Connects2 Vision CAM-JP2 User manual

Connects2Vision
www.c2vision-eu.comwww.c2vision-eu.com
User Manual
Universal Wheel Mount Reverse Camera
with a spare wheel mount bracket. Includes 5 dierent
viewing angles viewable with a Wireless Controller
PRODUCT FEATURES:
CAM-JP2
Image Sensor: 1/4”
TV Lines: 480
Resolution: 720 x 480
Minimum Illumination: 0.1 Lux
TV System: NTSC
Waterproof Rating: IP67
Viewing Angle: 210 Degrees
Parking Lines: Yes (Removable)
Image Adjustment: Yes (up to 5 different viewing modes)
Enhanced Performance In Low Light: Yes
Operating Voltage: 12-24V DC (Negative Ground)
Operating Temperature: -20 Degrees C to +75 Degrees C
Prior to Installation
Read the manual prior to installation. Technical knowledge is necessary for installation.
The place of installation must be free of moisture and away from heat sources. Please
ensure you use the correct tools to avoid damage to the vehicle or product.
Connects2 can not be held responsible for the installation of this product.
Technical Support
Connects2 want to provide a fast and suitable resolution should you encounter any
technical issues. With this in mind, when contacting Connects2, try to provide as
much Information as possible. This will speed up the process and help us to help you.
Please use our dedicated online technical support centre: support.connects2.com
DISCLAIMER:

2
Connects2Vision
www.c2vision-eu.com
CAM-JP2
Extension Cable
Power Adapter
Cable
Make Connections to Vehicle/Unit
Control Unit
Wireless Controller
(Mount on dashboard)
Wiring Diagram
INSTALLATION
Connecting CAN-Bus Wiring
FRONT OF OBD CONNECTOR
FRONT OF OBD CONNECTOR
Locate the vehicle’s OBD port and unscrew/
remove the female connector.
On the reverse of the connector (the side
where wiring enters it), connect the CAN
+ (blue) and CAN - (white) wires from the
harness to the locations specied in the
diagram (Pins 1 and 9).
1 Red Acc 12V Connect to vehicle 12V Accessory feed
2 Black Ground Connect to source of ground
3 Green Reverse Output Connect to aftermarket radio reverse trigger input
4 Purple Reverse Trigger Connect to vehicles reverse light for reverse gear trigger*
5 Blue CAN + Connect to rear of OBD connector (see diagram on Page 3)
White CAN - Connect to rear of OBD connector (see diagram on Page 3)
* this wire is only needed if you are not using the white/blue CAN data wires.
12345678
10111213141516 9

3
Connects2Vision
www.c2vision-eu.comwww.c2vision-eu.com
USING THE WIRELESS CONTROLLER
The wireless controller included in the kit can be used to change the viewing mode of the camera, as
well as adjust key parameters for each viewing mode.
To bring up the HUD menu, put
the vehicle into reverse gear and
press A.
Note: The HUD menu will time-out
after 3 seconds to allow an unin-
hibited view of the camera image.
Press the A button to bring the HUD
menu back onto the screen
The currently selected viewing mode is displayed by the icon in the centre of the HUD menu. This will
default to Driving/Rear-View mode, or to Reversing mode when in reverse gear.
To change the camera mode, whilst the vehicle is in reverse gear, press B or C to cycle through the
Reversing, Wide Angle and Birds-Eye viewing modes.
Start-Up
HUD Menu
Switch to
Wide Angle
Switch to
Birds-eye
Go to Settings
Currently selected view
Viewing Modes
Reversing (Select from HUD Menu) Driving/Rear-View (Default view when not in reverse)
A
BC
Birds-Eye (Select from HUD Menu) Left Blind Spot (Triggered by Indicator - See Below)
Wide Angle (Select from HUD Menu) Right Blind Spot (Triggered by Indicator - See Below)

4
Connects2Vision
www.c2vision-eu.com
Adjusting Settings
To adjust settings for all viewing modes, press A from the HUD menu to enter the settings menu.
Once in the settings menu, short press A to cycle through the various settings screens available. Screens
include camera angle and position for each mode, and guideline width for parking lines.
Once in a settings screen, the selected setting is indicated by the icon in the centre of the display. The
parameters can be adjusted with B and C.
To return to the previous screen, Press and hold A.
Activating/Deactivating Blind Spot View (BSV) Mode
When in any of the settings screens, a long press of B will activate or deactivate BSV (Blind Spot View).
When active, this will trigger the blind spot camera image when an indicator is activated and the vehicle
is moving at a speed of over 40km/h.
When inactive, using the indicators will not trigger the blind spot view and the camera will remain in
Driving/Rear-View mode.
Note: this function will only work if the CAN-Bus wiring is connected.
Move to next setting
(Short Press)
Return to previous
(Long Press)
Adjust parameter
Adjust paramater
(Short Press)
Activate/Deactivate BSV
(Long Press)
Currently selected
setting
A
C
B
