Contura C 35 Low User manual

www.contura.eu
C 35
Installation
instruction

66
GB
CERTIFICATE
PRODUCT
Product type Stove lit with solid biofuels
Type designation Contura 35
Manufacturing number See rating plate on the stove
Intended area of use Heating of rooms in residential buildings
Fuel Wood
MANUFACTURER
Name NIBE AB / Contura
Address Box 134, Skulptörvägen 10
SE-285 23 Markaryd, Sweden
CHECKS
According to AVCP System 3
European standard EN 13240:2001 / A2:2004
Test institute Rein-Ruhr Feuerstätten Prüfstelle, NB 1625,
has checked declared performance and issued test report no. RRF-40 12 3071
PERFORMANCE DECLARATION
No. C35-CPR-130618-SE-1
DECLARED PERFORMANCE
Essential characteristics Performance Harmonised technical
specification
Reaction to fire A1 WT
Minimum distance to combustible material 100 mm to rear
415 mm to side
Other safety distances according to
the installation instructions
Risk of falling embers Approved
Emissions from combustion CO 0.05%
NOx 106 mg/m3
OGC 53 mg/m3
PM 27 mg/m3
Surface temperatures Approved
Cleaning options Approved
Mechanical durability Approved
Emissions of hazardous substances Approved
Nominal output 5 kW
Efficiency 80%
Flue gas temperature in connector at nominal
output
300°C
EN 13240:2001 / A2:2004
The undersigned is responsible for the manufacture and conformity with the declared performance.
Niklas Gunnarsson, Business area manager NIBE STOVES
Markaryd, 1st July 2013

67
GB
List of Contents
Technical details 68
Installation distance to walls and ceiling 69
Supply of combustion air 70
Connection to chimney 72
Installation of surround 74
A warm welcome to Contura.
A warm welcome to the Contura family. We hope you
will get a great deal of pleasure from your new stove.
As a new owner of a Contura stove, you have secured
a product with timeless design and long service life.
Contura also has a combustion process that is both
environmentally friendly and efficient, for the best heat
production.
Read through these installation instructions carefully
before installation. Read how to best light your stove
in the lighting instructions.
NOTE:
Report the installation of a stove to your
local authority.
The owner of the house is personally responsible
for ensuring compliance with the mandatory safety
requirements and must have the installation approved
by a qualified inspector. Your local chimney sweep must
also be informed of the installation, as this will affect the
routines for regular chimney-sweeping services.
WARNING!
The stove becomes very hot
During operation, certain surfaces of the stove become
very hot and can cause burn injuries if touched. Also,
take heed of the strong heat radiated through the door
glass. Placing flammable material closer than the safe
distance indicated may cause a fire. Smoulder combustion
can cause quick gas ignition with the risk of damage to
property and personal injury.
CONTENTS

Eldstadsbeklädnad
Rosterreglage
Asklåda
Förbränningsluftsreglage
Brasbegränsare
68
GB
Effect 3-7 kW
Nominal effect 5 kW
Efficiency 80 %
Model C35
Weight (kg) 140
Width (mm) 550
Depth (mm) 430
Height (mm) 1600
Heat retaining blocks (kg) 70
Installation by authorised
technician
This manual contains instructions on
how the stoves must be assembled and
installed. To ensure the function and
safety of the stove, we recommend that
the installation be carried out by an
authorised technician. Contact one of
our dealers who can recommend suitable
fitters.
Building permission
Before installing a stove or erecting a
chimney, it is necessary for you to make
an application for building permission
to your local authority. Ask your local
authority for advice regarding building
regulations and the application.
Structural support
Check that the wood joists are strong
enough to bear the weight of the stove
and chimney. The stove and chimney can
usually be placed on a normal wooden
joist in a single occupancy house, if the
total weight does not exceed 400 kg.
Hearth plate
Due to the risk of embers falling out, a
flammable floor must be protected by
a hearth plate. It must extend 300 mm
in front of the stove and 100 mm on
each side of the stove, or have a 200 mm
extension on each side of the opening.
The hearth plate can consist of natural
stone, concrete, metal plate or glass.
A painted metal or glass hearth plate
is available as an accessory for these
models.
Important to remember!Technical details
Type approved in accordance with:
European standard EN-13240
Swedish type approval,
P-marking cert. no. 0112/07
Norwegian standard NS 3059,
SINTEF 110-0275
German standard DIN Plus,
RRF-40 09 1955
FACTS
Rating plate
Fire bars
Hearth cladding
Grate control
Combustion air control
Ash-pan

C 35
69
GB
Installation distance to walls and ceiling
*To prevent discolouration of painted fire walls, we recommend the same side distance as to combustible walls.
INSTALLATION DISTANCES
550
1600
min 2300
106
221
Air inlet Ø64
Combustible roof
430
430
1050 1140
167
120 Hole in foot plate Ø120
368
150
729
781
Combustible wall
267
100
415
435
435
690
Combustible wall
Permitted area for
combustible parts
of the building
268
50
629
900
900
640
Fire-retardant wall of
brick or concrete
217
50
1100
700
50*
325*
Fire-retardant wall of
brick or concrete
The minimum distance in front of
the stove opening to combustible
parts of the building or interior
decoration must be at least 1 m.
The dimension diagrams only
show the minimum permitted
installation distances for the
stove. When connecting to a steel
flue, also note the safety distance
requirements of the flue. The
safety distance between an un-
insulated flue and a combustible
part of the building should be at
least 300 mm.

HK HK
40 mm
HK
40 mm
HK
40 mm
70
GB
Combustion air can be provided directly via a duct from outside,
or indirectly via a vent in the outer wall of the room where the
stove is placed. The amount of combustion air that is used for
combustion is approx. 20 m3/h.
Outside air can be connected through the floor plate or at two
different heights through the two panels in the back of the stove.
Tap out the knockout using a hammer. The air duct connector on
the stove has an external diameter of Ø64 mm.
In hot areas, the duct has to be insulated with 30 mm mineral wool
covered with a moisture barrier (plastic). It is important that the
lead-in, between the pipe and the wall (or floor), is sealed using
jointing compound. When duct routing for further than 1 m, the
pipe diameter must be increased to 100 mm and a correspondingly
larger wall vent must be selected.
A 1 m length of condensation-insulated ducting for combustion air
is available as an accessory.
SUPPLY AIR/ACCESSORY
Supply of combustion air

71
GB
Self-closing door
The stove is equipped with a spring to close the
door automatically. The spring is situated above
the heat deflector. The closing force of the hatch
can be adjusted by moving the spring between the
three notches on the lever. The angle of the stove
also affects the closing force of the spring.
If the spring force seems weak, despite
the spring being mounted at the end of
the lever, the angle of the stove should
be checked. Adjust with adjustable feet if
necessary.
SUPPLY AIR/ACCESSORY

Ø ca 180 mm
Ø ca 180 mm
!
1
4
2
5
3
6
72
GB
Rear connection to a masonry chimney
The back panel must be installed before the stove is connected at
the rear.
Connection to chimney
Make sure that the connector
gasket does not come loose when
the connection pipe is placed on the
sleeve. If further sealing material is
required, heat-resistant sealant may
be used.
• The stove meets the requirements for connecting to chimneys
dimensioned for flue gas temperatures of 350°C.
• The external diameter of the connection sleeve is 150 mm.
• The stove requires a draft in the chimney of at least –12
Pa. The draft is affected both by the length and area of
the chimney, and by how well sealed it is. The minimum
recommended chimney length is 3.5 m and suitable cross-
sectional area is 150-200 cm² (140-160 mm in diameter).
• A flue with sharp bends and horizontal routing reduces the
draught in the chimney. The maximum horizontal flue is 1 m,
on the condition that the vertical flue length is at least 5 m.
• It must be possible to sweep the full length of the flue and the
soot doors must be easily accessible.
• Carefully check that the chimney is sealed and that there is no
leakage around soot doors and flue connections.
CHIMNEY
In the bag with these installation instructions
are two wing screws for the cover.

73
GB
Top connection to the chimney
The hot air grille must be installed before the chimney is
connected to the top.
Connection to chimney
Sweeping
When sweeping, the smoke baffle must be removed; on the
Contura 30 series this can be done by lifting the smoke baffle
and removing the side piece. Lift the smoke baffle out and
remove the remaining sections. Handle the parts with care.
CHIMNEY

1
3
4
2
74
GB
Installation of surround
INSTALLATION

10
10
VANADIUM
No. 7
CHROME
5
7
6
75
GB
INSTALLATION

!
9
8
76
GB
INSTALLATION
Clean the inner and outer
side glass before further
installation.
Heat retaining
blocks (Option)

10
11 12
77
GB
INSTALLATION
Final inspection of the installation
It is extremely important that the installation is inspected by an authorised chimney sweep before
the stove is used. Also read the ”Lighting instructions”, before lighting for the first time.
Heat retaining
blocks (Option)

811183 IAV SE-EX C35-4
2015-10-01
Contura reserves the right to change dimensions and
procedures described in these instructions at any time without
special notice. The current edition can be downloaded from
www.contura.eu
NIBE AB · Box 134 · 285 23 Markaryd · Sweden
www.contura.eu
