Consort Heatflow BFH2T Installation and operating instructions

57000584 Iss 06
I NSTALLATION
Ensure the electricity supply is disconnected from any relevant fixed wiring before commencing the
installation. Ensure that the mains supply voltage is as stated on the rating label.
The supply circuit must be adequate for the input of the appliance.
I MPORTANT
When installed in a bathroom the unit must not be connected via a plug and socket.
The heater must also be located in the appropriate zone of the bathroom, in accordance with section 601 of
the Wiring Regulations BS 7671). The appliance should be fitted horizontally such that the cable entry is
uppermost and the pullcord is at the bottom. The unit must be mounted a minimum of 1.8 metres from the
floor, also a minimum of 150 mm below ceiling level or any other projecting surface. It must also not be
less than 250 mm from any adjacent projecting surface. The unit must not be located immediately below a
fixed socket outlet. This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instructions concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance. The heater is to be
installed so that the switches and other controls cannot be touched by a person in the bath or shower. The
heater must not be installed in front of a socket-outlet. Means for disconnection must be incorporated in
the fixed wiring in accordance with the wiring rules. If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
Ensure that when in use the airstream is not obstructed by a cupboard or similar object.
WARNING – THIS APPLIANCE MUST BE EARTHED
WARNING – DO NOT PLACE AEROSOLS OR SIMILAR CONTAINERS OR MATERIALS
SUSCEPTIBLE TO HEAT IN THE DIRECT AIRSTREAM.
C ONNECTION T O T HE M AIN S UPPLY
Electrical installation should be carried out by a competent installer, preferably registered with NICEIC
(National Inspection Council for Electrical Installation Contracting) in accordance with the 16 edition of
the IEE Wiring Regulations, (BS.7671) and any relevant Local Authority Bye-Laws.
The heater is fitted with a 3-core mains supply cable and should be permanently connected to the
electricity supply via a double pole switch having 3 mm gap on each pole.
A switched Fused Connection unit to BS.1363 Part 4 is a recommended mains supply connection
accessory to ensure compliance with safety requirements applicable to fixed-wiring installation.
M OUNTING P ROCEDURE
Using the mounting bracket supplied as a template,
position it horizontally a minimum of 1.92 m from floor to
underside of bracket and mark the position of the three
fixing holes (ref A. in diagram).
Drill and plug the wall suitable for No 8 screws.
Insert the two keyhole screws in wall leaving
approximately 2 mm gap between head and wall.
Secure the mounting bracket to the appliance using the 3
No 6 screws supplied (ref B in diagram).
Position the appliance on the partially inserted wall screws
and secure the third wall screw immediately above
appliance.
C ONTROLS
The BFH2T has a heat loading of 2 kW. The heater is controlled by a pullcord operated on/off switch. A
neon indicator when lit shows that the unit is operational.
The appliance is fitted with an Electronic Safety Control (ES). This is a safety device which switches off
the heater if for any reason the appliance overheats. The ES Control can only be re-set after the appliance
has cooled down. In order to re-set the ES Control proceed as follows:-
•Switch off appliance by means of pullcord and leave for approximately 5 minutes.
•Switch appliance back on and ES Control will re-set.
•Ensure that the appliance is functioning correctly. If the ES Control operates again, the appliance
should be checked by a competent electrician.
T HERMOSTAT C ONTROL
The BFH2T is fitted with a thermostat.
o set the thermostat to the required temperature, turn the control knob fully clockwise. When the
desired room temperature is reached, turn the knob slowly anti-clockwise and when the thermostat ‘clicks’
off, leave the control at this setting. Thereafter, the fan heater will control the heat output automatically.
To set the heater to the Frost Watch mode, rotate the thermostat control knob fully to the lowest setting
(N
o
1). Thereafter the heater will trip in if the temperature drops sufficiently. The heater needs to be in
the ‘ON’ mode with the neon indicator light illuminated for this function to operate.
T HERMOSTAT C ONTROL K NOB
I F Y OUR H EATER D OES N OT W ORK
•Check re-set of E.S. Control as described under ‘controls’.
•Check that the plug is firmly pushed into the wall socket with the socket switched ‘on’.
•Check that the socket is live by using another appliance in it. (If it is not live, check the fuse at the
distribution board).
•Check that the plug is wired correctly.
•Check that the fuse has not blown. (This can be done by replacement with another suitable fuse).
•If you are replacing a fuse in the plug, a 13 Amp fuse approved by A.S.T.A to BS 1362 must be used.
•Should none of the above remedies work, than disconnect heater from the mains and consult an
accredited service agent.
•Do NOT attempt to repair the heater or unscrew the outer casing yourself.

57000584 Iss 06
S AFETY
This equipment has been designed and manufactured to the highest international standard, but, like all
electrical appliances which are operated by mains voltage, care must be taken if you are to obtain the best
results and safety is to be assured.
•Do NOT handle the appliance with wet hands.
•Do NOT use the appliance in workshops or rooms where excessive dust is generated or present.
•Ensure that nothing is pushed into any aperture of this appliance.
•Do NOT touch outlet grille when appliance is in use.
This appliance meets the requirements of EU Directive 89/336/EEC for EMC.
C LEANING
Always disconnect the heater from the mains before cleaning.
The fan heater should not require any maintenance, but it is strongly advised that it be kept clean. An
occasional wipe over with a soft cloth is all that should be necessary.
•Do NOT use metal or furniture polish on any part of the heater
•Do NOT touch the heater with wet hands or in any way bring water in contact with it.
The supply cord on this appliance can only be replaced by the use of special tools, and should any damage
or fault occur to the heater, it must be serviced by an accredited service agent.
IMPORTANT:
ALWAYS RETAIN YOU USER INSTRUCTIONS FOR FUTURE REFERENCE.
G UARANTEE
This guarantee is offered to you as an extra benefit and does not affect your legal rights.
All electrical appliances produced for the Company are guaranteed for one year against faulty material or
workmanship. This applies only if the appliance has been used for purposes in accordance with the
instructions provided and has not been connected to an unsuitable electricity supply, or subject to misuse,
neglect, damage or modified or repaired by any person not authorised by us.
The correct electricity supply voltage is shown on the rating label attached to the appliance.
Please retain your receipt as proof of purchase.
C USTOMER H ELPLINE
Should you need any advice on the use of your new Consort product, or should you require service or
repair, please contact our Helpline:


01646 692172 Mon to Fri 8.30 am to 3.30 pm
Consort Equipment Products Limited
Thornton Industrial Estate, Milford Haven, Pembrokeshire, SA73 2RT
Fax: [phone] Email: [email protected] Web: www.consortepl.com
Quality Space Heaters
Using and Looking after your
HEATFLOW
Wall Fan Heater
BFH2T
