Control iD iDAccess Nano User manual

Quick Guide –iDAccess Nano –Version 1.0 –Control iD 2021 ©
iDAccess Nano –Quick Guide
Thank you for purchasing iDAccess Nano! To access
detailed information about your new product,
please check the following link:
www.controlid.com.br/userguide/idaccess-nano-
en.pdf
Necessary Materials
In order to install your iDAccess Nano, you will
need the following items: drill, wall plugs and
screws, screwdriver or Philips, 12V power supply
with at least 1A and an electronic lock.
Installation
For the correct operation of your iDAccess Nano,
the following precautions should be taken:
•Install in a place that is not exposed to
direct sunlight and that is protected from
rain and other natural phenomena.
•Avoid metallic objects near the rear of the
device in order not to impair the proximity
reader’s range. In case this is not possible,
use insulating spacers.
•Fix the bottom part of the wall support for
iDAccess Nano at 1.2m from the ground.
•Before securing the device in place, ensure
all connecting cables are correctly routed
towards the device.
The device installation process is simple and
should follow the diagram below:
1.For greater security during the installation,
place the External Access Module (EAM) in a
secure region (internal area of the facility)
2.Use one of the reference patterns in the back
of this guide to drill the holes required to
install the iDAccess Nano and fit in the wall
plugs.
3.Connect the EAM to a +12V power source and
to the lock, using the cables supplied.
4.Propose a 4 –way cable long enough to
connect the EAM to the iDAccess Nano. For
distances that are greater than 5m, use a
twisted pair cable. Remember to use the
same pair for signals A and B.
⚠The EAM is responsible for powering
iDAccess Nano.
5.Connect the wire harness provided with
iDAccess Nano to the 4 wires in the previous
item.
6.Remove the wall support from the iDAccess
Nano.
7.Screw the wall support with the wall plugs.
8.Connect iDAccess Nano to the 4-way wire
harness
9.Secure the iDAccess Nano on the wall support
and secure it in place with the screws provided
together with the connection cables.
Description of the Connection
Terminals
On your iDAccess Nano, there is a connector on
the back of the device, besides the network
connector (Ethernet). In the External Access
Module (EAM) there is a matching connector and
3 other connecting pins that will be used to
connect locks, switches and scanners as explained
ahead.
iDAccess Nano: 4 - Pin Connector
EAM: 2 - Pin Connector (Power Supply)
⚠The connection to a +12V power supply with at
least 1A is fundamental for the correct operation
of the device.
EAM: 4 - Pin Connector
EAM: 5 - Pin Connector (Wiegand In/Out)
⚠External card readers should be connected to
Wiegand WIN0 and WIN1. In case there is a
control board, one can connect the Wiegand
WOUT0 and WOUT1 outputs to the control board
so that the user´s ID identified in the iDAccess
Nano is transferred to it.
EAM: 6 - Pin Connector (Door Control/Relay)
⚠The push button and door sensor inputs can be
configured as NO or NC and must be connected to
dry contacts (switches, relays etc.) between the
GND and respective pin.
iDAccess Nano Settings
The configuration of all the parameters of your new
iDAccess Nano can be set through the LCD display
(Graphic of user Interface –GUI) and/or through a
standard internet browser (as long as the iDAccess
Nano is connected to an Ethernet network and has
this interface).
In order to configure for example the IP address,
subnet mask and gateway, through the touch
screen, follow these steps: Menu →Settings →
Network. Update the information as you wish and
connect the device to the network.
Web Interface Settings
First, connect the device directly to a PC using an
Ethernet cable (cross or direct). Next, set a fixed IP
on your computer for network 192.168.0.xxx
(where xxx is different from 129 so that there is no
IP conflict) and mask 255.255.255.0.
To access the device settings screen, open a web
browser and enter the following URL:
http://192.168.0.129
The login screen will be shown. The default access
credentials are:
• Username: admin
• Password: admin
⚠Through the web interface you can change the
device’s IP. If you change this parameter,
remember to write down the new value so that you
can connect to the product again.
Electronic lock types
iDAccess Nano, through the relay in the External
Access Module, is compatible with almost all of the
locks available in the market.
Magnetic lock
The magnetic or electromagnetic lock consists of
a coil (fixed part) and a metal part (armature
plate) which is attached to the door (mobile part).
While there is a current passing through the
magnetic lock, the fixed part will attract the
mobile part. When the distance between these
two parts is small, ie. when the door is closed and
the dock is on top of the fixed part, the attraction
force between the parts can reach over 1000kgf.
Thus, the magnetic lock is normally connected to the
NC contact of the activation relay, as we normally
want for the current to go through the
electromagnet and, if we want the door to open, the
relay must open and interrupt the current flow.
In this guide, the magnetic lock will be
represented by:
Power
Supply
+12V
Relay, door sensor and push button
Wiegand input and output
Power supply for
iDAccess Nano and
communication
2
5
6
4

Quick Guide –iDAccess Nano –Version 1.0 –Control iD 2021 ©
Electric bolt
The electric bolt lock, also known as solenoid lock,
consists of a fixed part with a mobile pin
connected to a solenoid. The lock normally comes
with a metal plate that will be attached to the
door (mobile part).
The pin on the fixed part enters the metal plate
preventing the door from opening.
In this guide, the solenoid pin lock will be
represented by:
⚠The gray terminals may not be present in all
locks. If there is a power supply connection (+ 12V
or + 24V), it is essential to connect it to a source
before operating the lock.
Electromechanical Lock
The electromechanical lock or strike lock consists of
a latch connected to a solenoid through a simple
mechanism. After opening the door, the mechanism
returns to its initial state allowing the door to be
closed again.
Thus, the electromechanical lock typically has two
terminals connected directly to the solenoid. When
current passes through the lock, the door will be
unlocked.
In this guide, the electromechanical lock will be
represented by:
⚠Confirm the operating voltage of the lock
before connecting it to the iDAccess Nano! Many
electromechanical locks operate at 110V/220V
and must therefore use a different wiring set up.
Wiring Diagrams
iDAccess Nano and EAM (Mandatory)
Magnetic Lock
Solenoid Pin Lock (Fail Safe)
⚠We recommend the use of a dedicated power
supply source to power the Solenoid Lock.
Reference pattern for installation
(2 models)
Electromechanical Lock (Fail Secure)
⚠We recommend the use of an exclusive power
supply source to power the Electromechanical Lock.
Push Button
Door Sensor
Diode
Power Supply
+12V/1A
Diode
Power Supply
+12V/1A
Diode
Power Supply
+12V/1A
