MAINTENANCE
ALWAYS ENSURE THAT THE MAIN EXTERNAL ELECTRICAL SUPPLY IS SWITCHED OFF BEFORE ANY
MAINTENANCE IS CARRIED OUT.
To obtain the best esults f om the heate , it is necessa y to avoid any accumulation of dust o di t
within the unit o on the ai inlet g ille. The unit should be cleaned egula ly.
SAFETY
This equipment has been designed and manufactu ed to the highest inte national standa ds but, like
all elect ical appliances which a e ope ated by mains voltage, ca e must be taken if you a e to obtain the
best esults and safety is to be assu ed.
NOTE: The appliance is not intended fo use by pe sons (including child en) with educed physical,
senso y o mental capabilities, o lack of expe ience and knowledge unless they have been given
supe vision o inst uction conce ning use of the appliance by a pe son esponsible fo thei safety.
Child en should be supe vised to ensu e that they do not play with the appliance.
Do NOT use this appliance in bath ooms o whe e simila conditions of excessive moistu e a e
p esent.
No NOT handle the appliance with wet hands.
Do NOT use the appliance in an enclosed oom so small that the heate will gene ate ambient
tempe atu es in excess of 30
0
C.
Do NOT use the appliance with young child en unattended.
Do NOT use the appliance in ooms whe e excessive dust is gene ated o p esent.
Do NOT touch THE outlet g ille when appliance is in use.
Do NOT cove o est ict any ape tu e of the appliance when in use.
Do NOT use the appliance if damaged.
If the appliance has been kept in f eezing conditions, un at cold/fan setting fo 5 minutes befo e
using heat settings.
This appliance meets the equi ements of EU Di ective 98/336/EEC fo EMC.
GUARANTEE
This gua antee is offe ed to you as an ext a benefit and does not affect you legal ights.
All elect ical appliances p oduced fo the Company a e gua anteed fo one yea against faulty
mate ial o wo kmanship. This applies only if the appliance has been used fo pu poses in acco dance
with the inst uctions p ovided and has not been connected to an unsuitable elect icity supply, o subject
to misuse, neglect, damage o modified o epai ed by any pe son not autho ised by us.
The co ect elect icity supply voltage is shown on the ating label attached to the appliance.
Please etain you eceipt as p oof of pu chase.
CUSTOMER HELPLINE
Should you need any advice on the use of you new Conso t p oduct, o should you equi e se vice o
epai , please contact ou Helpline:


 01646 692172 Mon to F i 8.30 am to 3.30 pm
Consort Eq ipment Prod cts Limited
Thornton Ind strial Estate, Milford Haven, Pembrokeshire, SA73 2RT
Fax: [phone] Email: enq [email protected] Web: www.consortepl.com
Q ality Space Heaters
INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS FOR
CHELSEA WALL MOUNTED FAN HEATER
FOR WIRELESS ELECTRONIC CONTROLS
Catalogue Numbe s: WMHW3 (b ushed aluminium fascia)
PLEASE RETAIN THIS LEAFLET FOR FUTURE MAINTENANCE

58000312 Iss 2
INSTALLATION
Ensu e the elect icity supply is disconnected f om any elevant fixed wi ing befo e
commencing the installation. The supply ci cuit must be adequate fo the input of the
appliance and must be p otected by a 13 Amp fuse.
The heate must not be located immediately below a fixed socket outlet.
CONNECTION TO THE MAIN SUPPLY
Elect ical installation should be ca ied out by a competent installe , p efe ably
egiste ed with NICEIC (National Inspection Council fo Elect ical Installation Cont acting) in
acco dance with the 16 edition of the IEE Wi ing Regulations, (BS.7671: 1992), and any
elevant Local Autho ity Bye-Laws.
This heate is fitted with a 3-co e mains supply cable and should be pe manently
connected to the elect icity supply via a double pole switch having 3mm gap on each pole.
A switched fused connection unit to BS.1363 Pa t 4 is a ecommended mains supply
connection accesso y to ensu e compliance with safety equi ements applicable to a fixed-
wi ing installation.
PROCEDURE
1. Remove the f ont cove (2 sc ews on the side and 2 sc ews on the bottom).
2. Ma k top 2 sc ew fixing positions ‘A’ in acco dance with the dimension shown on the
diag am. The unit must be sc ewed to the wall with 3 sc ews th ough the holes p ovided
in the case. D ill 2 holes in the wall to suit No 10 wood sc ews ( ound Head) and inse t
wall plugs. At the top 2 sc ew positions ‘A’ sc ews can now be sc ewed in until the
heads a e app oximately 5mm f om the wall. The unit can now be hung on these two
sc ews and the position of the thi d bottom fixing ma ked on the wall. Remove the unit
f om the wall and d ill a thi d fixing hole in the position ma ked and inse t a wall plug.
The unit can now be hung on the wall and the thi d sc ew sc ewed in. Befo e tightening
all th ee sc ews ensu e the unit is ho izontal.
3. Refit f ont cove . Ensu e g ille ba s inte nal/exte nal a e spaced equally.
OPERATION
This heater can only be sed when connected to a CZC1 wireless programmable timer.
Each CZC1 can cont ol any numbe of heate s. The heate has an indicato light positioned
behind the fascia panel on the top ight side. The light may be:
Green - when no heat is needed
Yellow - when some heat is needed to maintain the oom tempe atu e
Red - when the heate is on full powe
Fast Flashing Red - when the heate has ove heated and the Elect onic Safety Cont ol
has switched the heate off.
Please efe to the CZC1 use and ope ating inst uctions fo full ope ational details.
E LECTRONIC S AFETY C ONTROL
The appliance is fitted with an Elect onic Safety Cont ol (ES). This is a safety device,
which switches the heate off if, fo any eason, the appliance ove heats. Ove heating is
indicated by a fast flashing ed light. The ES cont ol can only be e-set afte the appliance
has cooled down. In o de to e-set the ES cont ol, p oceed as follows:
•Switch the appliance off at the mains by using the isolato switch and leave to cool
down fo app oximately 5 minutes.
•Switch appliance back on and the ES cont ol will e-set.
•Ensu e that the appliance is functioning co ectly. If the ES cont ol ope ates again,
the appliance should be checked by a competent elect ician.
