Cooke & Lewis HINDL60CL User manual

60cm Induction Hob
HINDL60CL - Version: 01
GB IE 60cm Induction Hob - Barcode: 5052931258666
WARNING: Read the instructions before using the appliance.
HINDL60CL-C&L-A5-GB-IM-07.indd 1 10/9/13 3:37 PM

[01] x 1 [02] x 4
HINDL60CL 60cm Induction Hob
[03] x 4
1 : 1
HINDL60CL-C&L-A5-GB-IM-07.indd 2 10/9/13 3:37 PM

3
Let's
get started...
These instructions are for your safety. Please read through them
thoroughly before use and retain them for future reference.
Getting started… 04
Your product 04
Before you start 04
Safety 05
In more detail… 09
Operation 09
Care and maintenance 20
Troubleshooting 22
Recycling and disposal 23
Technical specications 23
Wiring 24
Technical and legal information 25
Guarantee 26
CE Declaration of conformity 28
Appendix...
29
Installation
GB
IE
HINDL60CL-C&L-A5-GB-IM-07.indd 3 10/9/13 3:37 PM

4
HINDL60CL 60cm Induction Hob
Getting started...
GB
IE
Your product
Things to check before you start
To avoid the risks that are always present when you use an electrical
appliance it is important that this appliance is installed correctly and that
you read the safety instructions carefully to avoid misuse and hazards.
Please keep this instruction booklet for future reference and pass it on to
any future owners. After unpacking the appliance please check that it is
not damaged. If in doubt, do not use the appliance but contact Customer
Services on 0844 800 1128 (UK) and 01 4475261 (Ireland).
Check the package and make sure you have all of the parts listed.
Decide on the appropriate location for your product.
If this product contains glass please take care when tting or handling to
prevent personal injury or damage to the product.
The specications plate is available on this appliance. This plate displays
all the necessary identication information for ordering replacement parts.
If you sell the appliance, give it away, or leave it behind when you move
house, make sure you also pass on this manual so that the new owner can
become familiar with the appliance and its safety warnings.
You will need
Your product
Before you start
Installation guide
located at the end of
the guidebook
HINDL60CL-C&L-A5-GB-IM-07.indd 4 10/9/13 3:37 PM

5
Getting started...
HINDL60CL 60cm Induction Hob GB
IE
Safety
These instructions are for your safety. Please
read through them thoroughly prior to
installation and retain them for future reference.
• All installation work must be carried
out by a competent person or qualied
electrician.
• This appliance must be installed correctly
by a suitably qualied person, strictly
following the manufacturer’s instructions.
This appliance complies with all current
European safety legislation, however, the
Manufacturer must emphasise that this
compliance does not prevent the surfaces of
the appliance from heating up during use and
remaining hot during its operation.
Accessible parts may become hot during
use. Young children should be kept away.
Care should be taken to avoid touching the
appliance.
The Manufacturer highly recommends that this
appliance be kept out of the reach of babies
and small children.
HINDL60CL-C&L-A5-GB-IM-07.indd 5 10/9/13 3:37 PM

6
HINDL60CL 60cm Induction Hob
Getting started...
GB
IE
Safety
This appliance can be used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they
have been given supervision or instruction
concerning use of the appliance in a safe way
and understand the hazards involved. Children
shall not play with the appliance. Cleaning and
user maintenance shall not be made by children
unless they are older than 8 and supervised.
Keep the appliance and its cord out of reach of
children less than 8 years.
Means for isolating the appliance must be
incorporated in the xed wiring in accordance
with the current wiring regulations. An all-
pole disconnection switch having a contact
separation of at least 3 mm in all poles should
be connected in xed wiring.
Regularly check the power plug and power
cord for damage. If the supply cord is
damaged, it must be replaced by a special
cord or assembly available from the
manufacturer or its service agent.
Make sure that the power cord is not caught
under or in the appliance and avoid damage to
the power cable.
HINDL60CL-C&L-A5-GB-IM-07.indd 6 10/9/13 3:37 PM

7
Getting started...
HINDL60CL 60cm Induction Hob GB
IE
Safety
Do not allow the electric cables to touch the
hot parts of the appliance.
Do not install the appliance outdoors in a
damp place or in an area which may be prone
to water leaks such as under or near a sink
unit. In the event of a water leak allow the
machine to dry naturally.
Please dispose of the packing material carefully.
Do not use ammable sprays in close vicinity
to the appliance.
We also recommend that great care be taken
during use and cleaning. Read the cleaning and
maintenance sections for this appliance carefully.
A steam cleaner is not to be used.
The appliance is not intended to be operated
by means of external timer or separated
remote-control system.
The appliance is for domestic use only.
When a cooking zone has been on for a long
time, the surface remains hot for some time
afterwards so do not touch the metal surface.
Do not store detergents or ammable
materials beneath the hob.
Do not leave hot oils or fats unattended as
they may catch light.
HINDL60CL-C&L-A5-GB-IM-07.indd 7 10/9/13 3:37 PM

8
HINDL60CL 60cm Induction Hob
Getting started...
GB
IE
Safety
The Manufacturer declines all liability for
personal or material damage as a result of
misuse or incorrect installation of this appliance.
Warning! Unattended cooking on a hob with fat
or oil can be dangerous and may result in re.
Never try to extinguish a re with water, but
switch off the appliance and then cover ame
e.g. with a lid or a re blanket.
Warning! Risk of re! Do not store items on
the cooking surfaces.
After use, switch off the hob element by its
control. Do not rely on the pan detector.
The means for disconnection must be
incorporated in the xed wiring in accordance
with the wiring rules.
Caution! In order to avoid a hazard due to
inadvertent resetting of the thermal cutout, this
appliance must not be supplied through an
external switching device, such as a timer, or
connected to a circuit that is regularly switched
on and off by the utility.
Warning: If the surface of the hob is cracked,
disconnect from power supply of the appliance
to avoid any possibility of electric shocks.
Do not leave metal objects, such as knives,
forks, spoons and lids on the hob as they may
get hot.
HINDL60CL-C&L-A5-GB-IM-07.indd 8 10/9/13 3:37 PM

9
In more detail...
HINDL60CL 60cm Induction Hob GB
IE
Operation
Product functions
• The induction hob caters for all kind of cooking, with its electromagnetic
cooking zones and its electronic touch controls and multi-functions, making it
the ideal choice for the modern family.
• The induction hob is extremely user-friendly, durable and safe.
Working principle
Iron pot
Magnetic circuit
Ceramic glass plate
Induction coil
Induced currents
• The induction hob comprises a coil, a hotplate made of ferromagnetic material
and a control system. Electrical current generates a powerful magnetic
eld through the coil. This produces a large number of vortices that, in turn,
generate heat that is then transmitted through the cooking zone to the pan.
Special functions
Protection from over-heating
A sensor monitors the temperature in the cooking zones. When the temperature
exceeds a safe level, the cooking zone is automatically switched off.
Detection of small or non-magnetic items
When an unsuitably sized or non-magnetic pan (e.g. aluminium) or some other
small item (e.g. knife, fork, key) has been left on the hob, the hob switches
automatically to standby one minute later.
Residual heat indicator
When the hob has been operating for some time, there will be some residual heat.
The letter "H" appears to warn you that it is too hot to touch the surface.
HINDL60CL-C&L-A5-GB-IM-07.indd 9 10/9/13 3:37 PM

10
In more detail...
HINDL60CL 60cm Induction Hob
GB
IE
Operation
Special functions
Auto shutdown
Another safety feature of the induction hob is auto shutdown. This occurs
whenever you forget to switch off a cooking zone.
The default shutdown times are shown in the table below:
Power level The heating zone shutdown automatically after
1-3 8 hours
4-6 4 hours
7-9 2 hours
Function keys
Child lockBoost controlKeep warm
Power/Timer regulating key
Heating zone selection control
Pause key On/off keyFlexible control
Reference Description
Boost control
Power/Timer regulating key (decrease/increase)
Keep warm
Child lock
On/off key
Pause key
heating zone selection control
exible control
HINDL60CL-C&L-A5-GB-IM-07.indd 10 10/9/13 3:37 PM

11
In more detail...
HINDL60CL 60cm Induction Hob GB
IE
Operation
Preparation before use
• When the power is switched on, the buzzer will sound once and all the
indicators will switch on for one second and then switch off. The hob is now
in standby mode. Place the pan in the centre of the cooking zone.
Caution
When the ON/OFF key is pressed, the induction hob returns to
standby mode if no other operation is carried out within one minute.
Heating zone operation
When the ON/OFF key is pressed, all the indicators show " " or " " or
" ".
1. To adjust the power level select the zone rst. Now select the hotplate and
select the power level by sliding the key for the relevant hotplate.
2. The indicator initially displays "5".
3. Adjust up or down by sliding the key.
4. If you press the keys at the end of the control simultaneously, the
power setting returns to "0" and the entire cooking zone switches off.
5. See the table below for the power specic to each cooking zone.
The above may vary according to the size of the pan and the material from which
it is made.
Heating Zone Max. Power (W)
Left back 1800/3000
Right back 1800/3000
Right front 1800/3000
Left front 1800/3000
Free zone 3000/4000
Free zone 3000/4000
Left back
Left front
Right back
Right front
Free zone Free zone
HINDL60CL-C&L-A5-GB-IM-07.indd 11 10/9/13 3:37 PM

12
In more detail...
HINDL60CL 60cm Induction Hob
GB
IE
Operation
Using the boost function
Activate the boost function
1. Touch the heating zone selection control.
2. Touch the boost control , the zone indicator show “b” and the power
reach maximum power.
Cancel the boost function
1. Touch the heating zone selection control that you
wish to cancel the boost function.
2. a: Touch the boost control , then the cooking zone will revert to its
original setting.
b: Touch the slider control, then the cooking zone will revert to the level you
select.
• The function can work in all cooking zones.
• The cooking zone returns to its original setting after 5 minutes.
• As the boost function of 1st cooking zone is activated, the 2nd cooking zone
is limited under level 2 automatically and vice versa.
• If the original heat setting equals 0, it will return to 9 after 5 minutes.
HINDL60CL-C&L-A5-GB-IM-07.indd 12 10/9/13 3:37 PM

13
In more detail...
HINDL60CL 60cm Induction Hob GB
IE
Operation
Using the keep warm function
The product have 3 levels of keep warm function.
Activate the keep warm function
1. Touch the heating zone selection control.
2. Touch the keep warm control , the zone indicator show " " , this
means choosing the heating level of 42°C with 2L of water.
Touch the keep warm control again, the zone indicator show " " , this
means choosing the heating level of 74°C with 2L of water.
Touch the keep warm control for the third again, the zone indicator show
"" , this means choosing the heating level of 94°C with 2L of water.
Cancel the keep warm function
1. Touch the heating zone selection control that you wish to cancel the keep
warm function.
2. Touch the slider control, then the cooking zone will revert to the level you
select.
HINDL60CL-C&L-A5-GB-IM-07.indd 13 10/9/13 3:37 PM

14
In more detail...
HINDL60CL 60cm Induction Hob
GB
IE
Operation
Flexible area
• This area can be used as a single zone or as two different zones,
accordingly to the cooking needs anytime.
• Flexible area is made of two independent inductors that can be controlled
separately. When working as a single zone, a cookware is moved from one
zone to the other one within the exible area keeping the same power level
of the zone where the cookware originally was placed, and the part that is
not covered by cookware is automatically switched off.
Note!
Make sure to place the cookware centered on the single cooking zone.
In case of big pot, oval, rectangular and elongated pans make sure to
place the pans centered on the cooking zone covering both cross.
Examples of good pot placement and bad pot placement.
≥ 200mm
As big zone
1. To activate the exible area as a single big zone,
simply press the dedicated keys.
2. The power setting works as any other normal area.
3. If the pot is moved from the front to the rear part (or
viceversa),the exible area detects automatically
the new position, keeping the same power.
As two independent zones
To use the exible area as two different zones with different power settings, press
the dedicated keys.
HINDL60CL-C&L-A5-GB-IM-07.indd 14 10/9/13 3:37 PM

15
In more detail...
HINDL60CL 60cm Induction Hob GB
IE
Using the timer
You can use the timer in two different ways:
• You can use it as a minute minder. In this case, the timer will not turn any
cooking zone off when the set time is up.
• You can set it to turn cooking zones off after the set time is up.
• You can set the timer for up to 99 minutes.
Using the timer as a minute reminder
If you are not selecting any cooking zone
1. Make sure the cooktop is turned on.
Note: You can use the minute reminder even if you are not selecting any
cooking zone.
2. Touch timer control, the "10" will show in the timer
display where touched, and the "0" ashes.
3. Set the time by touching the slider control (e.g. 6).
4. Touch timer control again, the "1" will ash.
5. Set the time by touching the slider control (e.g. 9), now the timer you set is
96 minutes.
Operation
HINDL60CL-C&L-A5-GB-IM-07.indd 15 10/9/13 3:37 PM

16
In more detail...
HINDL60CL 60cm Induction Hob
GB
IE
Operation
Using the timer as a minute reminder
1. Set the time by touching the slider control (e.g. 9),
now the timer you set is 96 minutes.
6. Buzzer will beep for 30 seconds and the timer
indicator shows “00 “ when the setting time
nished.
Setting the timer to turn cooking zones off
If the timer is set on one zone:
2. Touch the heating zone selection control that you
want to set the timer for.
3. Touch timer control, the “10” will show in the timer
display, and the “0” ashes.
4. Set the time by touching the slider control (e.g. 6).
5. Touch timer control again, the “1” will ash.
HINDL60CL-C&L-A5-GB-IM-07.indd 16 10/9/13 3:37 PM

17
In more detail...
HINDL60CL 60cm Induction Hob GB
IE
Operation
Setting the timer to turn cooking zones off
5. Set the time by touching the slider control (e.g. 9), now the timer you set is
96 minutes.
6. When the time is set, it will begin to count down
immediately. The display will show the remaining
time and the timer indicator ash for 5 seconds.
Note: The red dot next to power level
indicator will illuminate indicating that zone
is selected.
7. When cooking timer expires, the corresponding
cooking zone will be switch off automatically.
Caution
Other cooking zone will keep operating if they are turned on previously.
If the timer is set on more than one zone:
1. When you set the time for several cooking zones simultaneously, decimal
dots of the relevant cooking zones are on. The minute display shows the
min. timer. The dot of the corresponding zone ashes.
2. Once the countdown timer expires, the corresponding zone will switch off.
Then it will show the new min. timer and the dot of corresponding zone will
ash.
• Touch the heating zone selection control, the corresponding timer will be
shown in the timer indicator.
HINDL60CL-C&L-A5-GB-IM-07.indd 17 10/9/13 3:37 PM

18
In more detail...
HINDL60CL 60cm Induction Hob
GB
IE
Operation
Using the pause control
1. When the cooking zones are running, touch the
control, all the displays will show " " and
stop heating. At this moment only and
control can be operated.
2. Touch again, the displays show the original
setting, and the cooking zones keep on heating.
Safety mode (Child lock)
To ensure the safety of children, the induction hob is tted with an interlock
device.
To lock:
3. Hold down the "Lock" ; the hob then switches to "Lock" mode.
4. The timer displays "Lo" and the rest of the keys are disabled except the "ON/
OFF" key.
Unlocking:
1. Hold down the "Lock" key for 2 seconds and the hob will return to normal
working mode.
HINDL60CL-C&L-A5-GB-IM-07.indd 18 10/9/13 3:37 PM

19
In more detail...
HINDL60CL 60cm Induction Hob GB
IE
Operation
Selection of heating appliances
Caution
The base of the pan must contain magnetic material. It must have a at
bottom with a diameter of over 12 cm.
Oil Frying Pan
Enamel cooking
utensil
Iron plate
Stainless steel pot Iron pan
You may have a number of different cooking vessels
This induction hob can identify a variety of cooking vessels, which you can test by
one of the following methods:
1. Place the pan on the cooking zone. If the corresponding cooking zone
displays a power level, then the vessel is suitable. If "U" ashes, then the pan
is not suitable.
2. Hold a magnet to the base of the pan. If the magnet is attracted to the pan, it
is suitable for use with the induction hob.
HINDL60CL-C&L-A5-GB-IM-07.indd 19 10/9/13 3:37 PM

20
In more detail...
HINDL60CL 60cm Induction Hob
GB
IE
Care and maintenance
Care and maintenance
OFF
Warning
Always switch off the electricity supply before
performing maintenance work. In the event of a fault,
contact an ofcial distributor or authorised dealer.
If the supply cord is damaged, it must be replaced by a special cord
or assembly available from the manufacturer or its service agent.
For domestic use only.
Never place the induction hob directly into water.
Never place an empty pan on the hob as this will cause an error
message to appear on the control panel.
When a cooking zone has been on for a long time, the surface
remains hot for some time afterwards so do not touch the ceramic
surface.
Occasionally check that nothing is obstructing the air inlet beneath
the induction hob.
If the surface of the hob is cracked, disconnect from power supply
the appliance to avoid any possibility of electric shocks.
Do not place rough or uneven vessels on the hob, as they could
damage the ceramic surface.
Avoid banging pots and pans down on the hob.
The ceramic surface is tough but not unbreakable.
Do not leave metal objects, such as knives, forks, spoons and lids
on the hob as they may get hot.
Do not store detergents or ammable materials beneath the hob.
HINDL60CL-C&L-A5-GB-IM-07.indd 20 10/9/13 3:37 PM
