Consort WMH3SL Use and maintenance manual

Installation & Control Guide for
Chelsea Wall Mounted Fan Heater for SL Wireless Control-
All electrical appliances produced for the Company are guaranteed for one year against
faulty material or workmanship. This applies only if the appliance has been used for
purposes in accordance with the instructions provided and has not been connected to an
unsuitable electricity supply, or subject to misuse, neglect, damage or modified or repaired
by any person not authorised by us. This guarantee is offered to you as an extra benefit and
does not affect your legal rights.
The correct electricity supply voltage is shown on the rating label attached to the
appliance.
Reasonable care has been taken to ensure that this guide is accurate at the time of
printing. In the interest of progress the Company reserve the right to vary specifications from
time to time without notice.
QUALITY SPACE HEATERS
Model
WMH3SL
58000388 Iss 02

Overview
Please read this guide carefully and retain
for future use and maintenance.
This appliance has been designed and
manufactured to the highest international
standards, however, care must be taken
for optimal results and safety. This
appliance also meets the requirements of
EU Directive 2004/106/EC for EMC and
2009/125/EC Directive.
Safety & Care
The appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities or
lack of experience and knowledge unless
they have been given supervision or
instruction concerning use of the
appliance by a person responsible for their
safety. Children should be supervised to
ensure that they do not play with the
appliance.
Warning
 Do NOT site the appliance in a corner.
 Do NOT handle the appliance with wet
hands.
 Do NOT use the appliance in workshops
or rooms where excessive dust is
generated or present.
 Ensure that nothing is pushed into any
aperture of this appliance.
 Do NOT touch outlet grille when the
appliance is in use.
 Do NOT cover or restrict any aperture of
the appliance when in use.
 Do NOT use the appliance if damaged.
 Do NOT leave the appliance
unattended where young children are
present.
Thermally Operated Cut-Out
The appliance is fitted with a thermally
operated cut-out (TOC). This is a safety device,
which switches the heater off if, for any reason,
the appliance overheats. The TOC can only be
re-set after the appliance has cooled down. In
order to re-set the TOC, proceed as follows:
 Switch off appliance at mains and
leave for approximately 10 minutes.
 Switch appliance back on and TOC
will re-set.
 Ensure that the appliance is functioning
correctly. If the TOC control operates
again, the appliance should be checked
by a competent electrician.
The heater carries a ‘Do Not Cover’ label to warn
the user that if the appliance is covered, there is a
risk of overheating.
Cleaning
Always disconnect the heater from the mains before
cleaning. The heater should not require any
maintenance, but it is strongly advised that it is kept
clean. An occasional wipe over with a soft cloth is
all that should be necessary.
 Do NOT use metal or furniture polish on any part of
the heater.
 Do NOT touch the heater with wet hands or in any
way bring water into contact with it.
If the supply cord is damaged, it must be replaced
by the manufacturer or its service agent or a similarly
qualified person in order to avoid a hazard.
If Your Heater Does Not Work
 Check that power is available to the heater. The
LED light should be illuminated
 Check that the thermal cut-out has not operated.
Follow the reset instructions given under the
section headed ‘Thermally Operated Cut-out’.
 Check that the fuse in the spur unit has not blown.
This can be done by replacing the fuse with
another suitable fuse.
Should neither of the above remedies work, then
telephone the helpline number shown in these
instructions (UK ONLY). Do not attempt to repair the
heater.
Connection to the Main Supply
Electrical installation should be carried out by a
competent installer, preferably registered with
NICEIC (National Inspection Council for Electrical
Installation Contracting) in accordance with the 17th
edition of the IEE Wiring Regulations, (BS.7671), and
any relevant Local Authority Bye-Laws. The heater
can be connected in a number of ways depending
on the form of control required. Whichever method is
used, it must be permanently connected to the
electricity supply via a double pole switch having
3mm gap on each pole. There are no exceptions. A
switched Fused Connection unit to BS.1363. Part 4 is
a recommended mains supply connection
accessory to ensure compliance with safety
requirements applicable to fixed-wiring installation.
Note: When switched on for the first time the
appliance may emit a slight smell. This is purely the
evaporation of a fluid used in the manufacturing
process.
WARNING: This appliance must be earthed.
2
58000388 Iss 02

3
Wall Mounting
1. Remove the front cover (2 screws on the side and 2 screws on the bottom).
2. Mark top 2 screw fixing positions ‘A’ in accordance with the dimension shown on the diagram. The
unit must be screwed to the wall with 3 screws through the holes provided in the case. Drill 2 holes in
the wall to suit No 10 wood screws (round head) and insert wall plugs. At the top 2 screw positions
‘A’ screws can now be screwed in until the heads are approximately 5mm from the wall. The unit
can now be hung on these two screws and the position of the third bottom fixing marked on the
wall. Remove the unit from the wall and drill a third fixing hole in the position marked and insert a
wall plug. The unit can now be hung on the wall and the third screw screwed in. Before tightening
all three screws ensure the unit is horizontal.
3. Refit front cover. Ensure grille bars internal/external are spaced equally.
OPTIMUM MOUNTING HEIGHT IS 400mm FROM THE FLOOR.
NOTE:
- MINIMUM CLEARANCE FROM THE FLOOR IS 200mm.
- IF THE HEATER IS MOUNTED AT HIGH LEVEL, THE MINIMUM DISTANCE FROM THE CEILING IS 1000mm.
- THE HEATER MUST NOT BE LOCATED IMMEDIATELY BELOW A FIXED SOCKET OUTLET.
58000388 Iss 02

4
CUSTOMER HELPLINE
Should you need any advice on the use of your new Consort product please contact our Helpline:
Consort Equipment Products Limited
Thornton Industrial Estate, Milford Haven, Pembrokeshire, SA73 2RT
Tel: [phone] Fax: [phone] Email: [e-mail] Web:
www.consortepl.com
Operation hours: Mon to Thu 8.30am to 4.30pm | Fri 8.30am to 3.30pm
BS EN ISO 9001 Registered Company No FM12671
58000388 Iss 02
Operation
When the appliance is connected to the mains supply, the LED indicator will light up green, showing that the
power is available to the unit.
When the heat output has been enabled by a controller, the LED indicator light will turn red.
This heater can only be used in conjunction with any SL wireless controller.
Each SL controller can control any number of heaters providing they are in the RF range.
SLPB SLTI
SLVT / SLVTB
Please refer to the SL user and operating instructions for
full operational details.
SL wireless controllers
