Checking instructions
These instructions are for your safety. Please read the following
instructions carefully before proceeding with the installation
and use of this appliance.
WARNING: All installation work must be carried out by a suitably
qualified person, strictly following local building regulations and
these instructions.
To avoid the risks that are always present when you use an electrical
appliance it is important that this cooker hood is installed correctly
and that you read the safety instructions carefully to avoid misuse
and hazards. After unpacking the cooker hood please check that
it is not damaged. If in doubt, do not use the appliance but contact
Customer Services on 0800 324 7818 (UK) and 1-800 932 230 (Eire).
Check the package and make sure you have all of the parts listed
and decide upon the appropriate location for your product. If this
product contains glass please take care with fitting or handling to
prevent personal injury or damage to the product. The specification
plate shown on this appliance displays all the necessary identification
information for ordering replacement parts. If you sell the appliance,
give it away, or leave it behind when you move house, please ensure
that you pass on this manual so that the new owner can become
familiar with the appliance and its safety warnings.
Safety
5WARNING: There is a risk of electric shock and fire if cleaning is
not carried out in accordance with these instructions.
5WARNING: Where applicable, this appliance is supplied with
fixings. Please ensure you use the correct fixings suitable for the
substrate where the appliance will be installed and that they are
able to support the weight of the appliance.
5WARNING: Use only the same size of fittings and mounting
screws as recommended in this instruction manual. Failure to
follow these instructions may result in electrical hazards.

5WARNING: Switch off the appliance at the mains supply before
carrying out any maintenance work or cleaning.
5WARNING: Accessible parts may become hot when used with
cooking appliances. Children less than 8 years of age shall be
kept away unless continuously supervised. Care should be taken
to avoid touching the appliance.
5WARNING: Do not flambé under the hood. To avoid the risk of
fire, clean or replace the grease filter regularly and closely monitor
pans containing hot oil.
5WARNING: Means for full disconnection must be incorporated
in the fixed wiring in accordance with the local wiring installation
rules for your country. An all-pole disconnection switch having
a contact separation of at least 3mm in all poles should be
connected during installation.
5WARNING: When the extractor hood is located above an
appliance, the minimum distance between the supporting surface
for the cooking vessels on the hob and the lowest part of the hood
shall be at least 760mm.
5WARNING: Before connecting the hood, check that the supplied
voltage and frequency match with that indicated on the appliance
rating plate. Failure to install the appliance in accordance with
these instructions may result in a safety hazard. If in doubt, ask for
advice instore or from a qualified installer.
5WARNING: Consult local regulations regarding extraction outlets
and ensure these are complied with. Do not connect the hood
to a ventilation or hot air duct containing combustion fumes
from burning gas or other fuels. Confirm that room ventilation is
appropriate with the local authorities.
5WARNING: The hood may stop working during an electrostatic
discharge (e.g. lightning). This involves no risk of damage.
Switch off the electricity supply to the hood and reconnect after
one minute.
5WARNING: This appliance can be used by children aged from 8
years and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if they

have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
Keep the appliance and its supply cord out of the reach of children
less than 8 years old.
5If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in
order to avoid a safety hazard.
5Do not install the appliance outdoors in a damp place or in an
area which may be prone to water leaks such as under or near a
sink unit. In the event of a water leak affecting the appliance, do
not use and contact customer services to arrange for inspection.
5Do not use flammable sprays in close vicinity to the appliance.
5Please dispose of the packing material carefully. There is a
fire risk if cleaning is not carried out in accordance with the
instructions. Refer to the Care and Maintenance sections carefully
for details on how to clean and replace the aluminium and carbon
filters (if fitted).
5The LED lamps in this appliance are not replaceable by the
consumer. If a lamp fails, please contact the customer helpline at
the end of Care & maintenance to arrange an engineer visit.
5Do not use a steam cleaner for care and maintenance.
5The appliance is not intended to be operated by means of an
external timer or separate remote control system.
5There shall be adequate ventilation of the room when the hood is
used at the same time as appliances burning gas or other fuels.
Ensure that the negative pressure of the installation site does not
exceed 4 Pa (0.04 mbar) to ensure combustion fumes are not
drawn back into the room.
5Do not use the hood if it shows signs of damage or imperfection.
Contact customer services for assistance.

5The manufacturer declines all liability for personal or material
damage as a result of misuse or incorrect installation of
this appliance.
5The appliance is for domestic use only as an extractor hood.
Installation
All installation must be carried out by a competent person or qualified electrician. Before connecting
the mains supply ensure that the mains voltage corresponds to the voltage on the rating plate.
Direct Connection
The appliance must be connected directly to the mains using an omnipolar circuit breaker with a
minimum opening of 3mm between the contacts.
The installer must ensure that the correct electrical connection has been made and that it complies
with the wiring diagram.
The cable must not be bent or compressed.
Regularly check the power plug and power cord for damage. If the supply cord is damaged, it must
be replaced by a special cord or assembly available from the manufacturer or its service agent.
WARNING: This is a Class I appliance and MUST be earthed.
This appliance is supplied with a 3 core mains cable coloured as follows:
Brown = L or Live
Blue = N or Neutral
Green and Yellow = E or Earth
USE A 3AMP FUSE
DOUBLE POLE SWITCHED
FUSED SPUR OUTLET
EUR UK
(Blue)
(Brown)
(Green/Yellow)
N
L
N
L
N
L
FUSE ON
The fuse must be rated at 3 Amps.
To avoid the risks that are always present when you use an electrical appliance it is important that
this appliance is installed correctly and that you read the safety instructions carefully to avoid misuse
and hazards. Please keep this instruction booklet for future reference and pass it on to any future
owners. After unpacking the appliance please check that it is not damaged. If in doubt, do not use the
appliance but contact Customer Services.
The manufacturer declines all liability for damage caused to persons and objects due to incorrect
or improper installation of the appliance. Any permanent electrical installation must comply with the
latest wiring regulations applicable to your country and for your own safety a qualified electrician or
contractor should undertake the electrical installation.
The appliance is supplied from the factory to use external ducting (not supplied). Should you wish to
use this in recirculation mode only, please fit the correct carbon filter (not supplied).
