Converters.TV Component to Component Matrix - 4 in : 2 out User manual

Component to Component Matrix
4 in : 2 out ID# 510
Operation Manual

Introduction
Component to Component Matrix - 4 in : 2 out is a high performance Component +
L/R Audio Matrix with remote control. It offers you maximum convenience in DTV
audio/video signal distribution when you have multiple sources and displays to
connect together. Each of the four DTV audio/video sources can be directed to
any one of the two outputs, so two displays can show 2 identical or 2 different
sources at the same time. Component to Component Matrix - 4 in : 2 out provides a
maximum of 8 possible connection scenarios between sources and displays.
Features
1. Provides 4 by 2 matrix input/output of Component (YPbPr/YCbCr)
video and L/R audio signal.
2. Buffered video and audio output.
3. Input source LED indicators on each output select.
4. Ideal for home theater integration, conference room and retail
stores.
5. Supports high resolution input/output: DTV: 480i, 576i, 480p, 576p,
1080i, and 1080p
6. Supports analog stereo L/R audio input and output.
7. IR remote control.
8. RS-232 control.
Operating Functions
and Controls
Front Panel
1. Remote control sensor.
2. Power Switch & LED Indic tor:
The LED will illuminate when the power is turned on.
3. Input Select/Indic tors for Output A:
Press the "OUT A" button repeatedly to switch to your desired
source. One of the four LEDs will illuminate to indicate which input
source is being selected, and routed to the display.
4. Input Select/Indic tors for Output B:
Press the "OUT B" button repeatedly to switch to your desired source.
One of the four LEDs will illuminate to indicate which input source is
being selected, and routed to the display.

Rear Panel
1.RS-232 Communic tion Port:
Connect to the COM port of your PC for the distant control over RS-232
channel.
2. Component nd L/R Audio OUTPUT Ports A nd B:
Connect each set of Component (3 RCA) and Audio (2 RCA) to the
input of your DTV displays.
3. Component nd L/R Audio INPUT Ports 1, 2, 3 nd 4:
Connect each set of Component (3 RCA) and Audio (2 RCA) to the
output of your source equipments such as DVD player or set-top-box.
4. Power:
Plug the 12VDC power supply into the unit and connect the adapter to
AC wall outlet.
Remote Control
1. Power: Press the button to turn
on/off the unit.
2. Input Select for
Component/Audio OUT A:
Press 1, 2, 3 or 4 to select the
desired input source for
Component/Audio OUT A.
3. Input Select for
Component/Audio OUT B:
Press 1, 2, 3 or 4 to select the
desired input source for
Component/Audio OUT B.
4. Void buttons (No function.)

RS-232 Protocol
Pin Definition
Commands
ID #510

pecifications
•Input Ports: Component (YPbPr/YCbCr)
+ L/R Audio x 4 sets
•Output Ports: Component (YPbPr/YCbCr)
+ L/R Audio x 2 sets
•Power: 12V DC power supply
•Dimensions: 436 (W) x 120 (D) x 44 ( )mm
•Weight: 1.6 Kgs
Support Resolution
Connection and
Installation
