Cook & Beals Spin-Float Honey-Wax Separator User manual

Page1
Cook & Beals, Inc.
PO Box 220
Loup City, NE 68853
308-745-0154
[email protected]
Spin-Float Honey-Wax Separator
U.S. Patent #: 3217979
Canadian Patent #: 723027
Instructions for replacing separator belts

Page2
Instructions for replacing separator belts
1. Loosen cutter belt tightener (see 1A).
2. Loosen drum belt tightener bolts 1 & 2 (see 1A-C & 2A-C).
3. Loosen all 4 motor belt tightener bolts (see 1A).
4. Remove worn belts:
a. Motor belt #6941 (see 1A)
b. Drum belt # 6944 (see 2A-B)
c. Cutter belt #6937 (see 3A-B)
5. Install new belts:
a. Cutter belt #6937 (see 3A-B)
b. Drum belt #6944 (see 2A-B)
c. Motor belt #6941 (see 1A)
6. Drum belt tightener bolt #1 should be slightly more than finger tight
(see 1A-C & 3A-B).
7. Tension drum belt by tightening drum belt tightener bolt #2 (see 1A-C
& 3A-B).
8. Once the drum belt is tight, tighten drum belt tightener bolt #1 (see
2A-C).
9. Tighten the cutter belt with the cutter belt tightener rod (see 1A & 2A-
C).
10. Tighten the motor belt by pushing the motor outward with the 4 motor
belt tightener bolts. The motor plate should be equal measurements
on all 4 corners when measured from the separator base plate (see
1A).
DISCLAIMER: These photos may not apply to some older separators.
Please call [phone] CST if you need further assistance.

Page3
Cutter Belt Tightener Rod
Drum Belt Tightener Bolt #2
Motor Belt #6941
Cutter Belt Shield
Motor Belt Tightener Bolts (4)
Separator Base Plate
Drum Belt Tightener Bolt #2
Cutter Belt Shield
Drum Belt Tightener Bolt #2
Cutter Belt Shield
1A
1B
1C

Page4
Tachometer Sensor
Cutter Belt Tightener Rod
Drum Belt #6944
Tachometer Sending Disc
Drum Belt Tightener Bolt #1
Tachometer Sensor
Cutter Belt Tightener Rod
Drum Belt #6944
Tachometer Sending Disc
Drum Belt Tightener Bolt #1
Cutter Belt Tightener Rod
Drum Belt Tightener Bolt #1
2A
2B
2C

Page5
Drum Belt Tightener Bolt #2
Cutter Belt #6937
Motor Belt #6941
Drum Belt Tightener Bolt #2
Cutter Belt #6937
Motor Belt #6941
3A
3B
