Cook Tre User manual

1TRE IO&M B51144-002

TRE

Extruded Relief or Intake Ventilator

INSTALLATION, OPERATION AND MAINTENANCE MANUAL

Receiving and Inspection

Immediately upon receipt of an TRE unit, carefully in-

spect it for damage and shortage.

• Check dampers (if supplied) for free operation of all

moving parts.

• Record on the Delivery Receipt any visible sign of

damage.

Handling

Lift the unit by the base. Never lift by the tiers.

Storage

If the fan is stored for any length of time prior to installa-

tion, store it in its original shipping crate and protect it from

dust, debris and the weather.

TRE

The attachment of roof mounted fans to the roof curb as

well as the attachment of roof curbs to the building struc-

ture must exceed the structural requirements based on the

environmental loading derived from the applicable building

code for the site. The local code ofcial may require varia-

tions from the recognized code based on local data. The

licensed engineer of record will be responsible for prescrib-

ing the correct attachment based on construction materials,

code requirements and environmental effects specic to the

installation.

Failure to follow these instructions could result in death or

serious injury.

Installation

Damper and Curb Installation

Curb dimensions are calculated by adding 4” to the

throat width and throat length.

The optional backdraft damper is 1-1/2” larger than the

throat length and throat width. The damper is to be mount-

ed in the throat of the TRE.

Optional lters are shipped installed in the unit from the

factory.

Filters

Filter inspection and cleaning intervals can vary from

once a week to twice per year depending on contaminant

present and acceptable pressure drops across the lter.

Under most conditions lters may be cleaned with hot wa-

ter and a mild soap solution (such as dish washing liquid)

or steam. Some caustic cleaners will damage the lter. If

in doubt, please consult the factory for a compatibility list.

High pressure spray washers should be limited to

2,000psi operating pressure. Every attempt should be

made to remove the contaminants from the lter in a

“back-wash” ow (note airow arrow on the lter frame).

Once the lter is dry, it may be returned to the appropri-

ate lter racks in the same orientation (airow direction) as

they were removed.

Maintenance

Establish a denite schedule per the manufacturers rec-

ommendation for inspecting any accessory lters or damp-

er units that may have been installed with the ventilator.

Inspect the ventilator yearly for any debris that may ob-

struct airow. Check exterior surfaces for dust and grease.

To assure proper operation, remove any dust and grease

from the TRE surfaces.

The TRE top cap may be removed for roof top access

to the throat of the ventilator and access to the optional

lters. Filters may be removed for cleaning and mainte-

nance by sliding them up and out of the unit. Be sure to

reinstall all top cap fasteners upon reassembly.

This publication contains the installation, operation

and maintenance instructions for standard units of the

TRE - Extruded Relief or Intake Ventilator.

Carefully read this publication and any

supplemental documents prior to any

installation or maintenance procedure.

Loren Cook catalog, Gravity Ventilation, provides addi-

tional information describing the equipment, unit perfor-

mance, available accessories and specication data.

For additional safety information, refer to AMCA Publi-

cation 410-96, Safety Practices for Users and Installers of

Industrial and Commercial Fans.

All of the publications listed above can be obtained from:

• lorencook.com

• [email protected]

• 417-869-6474 ext. 166

For information and instructions on special equipment,

contact Loren Cook Company at 417-869-6474.

2TRE IO&M B51144-002

Tier Extrusion

5/16” Nut & Bolt

(between each tier

)

1/8” Aluminum plate

er Extrusion

1/8” Aluminum Plate

Note: Center tier dividers can

vary in qty. Depending on size

of unit, tier material comes in

192” long sections

5/16” Nut & Bolt

(between each tier)

“Detail” Top View

Topcaps can have multiple sec

tions depending on unit length

(some may be left assembled)

Bolt hood together

at each section

Hood is bolted at

corners and braces

Braces on tiers

are welded on

Top, bottom & cross braces

are bolted together

TRE Knockdown Installation Instructions

TRE Parts List

Part No. Description

1Topc ap

2Base

3Corner Post

4Tier

March 2017

Corporate Ofces: 2015 E. Dale St. Springeld, MO 65803

Phone 417-869-6474 | Fax 417-862-3820 | lorencook.com

Limited Warranty

Loren Cook Company warrants that your Loren Cook fan was manufactured free of defects in materials and workmanship, to the extent stated herein.

For a period of ve (5) years after date of shipment, we will replace any parts found to be defective without charge, except for shipping costs which will be

paid by you. This warranty is granted only to the original purchaser placing the fan in service. This warranty is void if the fan or any part thereof has been

altered or modied from its original design or has been abused, misused, damaged or is in worn condition or if the fan has been used other than for the

uses described in the company manual. This warranty does not cover defects resulting from normal wear and tear. To make a warranty claim, notify Loren

Cook Company, General Ofces, 2015 East Dale Street, Springeld, Missouri 65803-4637, explaining in writing, in detail, your complaint and referring to

the specic model and serial numbers of your fan. Upon receipt by Loren Cook Company of your written complaint, you will be notied, within thirty (30)

days of our receipt of your complaint, in writing, as to the manner in which your claim will be handled. If you are entitled to warranty relief, a warranty ad-

justment will be completed within sixty (60) business days of the receipt of your written complaint by Loren Cook Company. This warranty gives only the
