Contura C 590T User manual

C 590T
www.contura.eu
Installation
instruction

66
GB
CERTIFICATE
PRODUCT
Product type Stove lit with solid biofuels
Type designation Contura 590T
Manufacturing number See rating plate on the stove
Intended area of use Heating of rooms in residential buildings
Fuel Wood
MANUFACTURER
Name NIBE AB / Contura
Address Box 134, Skulptörvägen 10
SE-285 23 Markaryd, Sweden
CHECKS
According to AVCP System 3
European standard EN 13240:2001 / A2:2004
Test institute Rein-Ruhr Feuerstätten Prüfstelle, NB 1625,
has checked declared performance and issued test report no. RRF-40 09 2088
PERFORMANCE DECLARATION
No. C590T-CPR-130601-SE-1
DECLARED PERFORMANCE
Essential characteristics Performance Harmonised technical
specification
Reaction to fire A1 WT
Minimum distance to combustible material 100 mm to rear
480 mm to side
Other safety distances according to
the installation instructions
Risk of falling embers Approved
Emissions from combustion CO 0.06%
NOx 112 mg/m3
OGC 58 mg/m3
PM 26 mg/m3
Surface temperatures Approved
Cleaning options Approved
Mechanical durability Approved
Emissions of hazardous substances Approved
Nominal output 5 kW
Efficiency 79%
Flue gas temperature in connector at nominal
output
310°C
EN 13240:2001 / A2:2004
The undersigned is responsible for the manufacture and conformity with the declared performance.
Niklas Gunnarsson, Business area manager NIBE STOVES
Markaryd, 1st July 2013

67
GB
List of Contents
Technical details 68
Removing the loose parts 68
Connection to chimney 70
Supply of combustion air 71
Installation distances 72
Assembly 73
Installing the soapstone 76
Installing the lower cover 79
A warm welcome to Contura
A warm welcome to the Contura family. We hope you
will get a great deal of pleasure from your new stove.
As a new owner of a Contura stove, you have secured
a product with timeless design and long service life.
Contura also has a combustion process that is both
environmentally friendly and efficient, for the best heat
production.
Read through these installation instructions carefully
before installation. Read how to best light your stove
in the lighting instructions.
The stove becomes very hot
During operation, certain surfaces of the stove become
very hot and can cause burn injury if touched. Also, take
heed of the strong heat radiated through the door glass.
Placing flammable material closer than the safe distance
indicated may cause a fire. Smoulder combustion can cause
quick gas ignition with the risk of damage to property and
personal injury.
NOTE: WARNING!
Report the installation of a stove to your
local authority.
The owner of the house is personally responsible
for ensuring compliance with the mandatory safety
requirements and must have the installation approved by
a qualified inspector. Your local chimney sweep must also
be informed about the installation as this will affect the
routines for regular chimney-sweeping services.
CONTENTS

1
2
4
3
68
GB
FACTS
Effect 3-7kW
Nominal effect 5 kW
Efficiency up to 79%
Model 590T
Height (mm) 1543
Width (mm) 536
Depth (mm) 458
Weight (kg) 230
Type approved in accordance with:
European standard EN-13240
Swedish environmental and quality marking,
P-marking cert. no. 220309
Norwegian standard NS 3059, SINTEF 043-140
German standard DIN, 18.891, RO-91 03 529
Danish standard DS/EN 13240 Plus,
id no. 598
Removing the loose
parts
If the insert needs to be put down
to be moved, loose components
should be removed. When the stove is
installed reinstall the components in
reverse order.
1 Fire bars
2 Grate disc
3 Heat deflector
4 Hearth cladding (Vermiculite).
Installation by authorised
technician
This manual contains instructions about
how the stoves must be assembled and
installed. To ensure the function and safety
of the stove, we recommend that the
installation is carried out by an authorised
technician. Contact one of our dealers who
can recommend suitable fitters.
Building permission
These main insructions may give guidance
which would contravene national building
regulations. Please refer to supplementary
instructions or ask your local authority for
advice regarding building regulations.
Before installing a stove or erecting a
chimney it is necessary for you to make
a building application permission to your
local authority.
Structural support
Check that the wood joists are strong
enough to bear the weight of the stove and
chimney. The stove and chimney can usually
be placed on a normal wooden joist in a
single occupancy house, if the total weight
does not exceed 400 kg.
Floor plate
Due to the risk of falling embers, a
combustible floor must be protected by a
hearth plate which covers at least 300 mm
to the front and 100 mm along each side.
The hearth plate can consist of natural
stone, concrete, metal or glass. A painted
metal or glass hearth plate is available as
an accessory for these models.
Important to remember!
Technical details

1
2
4
3
69
GB
REMOVAL
How to remove the hearth surround (Vermiculite)
Handle the vermiculite with care. Lift the smoke baffle with one hand whilst removing
the sides pieces. Reinstall in reverse order
How to remove the heat deflector

Ø
ca 180 mm
Ø
ca 180 mm
LEK
!
21
5 6
3
4
70
GB
CHIMNEY
Connection to chimney
Rear connection to a masonry chimney
Top connection to the chimney
Make sure that the connector
gasket does not work loose when
the connection pipe is placed
on the connector. If further
sealing material is required, heat-
resistant sealant may be used.
The back panel must be installed on the stove before the stove is
connected at the rear.
The hot air grille must be installed before chimney
top connection.
• The stove meets the requirements for connecting to chimneys
dimensioned for 350°C flue gas temperature.
• The external diameter of the connection sleeve is 150 mm.
• The stove requires a draft in the chimney of at least –12 Pa. The
draft is affected both by the length and area of the chimney, and
by how well sealed it is. The minimum recommended chimney
length is 3.5 m and suitable cross sectional area is 150-200 cm²
(140-160 mm in diameter).
• A flue with sharp bends and horizontal routing reduces the
draught in the chimney. The maximum horizontal flue is 1 m, on the
condition that the vertical flue length is at least 5 m.
• It must be possible to sweep the full length of the flue and the
soot doors must be easily accessible.
• Carefully check that the chimney is sealed and that there is no
leakage around soot doors and flue connections.
In the bag with these installation instructions
are two wing screws for the cover.

HK
HK
40 mm
HK
40 mm
HK
40 mm
!
71
GB
SUPPLY AIR/ACCESSORY
Supply of combustion air
When a stove is installed in a room, the demand for air supply to the
room increases. Air can be provided indirectly via a vent in the outer
wall or via a duct from the outside that is connected to the connector
on the underneath of the stove. The amount of air needed for
combustion is approx. 25m3/h.
The connector has an external diameter of 67 mm. When duct
routing further than 1 m the pipe diameter must be increased to 100
mm and a correspondingly larger wall vent must be selected.
In hot areas the duct should be insulated with 30 mm mineral wool
covered with a moisture inhibitor (plastic). It is important that the
lead-in between the pipe and the wall (or floor) is sealed using
jointing compound.
A 1 m length of condensation-insulated ducting for combustion air is
available as an accessory.
Through the external wall
Indirect air supply through the external wall
Through floor and foundation slab
Through floor and wall-and-cavity foundation
C 590T
In the back and floor plates there are knockouts
that must be removed to insert pipes or for air
supply if the stove is equipped with a lower hatch
and/or fan (accessory).
Installation variants
Leave a 40 mm gap between the condensation
insulation and the bottom of the stove.

!
C 590T
72
GB
* To prevent discolouration of painted non-flammable walls we recommend that the same side distance as to combustible walls is used.
** If the stove is placed on a hearth plate made of glass for example (accessory), the height from the floor is affected by a distance corresponding to the thickness of the hearth plate. Also applies to
separate glass hearth plates (accessory).
The minimum distance in front of
the stove opening to combustible
parts of the building or interior
decoration must be at least 1 m.
When top connecting a steel flue,
please refer to the particular
manufacturer's installation
instructions. Observe the safety
distance to combustible material
that the steel flue requires.
Installation distances
WHEN INSTALLING TURNTABLE (OPTION) the
following installation distances do not apply.
See the separate installation instructions for
turntable.
A = height from floor to chimney
connection upwards
B = height from floor to c/c chimney
connection rear
C = height from floor to air inlet
D = height from floor to lower edge
of hatch
A separate glass hearth
plate (accessory)
increases the connection
height to the chimney
by 10 mm. The spacers
supplied with the hearth
plate are installed on the
stove before connection.
INSTALLATION DISTANCES
Permitted
area for
combustible
parts of the
building
1544
536
Min 2300
Combustible roof
Air inlet Ø67 97
31
D 575
C 589
B 1127
A 1220
458
139
Air inlet Ø67
310
80
615
760
Combustible wall
320*
50*
190
50
700
1100
Fire-retardant wall of
brick or concrete
280
50
585
690
800
800
Fire-retardant wall of
brick or concrete
750
480
240
100
100
200
300
400
60
160
260
360
Combustible wall
**
**

10
10
VANADIUM
No. 7
CHROME
10
10
CHROME
2
1
3
73
GB
Installing C 590T
ASSEMBLY

10
10
CHROME
10
10
CHROME
10
10
CHROME
4
6
5
7
74
GB
ASSEMBLY

8
9
75
GB
ASSEMBLY

603224
603225
603222
603223
603220
603221
603226
13
13
VANADIUM
No. 7
CHROME
1 2
76
GB
Installing the soapstone
ASSEMBLY
Place the insert on the hearth plate and check the installation
distance. Connection to the chimney from the rear of the stove body
is carried out prior to installing the soapstone. When the connecting
the chimney to the top of the stove body the soapstone surround
must be installed first. Remember to install the hot air grille before
top connecting.

3
5
4
6
77
GB
ASSEMBLY

!
7
78
GB
ASSEMBLY
It is extremely important that the installation is inspected by an authorised chimney sweep before
the stove is used. Also read the ”Lighting instructions”, before lighting for the first time.
Final inspection of the installation
Position the supplied
rating plate as
illustrated.

1
12
2
1
2
2
1
34
79
GB
Installing the lower cover
ASSEMBLY

811110 IAV SE-EX C590T - 5
2014-04-16
1
2
4
3
80
GB
!
!
ASSEMBLY
Install grey or black damper knob as illustrated. For top
connected stoves the knockout must be knocked out.
Then install the stove top, damper and finally
the hot air grille.
Stack the stones in the top frame.
A damper is supplied with the stones. Close the damper after
the last addition of wood to obtain maximum cooling off time.
It is important to open the damper at next lighting. Otherwise
the convection air is prevented from cooling the insert during
the firing.
Installing the stone magazine
With top connected chimneys, the
stone magazine and the damper must
be installed before the chimney.
Stoves with fans must not be
equipped with a convection damper!
Contura reserves the right to change dimensions and
procedures described in these instructions at any time without
special notice. The current edition can be downloaded from
www.contura.eu
NIBE AB · Box 134 · 285 23 Markaryd · Sweden
www.contura.eu
