Prior to starting the engine, select the proper throttle control mode and parameters required
for application.
CAN Bus Configuration
This module communicates to the engine ECUvia the J1939 CAN Bus network. This is a three
wire connection to the engine ECU. Engine information and alarmcodes are broadcast over the
CAN bus fromthe engine ECU to the controller display.
To assure proper communications between the engine ECU and the controller, the correct
SOURCE ADDRESS need to be selected in the controller for the particular engine make and
model. These settings are available in the CAN CONFIGURATION MENU.

CONTROLS, INCORPORATED
C O N T R O L S Y S T E M S & S O L U T I O N S
- 3 -
INSTALLATION INFORMATION

CONTROLS, INCORPORATED
C O N T R O L S Y S T E M S & S O L U T I O N S
- 4 -
CONNECTOR INFORMATION

CONTROLS, INCORPORATED
C O N T R O L S Y S T E M S & S O L U T I O N S
- 5 -
ENGINE ALARMS, CODES AND MESSAGES
Engine ECU Alarm/De-Rate/Shut Downs
It isimportant to understand panel operation with respect to engine safety protections, alarms, and
fault codes. The panel operates with J1939 engines. These engines have an ECU (engine control
unit) which is essentially a computer that runs the engine. When engine parameters are out of
normal operating ranges,the ECU takes specific actions which canincludethe following:
1) Broadcast a trouble code
2) Broadcast a red or yellow lamp
3) De-rate the engine
4) Shut down the engine
5) Turn on alarmhorn
It is the engine ECU that de-ratesor shuts down the engine when itis not operating within normal
parameters. This includes more common shut downs like high engine temperature and low oil
pressure but can encompass a large range of parameters depending on the ECU.
Alarm Annunciation and Code Reader
This panel is configured to operate with standard J1939 engines where engine de-rate and
shutdowns are managed by the engine ECU. The panel communicates with the engineECU and
serves as a trouble code reader. When the engine ECU broadcasts a trouble code (called an
SPN.FMI code) the panel does the following:
1) Illuminate the appropriate LED indicator lamp
a. Yellow Lamp = Alarm
b. Red Lamp = Engine Shut Down
2) Displays the trouble code (standard SPN.FMI code)
3) Displays a code description on the LCD screen
4) Displays the occurrence count of the code

CONTROLS, INCORPORATED
C O N T R O L S Y S T E M S & S O L U T I O N S
- 6 -
Indicator Lamps
.
Active and Stored Engine ECU Codes
The panel also provides the ability to check the engine ECU for all ACTIVE and STORED engine
ECU codes. These codes can be viewed via the Active Codes and Stored Codes menus.
Engine
Fault
Lamp
Engine
Alarm
Lamp

CONTROLS, INCORPORATED
C O N T R O L S Y S T E M S & S O L U T I O N S
- 7 -
CONTROL PANEL ANALOG AND DIGITAL INPUTS
The panel has one analoginput and up to one digital input available to monitor other components,
sendersor signals. These inputs can be used for a number of purposesincluding alarms and shut
downs.
Input
Heading
Default
Options
Connector
Pin
Analog 1
Function
A
5
Digital 1
Normally
Open
Open / Closed
A
4
Function
None
Message
None
Check
Off
Off / Always / Run
Digital 2
Normally
Open
Open / Closed
B
2
Function
None
Message
None
Check
Off
Off / Always / Run
Digital 3
Normally
Open
Open / Closed
B
5
Function
None
Message
None
Check
Off
Off / Always / Run

CONTROLS, INCORPORATED
C O N T R O L S Y S T E M S & S O L U T I O N S
- 8 -
1) Analog 1 Function Options
1) Fuel Level S-W –Fuel amount, in percentage, can be measured and displayed using a
standard Stewart Warner scale sender of 240 ohms –33 ohms. 240 = Empty and 33 = Full.
Sender ground must be common with batterynegative.
2) Fuel Level VDO –Fuel amount, in percentage can be measured and displayed using a VDO
scale sender of 10 ohms –180 ohms. 10 = Empty and 180 = Full. Sender ground must be
common with battery negative.
3) Oil Pressure 100 PSI –Oil pressure, in PSI, can be measured and displayed using a
standard Stewart Warner scale sender of 240 ohms –33 ohms. 240 = 0 PSI and 33 = 100
PSI. Sender ground must be common with battery negative.
4) Oil Pressure 125 PSI –Oil pressure, in PSI, can be measured and displayed using a
standard Stewart Warner scale sender of 240 ohms –33 ohms. 240 = 0 PSI and 33 = 125
PSI. Sender ground must be common with battery negative.
5) Oil Pressure bar –Oil pressure,in bar, can be measured and displayed standard Stewart
Warner scale sender of 240 ohms –33 ohms. 240 = 0 bar and 33 = 7 bar. Sender ground
must be common with battery negative.
6) Oil Pressure VDO PSI –Oil pressure,in PSI, can be measured and displayed using a
standard Stewart Warner scale sender of 10 ohms –180 ohms. 10 = 0 PSI and 180 = 150
PSI. Sender ground must be common with battery negative.
7) Oil Pressure bar –Oil pressure,in bar, can be measured and displayed using a standard
StewartWarner scale sender of 10 ohms –180 ohms. 240 = 0 bar and 33 = 10 bar.
Sender ground must be common with batterynegative.
8) Switch –This settingallows for a switch to be connected rather thanan analog sender. Set
Analog 1 Message to assign a label to theswitch device.
9) None –Setto None when no functionality is required.
2) Digital Function Activation
1) Off / Always / Run –Describes when the parameter will be monitored for alarm conditions.
Run refers to when theengineis running. Offdisables the alarmconditions. Always enables
the alarm constantly regardless of engine state.
2) AlarmDelay –The time period, after Sender Check Bypass, that the parameter must be on the
alarmcondition beforethe alarm becomes latched.

CONTROLS, INCORPORATED
C O N T R O L S Y S T E M S & S O L U T I O N S
- 9 -
MENU SYSTEM
To Enter Menu System
Hold MENU button and press ENTER button.
Menu Navigation
Press MENU button to scroll menu options.
Press UP arrow button to enter menu.
Press DOWN arrow button to reverse.
Exit Menu System
Hold MENU button and press ENTER button.
To Change a Setting
Press ENTER button to bring up brackets [ ].
Press UP arrow button and DOWN arrow button to change setting.
Press ENTER button to make selection, brackets disappear.
Recycle key to the OFF position after changing a setting.

CONTROLS, INCORPORATED
C O N T R O L S Y S T E M S & S O L U T I O N S
- 10 -
Main Menus
Main Menus
Sub Menus
Active Engine Fault Codes
View/Scroll Active Fault Codes
Stored Engine Fault Codes
View/Scroll Stored Fault Codes
Engine Parameters
View ECU Engine Information
(% Load, Torque, Oil Temp, etc.)
Engine Identification
Engine Model # View
Engine Serial # View
Module Information
Control Unit Part# View
Control Unit Software Version View
Controller Setup
Quick Setup
(1)
(PASSWORD PROTECTED)
Engine Parameter Configuration
(2)
Input Configuration
(3)
Module Configuration
(4)
Display Configuration
(5)
CAN Configuration
(6)
Maintenance Configuration
(7)
MODBUS Configuration
(8)
To access the controller setup menus, a password is required.
Configuration
Menus
Viewing Menus

CONTROLS, INCORPORATED
C O N T R O L S Y S T E M S & S O L U T I O N S
- 11 -
Configuration Menus
(1)
Quick Setup
Engine Manufacturer (Default = John Deere)
TSC Minimum Speed (Default = 650 RPM)
TSC Maximum Speed (Default = 2400 RPM)
Performance Display (Default = Off)
(3)
Input Configuration
Configure Parameter (Channels, Custom Message)
Digital Input 1 Configuration
Digital Input 2 Configuration
Digital Input 3 Configuration
(4)
Module Configuration
Pre Alarms Displayed (Default = 4)
Clear Number of Starts (Yes/No)
Engine Run Speed Criteria
Engine Stop Speed Criteria
(5)
Display Configuration
Pressure & Temp Units (English/Metric)
Performance Display On/Off
(6)
CAN bus Configuration
Engine Manufacturer (John Deere)
TSC1 Address (Default = 3) Others available
Source Address (Default = 44) Others available
Engine Address (Default = 0) Others available
Fuel Level Transmit
Voltage Transmit
Hours Transmit
Engine Status Transmit
Panel Status Transmit
Panel Information Transmit
Faults Transmit
Text During Sleep
JDLINK Auto Accept
(2)
Eng. Parameter Configuration
Parameter Selection (Speed, Coolant Temp., Oil Pressure, Fuel
Level, Voltage, Hour Meter)
Parameter Setup (Varies based on parameter)

12
(7)
Maintenance Configuration
Services Messages (Yes/No)
Maintenance Schedule Selection (A-C)
Schedule Reset (Yes/No)
Schedule Interval (Default = 1000 hrs.)
Schedule Warning (Default = 10 hrs.)
Schedule Trip (Default = 0 hrs.)
Schedule Message
(8)
MOD bus Configuration
Mode Off/Slave/Gauges
Baud Rate
Parity
Stop Bits
Slave Address
Communication Timeout
