Contura C i5 User manual

150 mm
125 mm
150 mm
500 mm500 mm
850 mm
www.contura.eu
811188 Kompletterande IAV Ci5 GB - 6
2018-11-26
Additional
installation instruction
When installing Ci5 and Ci6 in UK
Hearth dimensions
The appliance must stand on a constructional hearth which meet
the building regulations and has minimum dimension in front of
the appliance as shown in the diagram beside. Always check that
the building has enough bearing capacity for the hearth, stove and
chimney. The stove can be loaded with maximum 100 kg of chimney.

Flue collar
Remove the internal parts according to
installation instruction. Replace standard
flue collar with collar adapted for UK.
1
2

If the insert is connected
backwards the lid can be used
to cover the hole on the top.
Ci5 only
1
2

Smoke control area
In smoke control areas it is mandatory to stop
the damper from closing completely. In other
areas it´s optional.
1 2
43
