Connects2 CAM-VW13 User manual

Connects2Vision
User Manual
Boot Handle Reversing Camera
for select Volkswagen Vehicles
V1. 11/20
The information provided in this document is subject to change without notice due to manufacturer
changes and/or improvements to the product/s. This instruction manual is based on documented data
and research. The manufacturer of this product cannot be held responsible for any changes made to
the vehicle by the manufacturer or damages that may occur through the installation of this product in
accordance with the steps outlined herein.
DISCLAIMER
VW Beetle 2012 - 2018 VW Caddy 2016 - 2018
VW CC 2012 - 2017 VW Golf 2011 - 2018
VW Jetta 2005 - 2010 VW Passat 2011 - 2019
VW Polo 2011 - 2019 VW Tiguan 2007 - 2018
VW Touran 2016 - 2018 VW Touareg 2015 - 2018
CAM-VW13
APPLICATION

www.connects2.com
2
Connects2Vision
Connects2 want to provide a fast and suitable resolution should you encounter
any technical issues.
With this in mind, when contacting Connects2, try to provide as much
information as possible. This will speed up the process and help us to help you.
Please use our dedicated online technical support centre:
support.connects2.com
• 1/3” CMOS sensor
• 720 x 480 resolution (NTSC)
• Wide Angle Lens
• 12V DC operating voltage
• IP67 rated waterproof
• Viewing angle: 90 ° vertical / 170 ° horizontal
• Parking Guidelines (removable)
PRIOR TO INSTALLATION
Read the manual prior to installation. Technical knowledge is necessary for
installation. Please ensure you use the correct tools to avoid damage to the
vehicle or product.
Connects2 can not be held responsible for the installation of this product.
SPECIFICATIONS
PRODUCT INFORMATION
CAM-VW13
This compact Reverse Camera ensures a high level of safety within a small
package. The CAM-VW13 features automatic switching to the camera feed
upon activation of reverse gear and also boasts removable parking guidelines.
This product is a perfect safety solution for the following vehicles:
VW Beetle (A5) 2012 - 2018
VW Caddy 2016 - 2018
VW CC 2012 - 2017
VW Golf (MK7 - incl. Plus/Variant) 2011 - 2018
VW Jetta (III) 2005 - 2010
VW Passat (B7/B8 Limo) 2011 - 2019
VW Polo (V/VI) 2011 - 2019
VW Tiguan (5N) 2007 - 2018
VW Touran (5T) 2016 - 2018
VW Touareg (7P) 2015 - 2018
TECHNICAL SUPPORT

www.connects2.com 3
Connects2VisionINSTALLATION
1. Before installation, cut the loop on the camera to enable/disable camera
features.
Loop Cut - Lines On
Loop Uncut - Lines Off
6. Focusing now on the Camera Wiring Harness, connect the Black wire to a
suitable ground connection. Connect the Red wire to a switched +12V supply.
Then nally connect the Yellow RCA to the Head Units source of video input.
3. Connect the Power Adapter to the Extension Cable and begin to thread the
length toward the vehicles head unit.
4. Connect the ying wire found on the Extension Cable to a reverse trigger
signal (this can normally be found within the reverse light circuit).
2. Select a suitable location for the camera and ensure that the area is free
from any/all cabling, fuel or oil. Where possible, avoid locations subject to road
dirt and water spray.
5. Connect the Extension Cable to the main Camera Wiring Harness.
7. To test the camera connection, turn on the ignition and put the vehicle into
reverse. The camera feed will populate on screen with parking guidelines (if
loop has been cut).
If camera feed is unresponsive, please uninstall the wiring and reinstall carefully
in accordance with the above steps
For further help and support, please contact us directly at
support.connects2.com/tickets/technical
and ll out a support ticket with the full details of your issue.

www.connects2.com
4
Connects2VisionWIRING DIAGRAM
