ConMed PRO2038 User manual

The Hall
®
Power
Pro
®
Attachment
Instruction Manual

Proprietary Information
This manual contains information deemed proprietary to Linvatec Corporation. The
information contained herein, including all of the designs and related materials, is the sole
property of Linvatec and/or its licensors. Linvatec and/or its licensors reserve all patent,
copyright and other proprietary rights to this document, including all design, manufacturing
methodology and reproduction.
This document, and any related materials, is confidential and is protected by copyright laws
and shall not be duplicated, transmitted, transcribed, stored in a retrieval system, or
translated into any human or computer language in any form or by any means, electronic,
mechanical, magnetic, manual or otherwise, or disclosed to third parties, in whole or in part,
without the prior express written consent of Linvatec.
Linvatec reserves the right to revise this publication and to make changes from time to time in
the contents hereof without obligation to notify any person of such revision or changes, unless
otherwise required by law.
Linvatec, Hall and PowerPro are trademarks or registered trademarks of Linvatec
Corporation.
© Linvatec Corporation 2002.All Rights Reserved. Printed in USA
Record the Model and Serial Numbers of all attachments, and date received. Retain for
future reference.
Attachment Model No. Serial No Date
Attachment Model No. Serial No Date
Attachment Model No. Serial No Date
Attachment Model No. Serial No Date
Attachment Model No. Serial No Date
Attachment Model No. Serial No Date
Attachment Model No. Serial No Date
Attachment Model No. Serial No Date
Attachment Model No. Serial No Date

Table of Contents Page
i
1.0 INTRODUCTION
1.1 Intended Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
1.2 General Warnings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
1.3 Symbol Definitions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
2.0
PowerPro
®
ATTACHMENT OPERATION
2.1 Connecting and Removing Attachments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
2.1.1 Reaming Attachments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
2.1.1.1 AO Reamer (PRO2040) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
2.1.1.2 Aesculap Reamer (PRO2060). . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
2.1.1.3 Zimmer/Hudson Reamer (PRO2047) . . . . . . . . . . . . . . . . . . . . . . .4
2.1.2 Drilling Attachments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
2.1.2.1 Zimmer/Hudson Drill (PRO2046) . . . . . . . . . . . . . . . . . . . . . . . . .5
2.1.2.2 AO Drill (PRO2070). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
2.1.2.3 AO Attachment - Small (PRO2038) . . . . . . . . . . . . . . . . . . . . . . . .5
2.1.2.4 Trinkle /AO Attachment (PRO2029) . . . . . . . . . . . . . . . . . . . . . . .6
2.1.3 Jacobs Chucks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
2.1.3.1 5/32” Jacobs Chuck (PRO2030) . . . . . . . . . . . . . . . . . . . . . . . . . . .7
2.1.3.2 1/4” Jacobs Chuck (PRO2041) . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
2.1.3.3 1/4” High Torque Jacobs Chuck (PRO2042) . . . . . . . . . . . . . . . . .8
2.1.4 Keyless Chucks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
2.1.4.1 1/8” Keyless Chuck (PRO2050) . . . . . . . . . . . . . . . . . . . . . . . . . . .8
2.1.4.2 1/4” Keyless Chuck (PRO2250) . . . . . . . . . . . . . . . . . . . . . . . . . . .9
2.1.4.3 3/8” Keyless Chuck (PRO2375) . . . . . . . . . . . . . . . . . . . . . . . . . . .9
2.1.4.4 Radiolucent Drive Adaptor (PRO2514) . . . . . . . . . . . . . . . . . . . . .9

ii
Table of Contents Page
2.0
PowerPro
ATTACHMENT OPERATION (Continued)
2.1.5 Wire and Pin Driving Attachments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.1.5.1 Wire Driver (PRO5028) for Battery Handpieces . . . . . . . . . . . . . 10
2.1.5.2 Pin Driver (PRO5032) for Electric Handpieces . . . . . . . . . . . . . . 10
2.1.6 Sawing Attachments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.1.6.1 Sagittal Saw Attachment (PRO2043) . . . . . . . . . . . . . . . . . . . . . . 11
2.1.6.2 Reciprocating Saw Attachment (PRO2045). . . . . . . . . . . . . . . . . 11
3.0 MAINTENANCE
3.1 Cleaning and Sterilizing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.1.1 Cleaning Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.1.2 Attachment Cleaning Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.1.3 Sterilization Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.1.3.1 Sterilization Warnings, Precautions and Notes. . . . . . . . . . . . . . . 14
4.0 CUSTOMER SERVICE, REPAIRS and WARRANTY
4.1 Customer Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.2 Handpieces, Attachments and Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
4.3 Linvatec and Hall
®
Surgical Instrument Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . 19

1
1.0
INTRODUCTION
t is recommended that personnel study this
manual before attempting to operate, clean
or sterilize Hall
®
PowerPro
®
attachments.
The safe and effective use of this equipment
requires the understanding of and compliance
with all warnings, caution notices and instruc-
tions marked on the product and included in this
manual.
1.1 Intended Use
he PowerPro attachments are inter-
changeable between the battery operated
and electric PowerPro handpieces. These
attachments are used in conjunction with the
PowerPro handpieces to perform bone cutting,
reaming, drilling, driving screws, and sawing.
The fields of application for this handpiece
include: Osteotomies, Trauma, Orthopedic,
Total Joint Arthroplasties, Neurosurgical proce-
dures, and Medial Sternotomy.
1.2 GeneralWarnings
1. This equipment is designed for use by med-
ical professionals completely familiar with
the required techniques and instructions for
use of the equipment. Read and follow all
warning and caution notices and instruc-
tions marked on the product and
included in this manual .
2. Do not disassemble or
lubricate attachments, as
this may void your war-
ranty. There are no user-serviceable parts
inside.
3. Eye protection is recommended
when operating equipment.
4. Use only associated Hall
®
Surgical and
Linvatec accessories (saw blades, bits, etc.)
as defined within the descriptions of each
attachment.
5. Handle all equipment carefully. If an attach-
ment is dropped or damaged in any way,
return it immediately for service.
6. Prior to each use, perform the following:
• Inspect all equipment for proper
operation.
• Ensure all attachments and accessories
are correctly and completely attached
to the handpiece.
7. Always inspect for bent, dull or dam-
aged blades or drill bits before each
use. Do not attempt to straighten or
sharpen. Do not use if damaged. After use,
dispose of properly.
I
T

2
8. Continually check all attachments for over-
heating. If overheating is noticed, discon-
tinue use and return equipment for service.
9. Do not attach, insert or remove accessories
or attachments while the handpiece is oper-
ating. Place the handpiece safety button
to the safe position prior to installation
or removal of items .
10. All reaming attachments have a red colored
ring and are not designed to be used in the
screw or oscillate modes.
11. Do not operate any saw attachment
(Reciprocating Saw - PRO2045, Sagittal
Saw - PRO2043) in the oscillate mode.
They are only to be operated in the drill
mode.
12. After each use, thoroughly clean attach-
ments (See “3.1 Cleaning and Sterilizing”
on page 12 ).
1.3 Symbol Definitions
Attention, consult accom-
panying documents.
Single Use Only.
No user service recom-
mended. Refer servicing to
qualified Linvatec service
personnel.
Indicates product compo-
nent should not be steril-
ized.
Indicates product compo-
nent should not be
immersed in any type of
fluid.
Indicates product should
not be oiled or lubricated.
Eye Protection Required.
Caution: Federal Law
restricts this device to sale
by or on the order of a phy-
sician.
Rx ONLY

3
2.0
PowerPro
ATTACHMENT
OPERATION
PowerPro attachments, which are interchange-
able between the battery operated and electric
PowerPro handpieces, and are color coded by
function for easy identification, consist of the
following:
• AO Drill (PRO2070)
• AO Reamer (PRO2040)
• Reciprocating Saw (PRO2045)
• 1/8” Keyless Chuck (PRO2050)
• 1/4” Keyless Chuck (PRO2250)
• Aesculap Reamer (PRO2060)
• Zimmer/Hudson Reamer (PRO2047)
• Zimmer/Hudson Drill (PRO2046)
• Sagittal Saw (PRO2043)
• 5/32” Jacobs Chuck (PRO2030)
• 1/4” Jacobs Chuck (PRO2041)
• 1/4” High Torque Jacobs Chuck (PRO2042)
• Trinkle/AO (PRO2029)
• AO Attachment - Small (PRO2038)
• Radiolucent Drive Adapter Attachment
(PRO2514)
• 3/8” Keyless ChuckAttachment (PRO2375)
• Wire Driver for Battery Handpieces
(PRO5028)
• Pin Driver for Battery Handpieces
(PRO5032)
2.1 Connecting and Removing
Attachments
All attachments for the PowerPro handpieces
connect/disconnect in the same manner.
1. To connect an attachment:
(a) Place the handpiece in the safe posi-
tion.
(b) Orient the attachment shaft with the
handpiece opening. Insert the shaft and
press them until they snap together.
2. To disconnect an attachment twist the
attachment collet-lock in the direction of
the arrow. Remove the attachment.

4
2.1.1 Reaming Attachments
All reaming attachments are geared down to
provide higher torque levels for acetabulum and
femoral reaming, hip screws, or any procedure
where high torque is necessary. All PowerPro
reaming attachments are easily recognized by
the red-colored proximal ring.
NOTE: Reaming and sawing attachments
should only be used in the “Drill” mode and
are not indicated to be used in the screw or
oscillating drill modes.
All reaming attachments have the following
specifications in the “Drill” mode:
Variable Speed: 0-420 rpm
Torque (forward and reverse): 100 in. lbs.
1. To attach accessories to Reamer attach-
ments:
(a) Place the handpiece in the safe posi-
tion.
(b) Pull the collet sleeve back and insert
the accessory shank into the collet.
Release the collet sleeve.
2.1.1.1 AO Reamer (PRO2040)
Specifications:
Collet: Accepts large hex AO reamers
Cannulation: 5.1 mm
Color Ring: Teal/Red
2.1.1.2 Aesculap Reamer (PRO2060)
Specifications:
Collet: Accepts Aesculap Reamers
Cannulation: 5.1 mm
Color Ring: Brown/Red
2.1.1.3 Zimmer/Hudson Reamer
(PRO2047)
Specifications:
Collet: Accepts Zimmer, Hall Series 3,
Hall Series 4, and Hudson
accessories
Cannulation: 5.1 mm
Color Ring: Blue/Red

5
2.1.2 Drilling Attachments
All drilling attachment modes and specifications
are as follows:
Speed Torque (in. lbs.)
Mode Range (FWD/REV)
Drill 0-1250 rpm 35/35
Screw 0-250 rpm 20/35
Speed Oscillation
Mode Range Degrees
Oscillating Drill 0-500 cpm 270°
1. To attach accessories to Drill and AO
attachments:
(a) Place the handpiece in the safe posi-
tion.
(b) Pull the collet sleeve back and insert
the accessory shank into the collet.
Release the collet sleeve.
2.1.2.1 Zimmer/Hudson Drill
(PRO2046)
Specifications:
Collet: Accepts Zimmer, Hall Series 3,
Hall Series 4, and Hudson
accessories
Cannulation: 5.1 mm
Color Ring: Blue
2.1.2.2 AO Drill (PRO2070)
Specifications:
Collet: Accepts large hex style AO drill
bits for Synthes DHS and DCS
systems
Cannulation: 5.1 mm
Color Ring: Teal
2.1.2.3 AO Attachment - Small
(PRO2038)
Specifications:
Collet: Accepts small ASIF / AO type
accessories
Cannulation: 3.25 mm
Color Ring: Brown

6
2.1.2.4 Trinkle /AO Attachment
(PRO2029)
Specifications:
Collet: Accepts Trinkle and ASIF/AO
accessories
Cannulation: 3.4 mm
Color Ring: Purple
Trinkle Shank Accessories for the Trinkle/AO
Attachment
1. To attach accessories to the Trinkle/AO
attachment:
(a) Place the handpiece in the safe posi-
tion.
(b) Pull the collet sleeve back.
(c) Align the dimple on the Trinkle shank
with the black arrow on the outer collet
sleeve. Totally insert the Trinkle shank.
The spring-loaded inner sleeve will
retract.
(d) Release the collet sleeve and rotate the
accessory until it is completely
engaged. Pull the accessory firmly to
ensure proper engagement.
(e) To remove the accessory, pull back the
outer collet sleeve and remove the
accessory.

7
AO/ASIF Drill Bits for the Trinkle/AO
Attachment
1. Align the flat portion of the drill bit shank
with the black arrow on the outer collet
sleeve.
2. Insert the drill bit shank into the collet as far
as it will go without pulling back the collet
sleeve. Twist the shank to make sure it is
aligned properly, it should not spin in the
collet.
3. Pull back on the collet sleeve while pushing
the shank completely into the collet.
4. Release the collet sleeve. The shank is now
locked into the collet. Pull the drill bit
firmly to verify it is properly seated.
5. To remove the drill bit, pull back on the col-
let sleeve and remove the bit.
2.1.3 Jacobs Chucks
1. To attach accessories to the Jacobs Chuck
attachments:
(a) Place the handpiece in the safe posi-
tion.
(b) Insert the accessory shank into the
chuck. Secure the chuck with the
Jacobs Chuck Key.
2.1.3.1 5/32”Jacobs Chuck
(PRO2030)
Specifications:
Collet: 5/32” Jacobs Chuck
Cannulation: 3.9 mm
Color Ring: Green
Replacement Key: 999-53

8
2.1.3.2 1/4”Jacobs Chuck (PRO2041)
Specifications:
Collet: 1/4” Jacobs Chuck
Cannulation: 5.1 mm
Color Ring: Gold
Replacement Key: 999-53
2.1.3.3 1/4”High Torque Jacobs
Chuck (PRO2042)
Specifications:
Collet: 1/4” Jacobs Chuck
Cannulation: 5.1 mm
Color Ring: Gold/Red
Replacement Key: 999-53
2.1.4 Keyless Chucks
1. To attach accessories to Keyless Chuck
attachments:
(a) Place the handpiece in the safe posi-
tion.
(b) Insert accessory shank into chuck.
(c) While holding the knurled ring below
the chuck, turn the knurled portion of
the chuck and secure the accessory.
NOTE: The Keyless Chuck will loosen if the
handpiece is operated in the reverse or oscil-
lating drill modes.
2.1.4.1 1/8”Keyless Chuck (PRO2050)
Specifications:
Collet: 1/8” Keyless Chuck
Cannulation: 2.0 mm
Color Ring: Green

9
2.1.4.2 1/4”Keyless Chuck (PRO2250)
Specifications:
Collet: 1/4” Keyless Chuck
Cannulation: 4.1 mm
Color Ring: Copper
2.1.4.3 3/8”Keyless Chuck (PRO2375)
Specifications:
Collet: 3/8” Keyless Chuck
Cannulation: 4.1 mm
Color Ring: Copper
2.1.4.4 Radiolucent Drive Adaptor
(PRO2514)
1. To attach a radiolucent drive attachment:
(a) Place the handpiece in the safe posi-
tion.
(b) Slide the radiolucent drive attachment
onto the adaptor until it is completely
seated against the collar of the adaptor.
NOTE: Refer to the manufacturer’s
instructions on the proper use of the radiolu-
cent drive.
CAUTION: Do not drive screws or tap holes
with this adaptor.

10
2.1.5 Wire and Pin Driving
Attachments
NOTES:
1. See the appropriate PowerPro handpiece
instruction manual for information to
insert and drive wires and pins.
2. The Wire and Pin Driving attachments
should only be used in DRILL or Oscil-
lating Drill setting and are not indicated
to be used in the SCREW setting.
Wire and Pin Driving attachments have the fol-
lowing specifications in the DRILL setting:
Variable Speed: 0-1250 rpm
Torque (forward and reverse): 35 in. lbs.
Insertion of pins and wires, and the functionality
of the handpiece with either pins or wires is the
same with either attachment.
2.1.5.1 Wire Driver (PRO5028) for
Battery Handpieces
Specifications:
Collet: Wire Driver
Cannulation: Accepts wires from 0.028 in.
(0.71 mm) to 0.062 in. (1.57 mm)
Equipped with a Gold advancement lever
2.1.5.2 Pin Driver (PRO5032) for
Electric Handpieces
Specifications:
Collet: Pin Driver
Cannulation: Accepts wires from 0.062 in.
(1.57 mm) to 0.157 in. (3.9 mm)
Color Ring: Black
Equipped with a Gold advancement lever
Advancement
Lever Advancement
Lever
Wire Driver (PRO5028)
for Battery Handpieces Pin Driver (PRO5032) for Battery Handpieces

11
2.1.6 Sawing Attachments
NOTES:
1. See the appropriate PowerPro handpiece
instruction manual for information to
insert and drive wires and pins.
2. Do not operate any saw attachment
(Reciprocating Saw - PRO2045, Sagittal
Saw - PRO2043) in the oscillate mode.
They are only to be operated in the drill
mode.
3. Operating speed will vary based on the
power source in use.
2.1.6.1 Sagittal Saw Attachment
(PRO2043)
Specifications:
Operating Speed: 0 - 26,000 cpm
Stroke: 4° arc
NOTE: The sagittal saw attachment accepts
only Hall 5023 Series Sagittal Saw blades.
2.1.6.2 ReciprocatingSawAttachment
(PRO2045)
Specifications:
Operating Speed: 0 - 26,000 cpm
Cutting Stroke: 0.125 inch (3.2mm)
NOTE: The reciprocatingsawattachmentis
designed to accept Hall 5052-058 thru -061, -
073, -179, -258 thru -261, -273, -276 and -279
series blades. Refer to the Hall Catalog for
blade information.

12
3.0
MAINTENANCE
Regular and proper maintenance of your Power-
Pro attachments are the best way to protect your
investment. It is essential that you have your
powered surgical instruments serviced as sched-
uled so as to retain their optimum performance
and reliability, which will reward you with safer,
less problematic product performance over time.
The recommended maintenance interval for ser-
vice of your PowerPro attachments is every 24
months.
Proper care and handling of the instruments on a
day-to-day basis, which includes proper day-to-
day operation, cleaning, and sterilization, are
extremely important to ensure safe and efficient
operation.
Your authorized Hall Surgical service depart-
ment is the most knowledgeable about the Pow-
erPro attachments and will provide competent
and efficient service. Service at Hall Surgical at
the recommended service intervals is mandatory
to keep your product warranties in effect. Any
services and/or repairs done by any unautho-
rized repair facility may result in reduced per-
formance of the attachments or attachment
failure and is not recommended. See “4.3 Lin-
vatec and Hall
®
Surgical Instrument War-
ranty” on page 19 for more information on
product warranties.
3.1 Cleaning and Sterilizing
3.1.1 Cleaning Precautions
1. Follow universal precautions for protective
apparel when handling and cleaning con-
taminated instruments.
2. Do not lubricate any attachments.
3. Never immerse attachments.
4. Never clean attachments with
bleach, chlorine-based detergents, liquid or
chemical disinfectants, or any products con-
taining sodium hydroxide (such as
INSTRU-KLENZ or Buell Cleaner). They
will degrade the anodized aluminum coat-
ing.
5. Never clean equipment in an ultrasonic
cleaner or a combination washer/sanitizer.
6. Saw blades and bits are single-use
only. Do not resterilize. Dispose of
properly after use.

13
3.1.2 Attachment Cleaning
Instructions
Clean attachments as soon as possible after use.
1. Remove the attachment from the handpiece
prior to cleaning.
2. Thoroughly scrub attachments with a clean,
soft brush dampened with a mild,
pH-balanced detergent. Remove all traces
of blood, debris and stains. Do Not
immerse equipment in soap solution or
rinse water.
3. Clean the cannulated section of the attach-
ment by performing the following:
(a) Feed the wire end of a cleaning brush
through the attachment.
(b) Pull the brush completely through the
attachment. Repeat until all debris is
removed.
4. Manipulate all moving parts of attachments
to ensure all debris is removed. If not, clean
again until all debris is removed.
5. Rinse attachments under running water to
remove all traces of soap.
6. Flush all surfaces free of tap water with dis-
tilled water to prevent metal discoloration.
7. Gently shake attachments free of water and
wipe the surfaces with a clean, lint-free
towel.

14
3.1.3 Sterilization Information
team sterilization is safe and effective and
has no contraindications for its use in ster-
ilizing attachments.
3.1.3.1 SterilizationWarnings,
Precautions and Notes
WARNING: The use of disinfecting solu-
tions for an exterior instrument wipe will not
sterilize equipment and is not recommended.
1. Do not sterilize attachments with Ethylene
Oxide (EtO).
2. Never sterilize in a washer/sanitizer,
STERIS System, STERRAD System,
Abtox Plazlyte™ or comparable steriliza-
tion methods.
3. Do not sterilize attachments in cold ster-
ilants like CIDEX.
4. Do Not “Peel Pack” attachments for steril-
ization. Sterilization in a sealed pouch traps
moisture which can cause damage.
5. Attachments with collet mechanisms must
be sterilized with the collet fully open .
6. Do not use attachments while warm. Allow
adequate time for cooling prior to surgery.
Do not immerse in liquid or cover with a
damp cloth to cool. Cool by exposure to
room temperature.
NOTES:
1. The following guidelines do not
guarantee that the device is sterile after
the procedure. Your institution is still
responsible for the normal sterility
assurance validation.
2. Additional drying time may be required
for complete heat and moisture dissipa-
tion. Operation of attachments that are
not completely cool or dry may decrease
performance and/or reliability.
3. Sterilization validation is based onAAMI
guidelines (Association for the Advance-
ment of Medical Instrumentation).
All attachments may be processed in a pre-vac-
uum steam sterilizer (Steam Pre-vacuum) or in a
gravity (downward) displacement sterilizer
(Steam Gravity). Place attachments in an appro-
priate instrument tray or a fully perforated,
wrapped container, when applicable.
PowerPro sterilization cases are sold separately.
Consult the sterilization guidelines on the fol-
lowing page or the information insert supplied
with that particular tray.
S

15
Minimum recommended sterilization exposure times are as follows:
Table 1: Sterilization Parameters
Sterilization Type Temperature Minimum Exposure
Time Dry Cycle
Sterilization Guidelines for Sterilizing PowerPro Attachments Individually or in the
PowerPro PRO5090 System Sterilization Case
Steam Pre-vacuum 270 - 272°F (132 - 133°C) 4 minutes 8 minutes minimum *
Steam Gravity 270 - 272°F (132 - 133°C) 10 minutes 8 minutes minimum *
Steam Gravity 250 - 254°F (121 - 123°C) 40 minutes 8 minutes minimum *
Sterilization Guidelines for Sterilizing PowerPro Attachments in the PowerPro Basic
Sterilization Case (Lid - PRO2091/Tray - PRO2092)
Steam Pre-vacuum 270 - 272°F (132 - 133°C) 4 minutes 8 minutes minimum *
Steam Gravity 270 - 272°F (132 - 133°C) 15 minutes 8 minutes minimum *
Steam Gravity 250 - 254°F (121 - 123°C) 40 minutes 8 minutes minimum *
Sterilization Guidelines for Sterilizing PowerPro Attachments in the PowerPro Complete
Sterilization Case (PRO2090)
Steam Pre-vacuum 270 - 272°F (132 - 133°C) 4 minutes 10 minutes minimum *
Steam Gravity 270 - 272°F (132 - 133°C) 15 minutes 10 minutes minimum *
Steam Gravity 250 - 254°F (121 - 123°C) 40 minutes 10 minutes minimum *
* CAUTION: The recommended dry cycle must be run on all attachments every time they
are sterilized. Failure to use a dry cycle may lead to reduced product performance or prema-
ture product failure. Operation of an attachment that is not completely cool and dry may
decrease performance and/or reliability.

16
4.0 CUSTOMER SERVICE, REPAIRS andWARRANTY
4.1 Customer Service
f you need technical assistance regarding the use or application of this product, or you encounter
a problem that requires servicing or repair, contact Linvatec Customer Service at 800-925-4255
or your Hall Surgical Representative. Outside the U.S. contact your local Linvatec Hall Repre-
sentative.
Report any events involving injuries or malfunctions to the Linvatec RegulatoryAffairs Department.
Returning products for any reason requires a Return Goods (R.G.) number that can be obtained by
contacting Linvatec Customer Service. Please provide the following information:
• Product Number
• Serial Number
• Reason for Return
• Original Invoice Number
• Date of Purchase
Repairs
Products returned for repair must have an authorized Return Goods (R.G.) number prominently dis-
played on the box and included on all paperwork. Refer to this number if making inquiries about the
repair status. Please call Linvatec Customer Service and provide the following information to obtain
an R.G. number prior to returning a product for repair:
• Product Number
• Serial/Lot Number - if applicable
• Original Invoice Number
• Date of Purchase
• Detailed description of the problem
If you require a quote - Notify Customer Service when requesting your R.G. number, or on the
paperwork returned with the product indicate that a quote is required. If a quote is not requested the
repair will be processed and your account billed accordingly - provided the repair is not covered
under warranty.
I
