Safety 2
EN Before you start
• These instructions are for
your safety. Please read
the following instructions
before proceeding with
the installation and use of
this appliance. Keep the
instruction manuals for
future reference.
WARNING! This appliance
uses Isobutane R600a
refrigerant, which can be
flammable or explosive.
Repairs and disposal must
always be carried out by a
R600a qualified engineer.
WARNING! Risk of
fire / flammable materials!
WARNING: Do not use
mechanical devices or other
means to accelerate the
defrosting process, other than
those recommended by the
manufacturer.
WARNING: Do not damage
the refrigerant circuit.
WARNING: Do not use
electrical appliances
inside the food storage
compartments of the
appliance, unless they are
of the type recommended
by the manufacturer.
WARNING: Do not locate
multiple portable
socket-outlets or portable
power supplies at the rear
of the appliance.
WARNING: When positioning
the appliance, ensure the
supply cord is not trapped
or damaged.
WARNING: Keep ventilation
openings, in the appliance
enclosure or in the built-in
structure, clear of
obstruction.
WARNING: Do not block any
ventilation grills and ensure
there is sufficient airflow at
the rear of the appliance.
CAUTION: The appliance is
for the storage of beverages
only. Do not store food or any
other item in this appliance.
CAUTION: Do not overload
the shelves and follow the
maximum loading capacity.
5059340158037_MNL_IN_V04.indb 25059340158037_MNL_IN_V04.indb 2 1/11/22 3:32 PM1/11/22 3:32 PM

CAUTION: Ensure that the
bottles do not protrude from
the door opening to avoid
damaging the glass on closing.
• To avoid the risks that are
always present when you use
an electrical appliance it is
important that this appliance
is installed correctly and
that you read the safety
instructions carefully to
avoid misuse and hazards.
• This appliance is for
domestic household use only.
• The appliance is intended
to be used in dry indoor
areas only.
• Check the package and make
sure you have all of the parts
listed and decide upon the
appropriate location for the
appliance.
• After unpacking the
appliance please check that
it is not damaged. If in doubt,
do not use the appliance but
contact Customer Services
on 0800 324 7818 (UK) and
1800 932 230 (Eire).
• Place the appliance on a dry,
level, rigid surface.
• The specification plate
shown on this appliance
displays all the necessary
identification information for
ordering replacement parts
and further information can
be found at the end of this
manual.
• Do not store explosive
substances such as aerosol
cans with a flammable
propellant in this appliance
• This appliance contains glass
so please take care with
fitting or handing to prevent
personal injury or damage to
the appliance.
• Children aged from
3 to 8 years are allowed to
load and unload refrigerating
appliances.
• This appliance can be
used by children aged
from 8years and above
and persons with reduced
physical, sensory or
mental capabilities or
lack of experience and
knowledge if they have
been given supervision or
instruction concerning use
of the appliance in a safe
way and understand the
hazards involved. Children
shall not play with the
appliance. Cleaning and user
maintenance shall not be
made by children without
supervision.
Safety 3
5059340158037_MNL_IN_V04.indb 35059340158037_MNL_IN_V04.indb 3 1/11/22 3:32 PM1/11/22 3:32 PM

Safety 4
• Do not allow children to
play inside or with the door
of this appliance to avoid
possible toppling over of the
appliance and injury.
• Do not allow children access
to the front grill or rear
compressor department
of this appliance to avoid
possible injury.
• If the supply cord is
damaged, it must be replaced
by the manufacturer, its
service agent or similarly
qualified persons in order
to avoid a hazard.
• Connection to the mains
supply should not be made
with an extension cord.
• Unplug the appliance from
the mains supply when not
in use, before cleaning or
moving from one location.
• A steam cleaner should
never be used to clean the
appliance.
• If you sell the appliance, give
it away, or leave it behind
when you move house,
please ensure that you pass
on this manual so that the
new owner can become
familiar with the appliance
and its safety warnings.
• Do not attempt to repair this
appliance yourself, there
are no user serviceable
parts inside. In the event of
a malfunction, contact the
Customer Service helpline
at the end of this manual.
• Repairs should only be
made by an authorized
service engineer using
genuine replacement spares.
Repairs by non-authorized
engineers could invalidate
your guarantee. Contact the
Customer Service helpline
at the end of this manual for
assistance.
• Dispose of all packaging
materials safely and
responsibly.
• Avoid leaving the door
open for long periods.
This may cause a significant
increase of the temperature
in the compartment of the
appliance.
• If the appliance is left empty
for long periods, switch
off, clean, dry and leave
the door open to prevent
mould developing within the
appliance.
5059340158037_MNL_IN_V04.indb 45059340158037_MNL_IN_V04.indb 4 1/11/22 3:32 PM1/11/22 3:32 PM

Installation
5
Before connecting the mains supply ensure that the mains voltage corresponds to the voltage on the
rating plate.
Direct Connection
• The appliance is supplied with a fitted plug suitable for use in your country.
• Do not bend the cable or compress it under a heavy load.
• Regularly check the supply cord for damage. If the supply cord becomes damaged, it must be replaced
by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
Contact the Customer Service helpline at the end of this manual.
WARNING: This is a Class I appliance and MUST be earthed.
Technical data
Trademark: GOODHOME / COOKE&LEWIS
Model no.: GHFSWC25BUK / CLFSWC25BEU
Design type: Freestanding
Voltage/frequency: 220-240V~, 50Hz
Rated current: 0.55A
Protection class: I
Climate Class: N/SN (see note 2)
Refrigerant/weight: R600a / 36g
Insulation blowing gas: Cyclopentane
Loading capacity: 28 bottles (see note 1)
Net weight: 24.9kg
Supplier’s name or trade mark: GOODHOME / COOKE&LEWIS
Supplier’s address (b):
UK Manufacturer: Kingfisher International Products Limited, 3 Sheldon Square, London, W2 6PX,
United Kingdom
EU Manufacturer: Kingfisher International Products B.V. Rapenburgerstraat 175E 1011 VM
Amsterdam The Netherlands
Model identifier: GHFSWC25BUK / CLFSWC25BEU
Type of refrigerating appliance:
Low-noise appliance: No Design type: Free-
standing
Wine storage appliance: Yes Other refrigerating appliance: No
General product parameters:
Parameter Value Parameter Value
Overall
dimensions
(millimetre)
Height 830
Total volume (dm3or l) 88Width 430
Depth 480
EEI 171 Energy efficiency class G
5059340158037_MNL_IN_V04.indb 55059340158037_MNL_IN_V04.indb 5 1/11/22 3:32 PM1/11/22 3:32 PM

Installation
6
Airborne acoustical noise
emissions (dB(A) re 1 pW) 44 Airborne acoustical noise emission class D
Annual energy consumption
(kWh/a) 139 Climate class: SN/N
Minimum ambient temperature
(°C), for which the refrigerating
appliance is suitable
10°C Maximum ambient temperature (°C),
for which the refrigerating appliance
is suitable
32°C
Winter setting No
Compartment Parameters:
Compartment type
Compartment parameters and values
Compartment
Volume
(dm3or l)
Recommended
temperature setting
for optimised food
storage (°C) Freezing
capacity
(kg/24 h)
Defrosting
type (auto-
defrost =
A, manual
defrost = M)
These settings shall
not contradict the
storage conditions
set out in Annex IV,
Table 3
Pantry No — — — —
Wine storage Yes 88.0 12 — A
Cellar No — — — —
Fresh food No — — — —
Chill No — — — —
0-star or
ice-making No — — — —
1-star No — — — —
2-star No — — — —
3-star No — — — —
4-star No — — — —
2-star section No — — — —
Variable
temperature
compartment
Compartment
types — — — —
For 4-star compartments
Fast freeze facility No
For wine storage appliances
Number of standard wine bottles 28
5059340158037_MNL_IN_V04.indb 65059340158037_MNL_IN_V04.indb 6 1/11/22 3:32 PM1/11/22 3:32 PM

Installation
7
Light source parameters (a) (b):
Type of light source LED
Energy efficiency class Exempt from (EU)2019/2015
Minimum duration of the guarantee offered by the manufacturer (b): 24 months
Additional information:
Weblink to the manufacturer’s website, where the information in point 4 of Annex II of Commission
Regulation (EU) 2019/2019 (1) is found:
(a) as determined in accordance with Commission Delegated Regulation (EU) 2019/2015 (2).
(b) changes to these items shall not be considered relevant for the purposes of point 4 of Article 4 of
Regulation (EU) 2017/1369.
(c) if the product database automatically generates the definitive content of this cell the supplier shall not
enter these data.
(d) this item shall not be considered relevant for the purpose of Article 2(6) of Regulation (EU) 2017/1369.
A general description of the refrigerating model, sufficient for it to be unequivocally and easily
identified:
Product specifications:
General product specifications:
Parameter Value Parameter Value
Annual energy consumption
(kWh/a) 139.07 EEI (%) 171.0
Standard annual energy
consumption (kWh/a) 81.34 Combi parameter 1.00
Temperature rise time (h) - Load factor 1.0
Door heat loss factor 1.000 Climate class SN/N
Anti-condensation heater type none Airborne acoustical noise
emissions (dB(A) re 1 pW) 44
Additional product specifications for refrigerating appliances, except for low noise refrigerating
appliances:
Parameter Value
Daily energy consumption at 32 °C (kWh/24h) 0.621
Additional product specifications for low noise refrigerating appliances:
Parameter Value
Daily energy consumption at 25 °C (kWh/24h) -
Additional product specifications for wine storage appliances
Parameter Value Parameter Value
Internal humidity (%) 80 Number of bottles 28
5059340158037_MNL_IN_V04.indb 75059340158037_MNL_IN_V04.indb 7 1/11/22 3:32 PM1/11/22 3:32 PM

Installation
8
Compartment specifications
Compartment
type
Compartment parameters and values
Target
temperature
(°C)
Compartment
volume
(dm3or l)
Freezing
capacity
(kg/24 h)
Thermo-
dynamic
parameter
(rc)
Nc Mc Defrost factor
(Ac)
Built-in
factor
(Bc)
Pantry - - - - - - - -
Wine storage +12 88.0 - 0.60 75 0.12 1.00 1.00
Cellar - - - - - - - -
Fresh food - - - - - - - -
Chill - - - - - - - -
0-star or
ice making - - - - - - - -
1-star - - - - - - - -
2-star - - - - - - - -
3-star - - - - - - - -
4-star - - - - - - - -
2-star section - - - - - - - -
Variable
temperature
compartment - - - - - - - -
The sum of
the volumes
of the chill
compartment(s)
and the unfrozen
compartment(s)
(l or dm3)
88
The sum of
the volumes
of the frozen
compartment(s)
(l or dm3)
-
Notes:
1. Loading capacity will vary dependent upon the loading configuration and bottle size.
(Capacity: 28bottles standard Bordeaux size 750ml).
2. This appliance is designed to be used within an ambient temperature range of 10°C to 32°C.
(Climate Class: Sub-Normal SN, Normal N).
According to EU regulation 2019/2016. Information can also be found at the website:
www.kingfisher.com/products
5059340158037_MNL_IN_V04.indb 85059340158037_MNL_IN_V04.indb 8 1/11/22 3:32 PM1/11/22 3:32 PM

Installation
9
Fault Finding
The appliance makes noises including the
sound of flowing liquid. This is perfectly normal and is the sound of the coolant flowing through the compressor. Ensure the appliance is
level and that there is a small gap between the wall and
the rear of the carcass.
The appliance does not operate. Ensure that the supply cord is properly connected to a
suitable socket-outlet. Contact the Customer Helpline at
the end of this manual if assistance is needed.
The appliance turns itself on and off
frequently. Ensure the ambient temperature is no higher than 32°C. Close the door properly and do not open the door more
often than necessary.
The compressor is not working. Wait for 5-10 minutes and check again. Contact the
Customer Helpline at the end of this manual if assistance
is needed.
The compressor runs constantly. Place your hand in the cavity or check a bottle. If this does
not feel cold contact the Customer Helpline at the end of
this manual.
The appliance vibrates during operation. Ensure that the appliance is on a level surface without
touching any walls. Adjust the feet if needed. If the
vibration continues, contact the Customer Helpline at the
end of this manual.
The door does not close properly. Ensure that the appliance is on a level surface and the
gasket is clean. Check and reassemble the door hinge
if needed.
The contents are not cold enough. Adjust the thermostat for the right results. Ensure that the
appliance is not sited in direct sunlight or the door is open.
Condensation forms on the inside
of the door. Ensure that the door does not remain open for long periods of time. High ambient temperatures and very low
thermostat settings may cause condensation to form.
No light inside the cabinet. The light is not replaceable by the consumer.
Please contact the Customer Helpline at the end
of this manual for assistance.
Recycling & disposal
Waste electrical products (WEEE) should not be disposed of with household waste. Please recycle
where facilities exist. Check with your local governmental authority, domestic waste disposal
services or the retailer where the product was bought for recycling advice. The wheelie bin symbol
on the product or its packaging indicates that this product cannot be treated as normal household
waste. This product must be handed over to an electric and electronic equipment collection point for
recycling.
5059340158037_MNL_IN_V04.indb 95059340158037_MNL_IN_V04.indb 9 1/11/22 3:32 PM1/11/22 3:32 PM
