MINITERM
CICP1200 2-Door Intelligent Controller
The Miniterm (CICP1200) has 8 inputs, 1 tamper
alarm and 5 outputs. A locking steel enclosure, power
supply and battery are included.
Miniterm is an intelligent controller capable of supporting all
access control functions for one to two doors. This distributed
processor-based panel will operate as a standalone unit in the
event server communications is interrupted. The Miniterm is
programmed via Continental Instruments (CIC) CardAccess
software program, a Windows-based access control and
security management solution. Once programmed, the
controller does not require continuous server communications,
as it automatically stores system transactions in its internal
memory.
Up to 63 CIC Intelligent Controllers (Microterm, Miniterm,
Smarterm or Superterm) can be intermixed on the same
communications network. Multiple communication networks
(ports) can be connected to the CardAccess®server for
maximum system expansion. Controller communication
choices include: hardwire (repeat or multi-drop mode), LAN/
WAN, dial-up or fiber optics for maximum flexibility. The
Miniterm supports RS232 and RS422 communication formats
for optimal system configuration.
The Miniterm accepts industry standard Wiegand output
devices and supports virtually all card/reader technologies.
Proximity, Biometric, Magnetic Stripe, Barcode, Wiegand,
Barium Ferrite, Keypad and Smart Readers are easily
connected and controlled. The Miniterm can store multiple card
(bit) formats in its internal memory, making it a cost-effective
retrofit panel. Supporting multiple bit formats allows existing
card populations and readers to remain in place. The Miniterm
contains a 2.4AH rechargeable standby battery, providing 4-6
hours standby. In addition to the rechargeable standby battery,
each Miniterm includes a lithium battery for up to one year of
data protection.
This Intelligent Controller is UL Listed for UL294 (Access
Control System Unit), UL1076 (Proprietary Burglar Alarm
Unit) and UL1950 (Information Technology Equipment).**
Continental Instruments, A Napco Security Group Company •355 Bayview Ave., Amityville, NY 11701
[phone] •FAX [phone] www.cicaccess.com GSA GS-07F-00039H
Miniterm Capacities
Cards 3300 standard
Readers (5-wire) 2 (Wiegand output)
Keypads (5-wire) 2 (Wiegand output)
Keypads (7-wire) 2 X-Y Matrix type
Readers
w/Keypad
2 5-wire Readers with 2 or 4 X-Y Matrix Keypads
Standard
Inputs
8 (Supervised)
Expanded
Inputs
N/A
Standard
Outputs
5 Form C rated at 3A@24VDC/VAC
Expanded
Outputs
N/A
Transaction
Buffer
1000
Time Schedules 128
Access Groups 1000
Holidays 50
Reader Power 200mA@5VDC, 200mA@12VDC
Battery Backup 4-6 hours included
Enclosure Size 15.25”H x 12.5”W x 4”D, 18lbs.
UL Listings UL294, UL1076, UL1950**
** UL1950 replaced with EN60950 in Q2/2003

Typical Door Configuration
See Continental Instruments Configuration Guide for
additional detailed system wiring information.
Continental Instruments, A Napco Security Group Company •355 Bayview Ave., Amityville, NY 11701
[phone] •FAX [phone] www.cicaccess.com GSA GS-07F-00039H
CardAccess®and CI SQL 3000™are trademarks of Continental/NAPCO. © Continental Instruments/NAPCO, 2003.
CICP1200 Two-Door Intelligent Controller
Continental Instrument’s Controllers can connect to the
CardAccess Server via hardwire (shown below), LAN/WAN
dial-up modem or fiber optics. See the CIC Configuration
Guide for additional detailed system information.
Miniterm Components
QTY. Part No. Description
1CICP1200 Two (2) reader controller with standard
3,300 card capacity, 8 EOL Class
A supervised alarm inputs, tamper
alarm, and 5 relay outputs. Unit ships
complete in a lockable steel enclosure
including battery standby for memory
and system operation.
1Standard 14VAC Power Supply via step-
down transformer mounted inside
enclosure. 10’ power line cable with
110VAC plug is included.
1Standard 2.4 AH Battery Backup included.
Door Contact
Electric
Door Strike
Door Lock
Power Supply
RS422 to Panels
Continental
Instruments llc
Re
q
uest to Exi
t
M
o
ti
o
n D
e
t
ec
t
o
r
Door Contact
C
ard Reader
Request
to Exit
B
u
Doo
r
Lock
A or B
G
D
G
G
G
Request
to Exit
G
H
G
NOTE: Request to Exit motion detectors will require
an additional 12VDC power cable. Exit devices are
typically mounted on the egress side of door.
C
ardAccess
3000
D
a
t
abase
a
n
d
C
ommunication
s
S
erve
r
C
I
C
E1
9
4
0
PL-
1
Pollin
g
Line Converte
r
R
S
2
3
2 to R
S
42
2
Required if server is not located
within 5
0
RS422 Re
p
eat Mode Communications Networ
k
4
000
' max. distance between controllers.
U
p
to 63 controllers on a Re
p
eat Mode Network
.
p
erter
m
Su
p
p
p
erter
m
Su
p
p
RS
42
2
x
. 4
000'
R
S
42
2
Max. 4
000'
R
S
42
2
Max. 4
000'
R
S
42
2
Max. 4
000'
R
S
42
2
Max. 4000'
R
S
2
32
Max.
50'
nit
e
r
m
M
i
i
m
arter
m
Sm
m
C
A430A
