Convair CTF01 Setup guide

OWNER’S INSTRUCTION MANUAL
P O R T A B L E T O W E R F A N
MODEL CTF01

Waste electrical products must not be disposed of with household waste. This
product should be taken to your local recycling centre for safe treatment.
As the policy of this company is one of continuous improvement, all specifications are subject to change without notice.

Make sure that the fan never comes into
contact with water.
Never turn the fan on if the lead is damaged
or if the fan’s casing is obviously damaged.
In order to avoid a hazard, the power cord
must be replaced by a licensed electrician or
service agent.
Do not pull the fan along by the power cord.
Always uncoil the power cord completely.
Always turn the fan off and unplug from the
power socket when not in use.
GENERAL SAFETY
Please read these instructions before using
the fan and keep for future reference.
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless
they have been given supervision or
instruction in using the appliance by a
person responsible for their safety.
Children should be supervised to ensure that
they do not play with the appliance. Do not
poke anything through the ventilating slits.
Assemble the fan completely before use.
Always use the fan in an upright position.
Stand it on a firm, solid, horizontal base (not
on thick pile carpets).
Clean these openings at regular intervals to
prevent airflow reduction (refer Maintenance
section).
For indoor use only. Do not use this fan
outdoors, or on wet surfaces. Do not use the
fan near flammable areas or substances.
ELECTRICAL SAFETY
Before connecting your electrical power
cord to a power outlet, check that the fan
voltage is the same as your power
supply. The fan voltage will be stated on
the rating label.
1
1
SAFETY

COMPONENT LIST
1 Control Knob
2 Air outlet
3 Front Base
4 Rear Base
5 Base Screw x3
6 Power Plug & Cord
1
2
ASSEMBLY
Unpack the fan and check that you have all
of the components.
Remove the screws from the base.
Assemble the front and rear base stand onto
the fan, pulling the cable through the central
hole between them.
Screw the base stand into position and feed
the cord through the retention slots (Fig 2).
ASSEMBLY
2

3
OPERATION - MAINTENANCE
OPERATION
Insert the plug into the power outlet.
Select the desired fan speed by rotating the
control knob to the desired selection. Your
selection is indicated by the “ ” on the
control knob.
Your fan has 3 speeds and can oscillate from
side to side in a 60° arc.
Refer to Fig 3 and the selection chart below :-
= Off position
= Fan Speed Low
= Fan Speed Medium
= Fan Speed High
= Oscillation On ,Fan Speed Low
= Oscillation On ,Fan Speed Medium
= Oscillation On ,Fan Speed High
To turn the fan “OFF”, turn the knob to one of
the 2 “OFF” positions.
=
MAINTENANCE
To maximise the efficiency of the fan, clean
the inlet and outlet grilles regularly.
• Unplug the fan from the mains power
supply before cleaning.
• Use a soft, damp cloth to wipe the
outside. Never use thinners or other strong
chemicals on the fan surfaces.
• Use a vacuum cleaner to remove dirt and
dust from the inlet and outlet grilles.
• Ensure the fan is dry before plugging
back into the mains power supply.
Unit Controls 3

NOTES
4

Service
Australia 1-300-650-399
seeleyinternational.com
It is the policy of Seeley International to introduce continual
product improvement. Accordingly, specifications are
subject to change without notice. Please consult with your
dealer to confirm the specifications of the model selected.
00136401-B seeleyinternational.com AU 1112
