity
Summer Winter CR 8
Quality
Engine
Engine oil SAE 10 W 40 1.9 l
(–10 ~ +50 °C)
API - CD CE-CF-CG
or SHPD
or CCMC - D4 - D5 - PD2
Diesel 10.0 l
Diesel in accordance with
DIN 51601-DK
Fuel tank or BS2869-A1/A2
or STM D975-1D/2D
Fully-synthetic transmission uid
API GL-5/GL-4
Vibrator First lling Fuchs Titan SINTOPOID 1.25 l
LS SAE 75W-90
Transmission
Transmission uid
DEXRON II-D-ATF
First lling As necessary
Fuchs Titan ATF 3000
or equivalent
Lubricating points High-pressure grease
(saponied with lithium) As necessary
in accordance with
DIN 51825-KPF2
Battery Distilled water As necessary
