Du Pont WFPF3800 Series User manual

Installation
Instructions
Universal Valve-in-Hea
Whole House Filtration Systems
Instrucciones e instalación
Sistema universal e filtra o para to a la casa con válvula en el cabezal
Water Filtration
Model Series WFPF3800 & WFPF2800
Serie del modelo WFPF3800 y WFPF2800
V4.0

Package Contents
Installation Instructions
Universal Valve-in-Hea
Whole House Filtration System
Parts & Hardware Included
AValve-in-Hea Filter System
(System Hea with Filter Housing)
BBlack O-Ring
CFilter Cartri ge
DFilter Housing Wrench
Tools & Materials Required
nCompression Fittings/Valves (not inclu e )
(See Step 2: Configure Your System)
nTwo A justable Wrenches
nPipe Wrench
nPipe Cutter or Hacksaw
nPan or Bucket
nFile
nPencil
nPlumber’s Tape
nSilicone Grease
Optional Materials
nMounting Bracket, Bolts & Screws
DuPont Part No. WFAB150
nGroun ing Kit
A
B
A
D
C
For installations in Massachusetts, the Commonwealth of Massachusetts Plumbing Code CMR248 shall be adhered to.
www.waterfiltration.DuPont.com
Protect Plus, LLC n Hickory, NC 28601 USA
866-709-2086 T ll Free
For Service Requests & Pro uct Information
Hours of Operation: 24 Hours/Day, 7 Days/Week
800-441-7515
For Safety & Health Questions
Information & Assistance
System Head
Black O-Ring
DuPont Part No. WFAO150
Filter Cartridge
Filter Housing
Filter Housing Wrench
DuPont Part No. WFAW150

WFPF3800 / WFPF2800 Series 2V4.0
Proper Installation
Please rea all instructions, specifications, an precautions before installing an using your water filter system.
Precautions:
For col water use only.
After prolonge perio s of non-use (such as uring a vacation), it is recommen e that the system be flushe thoroughly. Let water run
for 10 minutes before using.
The filter cartri ges use with this system have a limite service life. Changes in taste, o or, an /or flow of the water being filtere
in icate that the cartri ge shoul be replace .
Do not install where system will be expose to irect sunlight.
Your water filtration system will withstan up to 100 psi water pressure. If your house water supply pressure is higher than 100 psi, install
a pressure re ucing valve before the system is installe .
Before You Begin
nLocate the main water supply line to your home an check to see what type of plumbing is in place (ex: plastic, copper, galvanize ).
The main water supply line is typically locate in a basement, crawlspace or garage. Connect to col water line only.
nMeasure the iameter of the existing pipe to etermine what size fittings an /or valves (not inclu e ) will be require .
nChoose a location in the main supply line to install the Filter System. Make sure to place the Filter System in an area after the
water meter or pressure tank an before the water heater. Also select a location that will be easily accessible when changing
filter cartri ges.
nConsult your local plumbing co es an install accor ingly.
This filter must be protecte
from freezing, which can
cause cracking of the filter
an water leakage.
CAUTION
Because of the pro uct’s limite service life an to prevent costly repairs or possible water amage, we strongly
recommen that the housing be replace every ten years. If the hea of the filter has been in use for longer than
this perio , it shoul be replace imme iately. Date the top of any new hea to in icate the next recommen e
replacement ate.
CAUTION

WFPF3800 / WFPF2800 Series 3V4.0
STEP 1
Turn Off the Main Water Supply Line
1Turn off the main water supply line to your home.
2Purge all water from the plumbing lines by turning on all faucets in your home an raining completely.
STEP 2
Configure Your System
See the System Configuration Chart below to etermine how you will configure your filter system.
NOTE: For galvanized piping, consult a professional plumber.
2
The Filter System must be installe after the water meter or pressure tank.
CAUTION
1
Type of plumbing in your house: 3/4” Copper Pipe 1” Copper Pipe 3/4” PVC Pipe 1” PVC Pipe 3/4” PEX 1” PEX
Quantity Fitting Method Solder according to local
plumbing
No individual fitting - it
will require more than
just 1. Solder according
to local plumbing codes
Use PVC Primer & PVC
Pipe Cement per your
local plumbing codes
Use PVC Primer & PVC
Pipe Cement per your
local plumbing codes
You may need to consult
your local plumber -
requires special tools
You may need to consult
your local plumber -
requires special tools
2 Std Mal Adapt r 3/4” Mal Adapt rs
1” x 3/4” r ducing
coupling & 3/4” mal
adapt r & 3/4” x 2” copp r
nippl
3/4” MPT x 3/4” tub mal
adapt r PVC Slip Typ
3/4” MPT x 1” tub mal
adapt r PVC Slip Typ
3/4” MPT x 3/4” CTS QC
Adapt r
(WATTS Wat r PEX)
3/4” MPT x 1” CTS QC
Adapt r
(WATTS Wat r PEX)
2 Compr ssion
3/4” OD tub x 3/4” MIP
Compr ssions Mal
Adapt r
Compr ssion not r adily
availabl for 1” copp r
pip
n/a n/a
2 Union
3/4” Copp r Union & 3/4”
Mal Adapt r & 3/4” x 2”
copp r nippl
1” Copp r Union & 1” x
3/4” r ducing coupling &
3/4” mal adapt r & (2)
3/4” x 2” copp r nippl
3/4” PVC Union & 3/4”
MPT x 3/4” tub mal
adapt r PVC Slip Typ &
3/4” x 2” PVC nippl
1” PVC Union & 3/4” MPT
x 1” tub mal adapt r
PVC Slip Typ & 1” x 2”
PVC nippl
Mat rials N d d For 3/4” Diam t r Housing Inl t/Outl t Ports

STEP 3
Assemble the System
1Dry assemble the complete system (accor ing to the configuration chosen), inclu ing all fittings an valves.
OPTIONAL: If using a mounting bracket (not included), position it on the Filter System Head in alignment with the inlet and outlet ports.
2Measure the overall length (see iagram) of the configure system.
3Re uce this measurement enough to allow for the amount of engagement (X) to etermine how much pipe to remove from the line.
STEP 4
Mark Measurements and Cut the Plumbing Pipe
1Mark the section of the plumbing pipe that will nee to be remove (X) to allow for the configure system (as etermine in Step 3).
NOTE: Measure twice, cut once!
2Using a pipe cutter or hacksaw, cut the marke section from the plumbing pipe.
NOTE: Use a pan or bucket to catch any remaining water in the pipes.
3Remove any burrs or ebris from the cut e ges with a file.
3
WFPF3800 / WFPF2800 Series 4V4.0
4
1
2
3
Please wear safety glasses to protect
eyes when cutting.
CAUTION

WFPF3800 / WFPF2800 Series 5V4.0
STEP 5
Hang the Filter System Head
1Align the System Hea Aon the pipes so that the inlet an outlet are in the correct locations. The "in" port on the Filter
System shoul be facing the incoming water supply.
2Allow the System Hea to temporarily hang between the two cut plumbing pipes.
3Apply plumber’s tape or appropriate sealant to the fittings an lines, accor ing to your system configuration.
4Make all connections an tighten fittings.
NOTE: Keep the Filter System in an upright position.
STEP 6
Install the Filter Housing
1Insert the Filter Cartri ge Cover stan pipe in the bottom of the Filter Housing A.
2Screw the Filter Housing back onto the System Hea an han -tighten. Using the Filter Housing Wrench D, tighten 1/4 turn.
NOTE: Do not over tighten.
5
3
A groun ing kit (not inclu e ) must be installe on water pipes if they are
use to groun electrical systems, appliances or phones.
CAUTION
GROUNDING KIT (NOT INCLUDED)
WATER
FLOW
TO
HOUSE
6
2
D
A
A
IN OUT
C

WFPF3800 / WFPF2800 Series 6V4.0
STEP 7
Test the Filter System for Proper Operation
1Turn the valve lever on the System Hea Ato the off position by lining up the re in icator on the valve with “OFF”
written on the System Hea .
2Turn on the water supply.
3Slowly turn the valve on the System Hea to the “FILTER” position by rotating it clockwise until it stops. The re in icator on the
valve shoul line up with “FILTER” written on the system hea .
4Check for any leaks between the System Hea an Filter Housing of the Filter System, an on the inlet an outlet connections. If
there are leaks, see the troubleshooting tips below.
5Turn on the nearest faucet an flush the Filter System for 40 minutes.
If there are leaks between the head and housing of the Filter System:
nTurn the valve lever on the System Hea to the "OFF" or “bypass” position.
nUnscrew an remove the sump part from the hea part using the Filter Housing Wrench D.
NOTE: Use a pan or bucket to catch any water in the housing.
nRemove the Black O-Ring Ban inspect. Clean an lubricate with silicone grease.
nClean the grooves in the top of the Filter Housing where the O-Ring sits.
nPlace the clean, lubricate O-Ring back in the groove.
nScrew the Filter Housing back onto the System Hea an han -tighten. Using the Filter Housing Wrench, tighten 1/4 turn.
NOTE: Do not over tighten.
nTurn the valve lever on the System Hea to the "ON" position an inspect for leaks.
If there are leaks on the inlet and/or outlet connections:
nTurn off the main water supply to your home.
nPurge all water from the plumbing lines by turning on all faucets in your home an raining completely.
nTighten all fittings.
nTurn on the main water supply an turn the valve lever on the System Hea to the "ON" position an inspect for leaks.
nIf leaks continue, isassemble the configure system, reapply plumber’s tape or sealant, an reinstall the Filter System.
‰ If leaks continue, turn off the water supply an call Customer Service or consult your local plumber.
7
3
WATER
OFF
BYPASS
FILTER
(WATER ON)

WFPF3800 / WFPF2800 Series 7V4.0
Filter Cartridge Replacement
STEP 1
1Turn the valve on the System Hea Ato the "OFF" or “BYPASS” position.
NOTE: “Off” will shut off all water flow in the home. “Bypass” will allow unfiltered water to Flow in the home.
2Use the Filter Housing Wrench Dto unscrew the Filter Housing.
NOTE: Use a pan or bucket to catch any water in the Filter Housing.
3Pour out the water in the Filter Housing an remove the use Filter Cartri ge B.
STEP 2
NOTE: Have a pan or bucket handy to rinse out the Filter Housing.
1Rinse out the bottom of the Filter Housing.
2A enough water to fill the Filter Housing 1/3 full. A approximately 2 tablespoons of bleach an clean the System Hea an
bottom of the Filter Housing with a clean cloth. After cleaning, rinse the Filter Housing thoroughly to remove bleach.
3Remove the O-Ring Bin the top of the Filter Housing an wipe clean.
4Use silicone grease to lubricate the O-Ring.
5Place the O-Ring back in the groove of the Filter Housing.
NOTE: Make sure that the O-Ring is seated properly in the groove to ensure a good seal.
STEP 3
1Insert the new filter cartri ge over the stan pipe in the bottom of the Filter Housing.
2Screw the Filter Housing back onto the System Hea an han -tighten. Using the Filter Housing Wrench, tighten 1/4 turn.
NOTE: Do not over tighten.
3Slowly turn the valve on the System Hea to the "FILTER" position to allow the Filter Housing to fill with water.
4Check for any leaks before procee ing.
5Turn on the nearest faucet an flush the Filter System for 40 minutes.
1
1
C
WATER
OFF
2
B
D
3
3
WATER
OFF
BYPASS
FILTER
(WATER ON)

WFPF3800 / WFPF2800 Series 8V4.0
These units are inten e for non-commercial use. They shoul be use only in
ambient air temperature of between 35 egrees F / 2 egrees C an 100 egrees
F / 38 egrees C. Placement of these units in irect sunlight or use of electrical
heating equipment on these units must be avoi e . Replace filter cartri ge when
an as irecte in the installation/ operation instructions inclu e with each
cartri ge. Replacement filter cartri ges are available at retail outlets.
Operation/Maintenance Data
• These filters are not water purifiers. Do not use with water that is microbiologically
unsafe or of unknown quality without a equate isinfection before or after the
system. Systems certifie for Cyst re uction may be use on isinfecte waters
that may contain filterable Cysts.
• This unit is not esigne to filter sulfur (rotten egg o or). Use of carbon filters to
treat sulfur may intensify taste/o or problems.
• Please comply with all state an local regulations regar ing the installation of
water treatment evices.
• The contaminants or other substances re uce by the water filter evice are not
necessarily in your water.
CAUTION
Usage an quality of water in your incoming water line affect the life of filter cartri ges
an etermine when the cartri ge shoul be change . Cartri ges shoul be replace
sooner if water pressure at the faucet begins to rop noticeably or if the filter fails to
perform satisfactorily.
Replacement Cartri ges
DuPont™ Universal Valve-in-Hea
Whole House Filtration Systems WFPF3800 an WFPF2800 Series
System Cartri ge Mo el Numbers
________________________________________________________________________________________________
Universal Valve-in-Hea WFPFC3002, WFPFC4002, WFPFC5002,
Whole House Filtration System WFPFC8002, WFPFC9002
WFPF2800 Series
________________________________________________________________________________________________
Universal Valve-in-Hea WFPFC3002, WFPFC4002, WFPFC5002,
Whole House Filtration System WFPFC8002, WFPFC9002
WFPF3800 Series
Replacement Parts
DuPont™ Universal Valve-in-Hea
Whole House Filtration Systems WFPF3800 an WFPF2800 Series
Part Number Description
________________________________________________________________________________________________
WFAB150 Mounting Bracket
________________________________________________________________________________________________
WFAO150 O-Ring
________________________________________________________________________________________________
WFAW150 Filter Housing Wrench
________________________________________________________________________________________________
www.waterfiltration.DuPont.com
Protect Plus, LLC n Hickory, NC 28601 USA
866-709-2086 Gratis
For Service Requests & Pro uct Information
Hours of Operation: 24 Hours/Day, 7 Days/Week
Or ering Information:

WFPF28001C
Conteni o el embalaje
Instrucciones e instalación
Sistema universal e filtra o para to a la
casa con válvula en el cabezal
Piezas y elementos de montaje incluidos
ASistema e filtra o con válvula en el cabezal
(Cabezal el sistema con carcasa el filtro)
BRetén anular negro
CCartucho el filtro
DLlave para la carcasa el filtro
Herramientas y materiales necesarios
nVálvulas/conexiones e compresión (no inclui as)
(Vea el Paso 2: Configuración e su sistema)
n2 llaves ajustables
nLlave e tubos
nCorta or e tubos o sierra cortametales
nBan eja o cubo
nLima
nLápiz
nCinta para cañerías
nGrasa silicona a
Optional Materials
nSoporte e montaje, pernos y tornillos
Nº de pieza DuPont WFAB150
nConexión e puesta a tierra
A
B
A
D
C
Para instalación en Massachusetts, se debe cumplir el Código de Plomería de la Mancomunidad de Massachusetts CMR248.
www.waterfiltration.DuPont.com
Protect Plus, LLC n Hickory, NC 28601 USA
866-709-2086 Gratis
Para solicitu es e servicio e información e pro uctos
Horarios e atención: Las 24 horas, los 7 ías e
la semana
800-441-7515
Para preguntas sobre salu
y seguri a
Información y asistencia
Cabezal del sistema
Ret n anular negro
Nº de pieza DuPont WFAO150
Cartucho del filtro
Carcasa del filtro
Llave para la carcasa
del filtro
Nº de pieza DuPont WFAW150
