Connects2 CAM-VW8 User manual

Image Sensor: 1/3” CMOS
Lens Angle: 170 Degrees
TV Lines: 700
TV System: PAL
Horizontal Resolution: 700 TV Lines
Operating Voltage: 12V DC (Negative Ground)
IP Rating: IP69K
Power Consumption: <3W
Built-In Lens: 2.8mm
User Manual
Prior to Installation
Read the manual prior to installation. Technical knowledge is necessary for installation.
Please ensure you use the correct tools to avoid damage to the vehicle or product.
Connects2 can not be held responsible for the installation of this product.
Technical Support
Connects2 want to provide a fast and suitable resolution should you encounter any
technical issues. With this in mind, when contacting Connects2, try to provide as
much Information as possible. This will speed up the process and help us to help you.
Please use our dedicated online technical support centre: support.connects2.com
Volkswagen Brake Light Reverse Camera
Volkswagen Caddy 2008 - 2016
PRODUCT FEATURES:
DISCLAIMER:
CAM-VW8

www.connects2.com
2
Connects2Vision
CONTENTS
• Brake light camera
• 10m Male to Female 4pin extension cable
• Instructions
INSTALLATION
1. Remove the third brake light from the vehicle and unplug the connection
cable
2. Connect the CAM-VW8 4pin connector to the 4pin connector found on
the extension cable, then attach it to the vehicle taking care not to trap any
cables
3. Connect the Black wire to a suitable ground and connect the Red wire to
the reversing light circuit or an interface which provides a reverse signal
4. Connect the camera to the display screen via the Yellow RCA connector
and ensure that the image is displayed correctly
Subscribe to our YouTube Channel for installation
guides and tips... www.youtube.com/connects2
