Conotec FOX-2001D User manual

A key to change of the programs & setting temperature

1. As the product is not manufactured as safety equipment, make
sure to use this product after mounting double safety device
when using it for the purpose of controlling a device having risk
of personal injury, equipment damage or huge property loss.
2. Do not cut the wire or make check-up or maintenance when the
power supply is connected.
3. Make sure to check the socket number before connecting the power.
4. Never disassemble process, improve or repair this equipment.

• Please carefully read and digest the operation procedure and safety related
regulations or WARNING descriptions prior to the use of product, and make sure to
operate the product only per the relevant specification or within the corresponding
capacity rating.
• Do not make wiring or install the product on motor or solenoid with large inductive
loads. When extending the sensor, use the shielded wire not extending the extension
wire length unnecessarily long.
• Do not use the components generating arc when opening and closing under same
power supply line or near to power supply.
• Keep the power supply line away from high voltage wire, and avoid installation at the
locations subject to severe moisture, oily content and dust.
• Do not install the product at places exposed to direct sung light or rain.
• Do not install the product at places subject to strong magnetism or severe noise,
vibration and impact.
• Keep the product far away from the places directly producing strong alkali or acidic
substances using separate conduit for wiring.
• Do not spray water on the product for cleaning purpose when installed at kitchen area.
• Do not install at those places under the temperature and/or moisture exceeding the
rated capacity.
• Use the product paying attention not to have disconnected sensor wiring or defect.
• Allow the sensor wiring stay away from signal, power supply, drive and load wires
using separate conduit for wiring.
• Please note that no warranty services shall be provided when the product is
disassembled or modified at user’s own discretion.
• The mark shown on Terminal Wiring Diagram is a safety notice notifying warning
or caution.
• Do not use the product at places near to the devices generating strong high frequency
noise (High frequency welding machine, high frequency sawing machine, high frequency
radio, large capacity SCR controller).
• Using the product with procedures not specified by the manufacture may incur the
personal injury or property damage.
• Not being a toy, do not allow children touch the product.
• Make sure to execute the installation only by the skilled person with related industry
or authorized personnel.
• CONOTEC shall assume absolutely no responsibility of whatsoever nature for those
damages and/or losses incurred due to the operation not complying with above WARNING
or NOTE descriptions or negligence and/or fault of user.
shock.
shock
relay
relay
relay
The function of each key
A key to change of the temperature or the
program’s set values.
In case of using the load exceeding the capacity of
the contact, it caused fused contact, connection error.
Connection
Display
Setting
temp.
Range Remark
Setting temp. 1
Setting temp. 2
Setting temp. 3
Setting temp. 4
Program
setting
Setting for the
highest limit of
use
It is irrelevant to
the relay output
It is irrelevant to
the relay output
Lock function
Correction of
temperature
Setting for the
lowest limit of
use
Temp. 1
function select
Lock
Unlock
however, except for
the set value.
Correct for discrepancy
between the display
and real temp.
Hysteresis +
Delay time
set for temp.1
output
Delay time
set for temp.2
output
Delay time
set for temp.3
output
Delay time
set for temp.4
output
Temp. deviation
for temp. 2
Temp. deviation
for temp. 1
Refer to remark on
the temp. 1 function
select
Display the present temperature
setting temp.
1 change
setting temp.
2 change
setting temp.
3 change
setting temp.
4 change
Setting temperature
is displayed as a
Setting value change sequence
Temp. 2
function select
Temp. 3
function select
Temp. 4
function select
Temp.3 deviation
temp. setting
Temp.4 deviation
temp. setting
Refer to the remark
Temp. 1 deviation
temp. setting
Refer to the remark
Temp. 1 deviation
temp. setting
Refer to the remark
Temp. 1 deviation
temp. setting
Refer to remark on
the temp. 1 function
select
Refer to remark on
the temp. 1 function
select

Common
application
application
application
P
min, sec
min, sec
min. sec
min. sec
min.sec
min.sec
min.sec
min.sec
To change it with program mode press the key for more than 5 second in the present temperature display mode.
The set or program mode is terminated if you press the key for 2 second, parameters(set values) are saved after
the display shows letter or return to present temperature automatically after 30 second.
URL
e-mail
How to diagnose a breakdown
When using this product, please observe the information of warning due to give rise to
disordering.
Cooling Heating
Main output Main output
Indicating ERROR on using items
This
is the damage of memory data for various of inner-DATA
got nosied strongly from outside while using this items.
Although our controller is designed as the complementary
measures regarding these noise from outside, it is not endurable
against these noise with endlessly.
If noise(2KV) disordering become an inflow, the inner-part will be damaged.
Application
Output specifications
Main output
Main output
output
output
output
output
due to be
Please request us A/S by return.
If these letters like (open error) and (short error) indicates,
the sensor’s error is the main cause of the displaying. Please check
the sensor
ex1)
Heater →
turn off at 30.0℃,
turn on at 25.0℃
<setting Temp.> (see the setting
temperature)setting : 30.0℃
<setting program> (see the setting
program)typ :H
DIS : P (deviation→on side,
set point→OFF)
dif : 5.0 (on/off interval→5.0℃)
ex2)
Cooler →
turn off at 0.0℃,
turn on at 2.0℃
<setting Temp.> (see the setting
temperature)setting : 0.0℃
<setting program> (see the setting
program)
typ : C DIS : P(deviation→one side,
set point→OFF)
dif : 2.0(on/off interval→2.0℃)
ex
Set temp.
set value
which point to be output ON?
In increasing current temp, if passes
26.0 at , after 1 min 30sec as
setting time, Relay is to be ON at .
The reason why applied output delay time
not from but is set to be interval
as .
Temp.
Alarm
Defrost
FAN
Sensor ( 1EA ) ( 1EA ) ( 1EA )
Temp. 1 stage 4 stage3 stage2 stage
control by temperature & time
(for greenhouse)
Detailed manual
: setting for the 1-stage temperature(application model : 2001D, 2001T, 2001F)
: setting for the 2-stage temperature(application model : 2001D, 2001T, 2001F)
: setting for the 3-stage temperature(application model : 2001T, 2001F)
: setting for the 4-stage temperature(application model : 2001F)
: Setting function of the highest limit of temperature range
(maximum set point allowed to the end user)
- Impossible to set up the set value more than HSP set value
ex) HSP = 25.0℃ setting ⇒ impossible to raise the set value
more than 25.0℃
: Setting function of the lowest limit of temperature range
(Minimum set point allowed to the end user)
- Impossible to set up the set value less than HSP set value
ex) HSP = 10.0℃ setting ⇒ impossible to lower the set value
less than 10.0℃
ex)
real temp.
display
: Correction of the present temperature.
The product itself has no problem, but the correction function
for that if temp. differs between an error occurs in the input the
sensor
from outside and basic temp. (ex. mercury thermometer or an
existed using thermometer, temperature controller)
If discrepancy between the real
temperautre and the displayed
if corrected to
:
will be displayed
: The lock function
- As a safety device, it is used in order not to change
the set values except for the main user.
ON - All setting values for the lock function except for the set value.
OFF -All setting values for the unlock function except for the set value.
: Selection of the Temp. 1 or or Cooling(C) or Heating(H)
(application model : 2001D, 2001T, 2001F)
Temp. 1 output delay time(application models : 2001D, 2001T, 2001F)
In case of operating ON/OFF control very often,
(Cooler, compressor and so on)
to protect the operation machi nery when re-input of the power
supply or momentary stoppage of power supply.
Selection of the Temperature 2 cooling(C) or heating(H)
See the No. 9(application models : 2001D,2001T, 2001F)
:
Delay time of the temperature 2 ouput
See the No. 10(application models : 2001D, 2001T, 2001F)
:
Setting deviation for temperature 2
See the No. 11(application models : 2001D, 2001T, 2001F)
Selection of the Temperature 3 cooling(C) or heating(H)
See the No. 9(application models : 2001T, 2001F)
Delay time of the temperature 3 ouput
See the No. 10(application models : 2001T, 2001F)
Setting deviation for temperature 3
See the No. 11(application models : 2001T, 2001F)
:
Selection of the Temperature 4 cooling(C) or heating(H)
See the No. 9(application models : 2001F)
:
Delay time of the temperature 4 ouput
See the No. 10(application models : 2001F)
:
Setting deviation for temperature 4
See the No. 11(application models : 2001F)
:
Setting deviation for temperature 1
(application models : 2001D,2001T, 2001F)
- In the ON/OFF control it needs at regular interval
between ON and OFF. By operating the ON/OFF control
frequently, the relay or its output contact can be
damaged quickly and it also occurs the hunting
(oscillation, chattering) by virtue of external noise. You
can make use of the temperature deviation in order to
protect its relay or contact and so on.
present temp. > set value + deviation value
PV
present temp. < set value - deviation value
PV
PV SV PV SV
setting setting
Sensor
wide use
1 EA
( 1EA )
Temp.1 Temp.2
Alarm1 Alarm2
