Consort CSL2LST Original operating instructions

62001231 Iss 03
CSL2LST
CSL2MLST
Installation & operation Guide for wirelessly controlled
2kw Low Surface Temperature Fan Heaters
All electrical appliances produced by the Consort are guaranteed for one year against
faulty materials or workmanship. This applies only if the appliance has been used for
purposes in accordance with the instructions provided and has not been connected to an
unsuitable electricity supply, or subject to misuse, neglect, damage or modified or repaired
by any person not authorised by us. This guarantee is offered to you as an extra benefit and
does not affect your legal rights.
The correct electricity supply voltage is shown on the rating label attached to the
appliance.
Reasonable care has been taken to ensure that this guide is accurate at the time of
printing. In the interest of progress the Company reserve the right to vary specifications from
time to time without notice.
QUALITY SPACE HEATERS
Models

62001231 Iss 03
2
General Safety
Our Low Surface Temperature heaters
have been designed and built to the
NHS requirement for safe surface
temperatures which is that no surface
which can be touched by the user will
be more than 43 ºC (at a room
temperature of 21 ºC) This means that
our Low Surface Temperature heaters
out-perform the European Standard by
a significant margin.
The appliance is not intended for use by
persons (including children) with
reduced physical, sensory or mental
capabilities or lack of experience and
knowledge unless they have been given
supervision or instruction concerning use
of the appliance by a person
responsible for their safety. Children
should be supervised to ensure that they
do not play with the appliance.
Safety Monitor
As part of the intelligent control (see
section 15), the heater has built-in safety
monitoring. In the unlikely event of a
fault, the safety monitoring will help
prevent high surface temperatures. The
safety monitor will identify overheating,
fan failure and certain electronic faults.
When the safety monitor identifies a
fault, the heater runs in restricted mode.
However, in the event of a serious fault
the heater stops running. The heater
indicates a fault by beeping twice. It will
not beep again until the unit is switched
off and then back on, but the LED will
flash red continuously.
Thermally Operated Cut-Out
The appliance is fitted with a thermally
operated cut-out (TOC). In the unlikely
event that the safety monitor fails, this
safety device will switch the heater off if
the appliance overheats. If the TOC has
tripped there is a high possibility the
heater is faulty and should be checked
by a qualified person. The TOC can only
re-set after the appliance has cooled
down, however we advise not to do this
until the heater has been checked
In order to re-set the TOC, proceed as
follows:
· Switch off appliance and leave for
approximately 10 minutes.
· Switch appliance back on and the
TOC will re-set.
· Ensure that the appliance is
functioning correctly. If the TOC
control operates again, the
appliance should be checked by a
qualified person.
The heater carries a ‘Do Not Cover’ label to
warn the user that if the appliance is
covered, there is a risk of overheating.
Warning
· Do NOT site the appliance in a corner.
· Do NOT handle the appliance with wet
hands.
· Do NOT use the appliance in workshops or
rooms where excessive dust is generated
or present.
· Ensure that nothing is pushed into the air
outlet of this appliance.
· Do NOT touch outlet grille when the
appliance is in use.
· Do NOT cover or restrict the appliance
when in use.
· Do NOT use the appliance if damaged.
· Do NOT leave the appliance unattended
where young children are present.
· This appliance must be earthed.
Intelligent Fan Control
The intelligent fan control incorporates one of
the latest low energy consumption EC
motors. This allows the heater to operate
quietly, whilst still providing the best possible
levels of comfort.
The intelligent fan control is only activated
when the heat is switched on. If the heater is
running in fan/boost mode only (heat
switched off), then the fan will operate at a
fixed speed.
When activated, the intelligent fan control
detects the temperature of the room.
Depending on which heat mode is
activated, it will calculate the best possible
airflow temperature and will adjust the fan
speed accordingly.
NOTE: When turning the heater on, or changing
heat mode or fan speed mode, the fan will
respond accordingly after a small time delay.

3
SLPB SLTI SLVT
Please refer to the SL user and operating instructions for full operational details.
SL wireless controllers
62001231 Iss 03
SLVTB
Controls
When the appliance is connected to the mains
supply and the wall socket is switched ‘ON’ the
mains neon indicator will light locate at the
front, showing that the power is available to
Operation
This heater can only be used in conjunction with
any Consort wireless controllers. Each controller
can control any number of heaters in the same
room.
CRXSL wireless controller
Please refer to the CRXSL installation and control
guide for full operational details.
Intelligent Fan Control
The intelligent fan control incorporates one of the
latest low energy consumption EC motors. This al-
lows the heater to operate quietly, whilst still
providing the best possible levels of comfort.
The intelligent fan control is only activated when
the heat is switched on. If the heater is running in
fan/boost mode only (heat switched off), then
the fan will operate at a fixed speed.
When activated, the intelligent fan control de-
tects the temperature of the room. Depending on
which heat mode is activated, it will calculate the
best possible airflow temperature and will adjust
the fan speed accordingly.
NOTE: When turning the heater on, or changing
heat mode or fan speed mode, the fan will
respond accordingly after a small time delay.
Wall mounting
Located on the rear of the heater are two key-
hole slots used for wall mounting. Attach screws to
the wall following the recommended clearances
in figure 1.
Remove the two wall brackets that are screwed
to the bottom of the heater. Rotate them 180 de-
grees as shown in figure 1.
Install the heater on the two screws, ensuring it
drops into the two locating slots and is tight
against the wall.
With the heater in position, mark the holes for
each of the bottom brackets. Screw the bottom
brackets to the wall.
Light colour Heater status
STAND-BY No heat output
Reduced heat output
Full power heat output

4
62001231 Iss 03
CUSTOMER HELPLINE
Should you need any advice on the use of your new Consort product please contact our
Helpline:
Consort Equipment Products Limited
Thornton Industrial Estate, Milford Haven, Pembrokeshire, SA73 2RT
Tel: [phone] Fax: [phone] Email: [e-mail] Web:
www.consortepl.com
Operation hours: Mon to Thu 8.30am to 4.30pm | Fri 8.30am to 3.30pm
BS EN ISO 9001 Registered Company No FM12671
Wall mounting
