STEP 1
Take all parts out of boxes 1 and 2
and ensure they are all present.
Box 1
a) Lower pole x 1
b) 360˚ Swivel system x 1
c) Screws x 4 (M8 x 15)
d) Screws x 4 (M8 x 25)
e) Washer x 8
f) Umbrella frame & canopy x 1
g) Crank handle x 1
h) Screw with plastic cap x 1
i) Plastic cover x 1
j) Plastic cone x 1
k) Allen key x 1
l) Umbrella cover x 1
m) Stay pole x 1
Box 2
n) Fillable base and metal
cross base x 1
o) Base wheels x 4 (optional)
STEP 2
Check that cross base pieces are secured to
the under side of (n).
Attach wheels (o) to the underside
of (n) (optional).
STEP 4
Place the plastic cone (j) over the lower pole
(a) & position over 360° swivel system (b).
STEP 6
Place the umbrella frame pole (f) onto the
lower pole (a). Push plastic cover (i) down to
sit neatly on plastic cone (j). Secure poles
together using the screw with plastic cap (h).
STEP 7
Using the easy glide handle, push in an
upwards direction towards the top of
the umbrella pole until it locks into the
lowest position.
STEP 8
Open the umbrella by inserting and
rotating the crank handle (g).
STEP 11
To tilt the canopy horizontally, release the
lever on (f) as shown, then rotate to the le
or right and lock into position at desired angle.
2.82m/9'3"
2.2m/7'3"
3.5m/11'6"
BANKSIA
ASSEMBLY GUIDE
a
e
i
m
d
h
l
b
f
j
n
c
g
k
o
STEP 3
Using screws (d) and washers (e) x the
360° swivel system (b) onto the llable
base (n). Then x the lower pole (a) to
the 360° swivel system (b) using screws (c)
and remaining 4 washers (e).
Ensure canopy is closed when not in use. Close in windy conditions or when a storm approaches. Never allow the umbrella
to ap in the wind; this could damage the canopy. Do not use in extreme weather conditions including heavy rain or high winds.
The base must be lled with water to prevent the umbrella from tipping. This is a non permanent structure.
STEP 5
Place the plastic cover (i) on the bottom
of the umbrella frame pole (f) as shown.
i
f
j
a
e
e
d
c
n
b
f
i
a
h
1
2
g
12
STEP 9
Adjust the vertical angle of the umbrella,
by sliding the easy glide handle up the
pole and locking into desired position.
STEP 10
The umbrella can be rotated 360° by
stepping on the foot pedal on the base.
1
2
2
1
n
o

STEP 1
Take all parts out of boxes 1 and 2
and ensure they are all present.
Box 1
a) Lower pole x 1
b) 360˚ Swivel system x 1
c) Screws x 4 (M8 x 15)
d) Screws x 4 (M8 x 25)
e) Washer x 8
f) Umbrella frame & canopy x 1
g) Crank handle x 1
h) Screw with plastic cap x 1
i) Plastic cover x 1
j) Plastic cone x 1
k) Allen key x 1
l) Umbrella cover x 1
m) Stay pole x 1
Box 2
n) Fillable base and metal
cross base x 1
o) Base wheels x 4 (optional)
STEP 2
Check that cross base pieces are secured to
the under side of (n).
Attach wheels (o) to the underside
of (n) (optional).
STEP 4
Place the plastic cone (j) over the lower pole
(a) & position over 360° swivel system (b).
STEP 6
Place the umbrella frame pole (f) onto the
lower pole (a). Push plastic cover (i) down to
sit neatly on plastic cone (j). Secure poles
together using the screw with plastic cap (h).
STEP 7
Using the easy glide handle, push in an
upwards direction towards the top of
the umbrella pole until it locks into the
lowest position.
STEP 8
Open the umbrella by inserting and
rotating the crank handle (g).
STEP 11
To tilt the canopy horizontally, release the
lever on (f) as shown, then rotate to the le
or right and lock into position at desired angle.
2.82m/9'3"
2.2m/7'3"
3.5m/11'6"
BANKSIA
ASSEMBLY GUIDE
a
e
i
m
d
h
l
b
f
j
n
c
g
k
o
STEP 3
Using screws (d) and washers (e) x the
360° swivel system (b) onto the llable
base (n). Then x the lower pole (a) to
the 360° swivel system (b) using screws (c)
and remaining 4 washers (e).
Ensure canopy is closed when not in use. Close in windy conditions or when a storm approaches. Never allow the umbrella
to ap in the wind; this could damage the canopy. Do not use in extreme weather conditions including heavy rain or high winds.
The base must be lled with water to prevent the umbrella from tipping. This is a non permanent structure.
STEP 5
Place the plastic cover (i) on the bottom
of the umbrella frame pole (f) as shown.
i
f
j
a
e
e
d
c
n
b
f
i
a
h
1
2
g
12
STEP 9
Adjust the vertical angle of the umbrella,
by sliding the easy glide handle up the
pole and locking into desired position.
STEP 10
The umbrella can be rotated 360° by
stepping on the foot pedal on the base.
1
2
2
1
n
o

STEP 1
Take all parts out of boxes 1 and 2
and ensure they are all present.
Box 1
a) Lower pole x 1
b) 360˚ Swivel system x 1
c) Screws x 4 (M8 x 15)
d) Screws x 4 (M8 x 25)
e) Washer x 8
f) Umbrella frame & canopy x 1
g) Crank handle x 1
h) Screw with plastic cap x 1
i) Plastic cover x 1
j) Plastic cone x 1
k) Allen key x 1
l) Umbrella cover x 1
m) Stay pole x 1
Box 2
n) Fillable base and metal
cross base x 1
o) Base wheels x 4 (optional)
STEP 2
Check that cross base pieces are secured to
the under side of (n).
Attach wheels (o) to the underside
of (n) (optional).
STEP 4
Place the plastic cone (j) over the lower pole
(a) & position over 360° swivel system (b).
STEP 6
Place the umbrella frame pole (f) onto the
lower pole (a). Push plastic cover (i) down to
sit neatly on plastic cone (j). Secure poles
together using the screw with plastic cap (h).
STEP 7
Using the easy glide handle, push in an
upwards direction towards the top of
the umbrella pole until it locks into the
lowest position.
STEP 8
Open the umbrella by inserting and
rotating the crank handle (g).
STEP 11
To tilt the canopy horizontally, release the
lever on (f) as shown, then rotate to the le
or right and lock into position at desired angle.
2.82m/9'3"
2.2m/7'3"
3.5m/11'6"
BANKSIA
ASSEMBLY GUIDE
a
e
i
m
d
h
l
b
f
j
n
c
g
k
o
STEP 3
Using screws (d) and washers (e) x the
360° swivel system (b) onto the llable
base (n). Then x the lower pole (a) to
the 360° swivel system (b) using screws (c)
and remaining 4 washers (e).
Ensure canopy is closed when not in use. Close in windy conditions or when a storm approaches. Never allow the umbrella
to ap in the wind; this could damage the canopy. Do not use in extreme weather conditions including heavy rain or high winds.
The base must be lled with water to prevent the umbrella from tipping. This is a non permanent structure.
STEP 5
Place the plastic cover (i) on the bottom
of the umbrella frame pole (f) as shown.
i
f
j
a
e
e
d
c
n
b
f
i
a
h
1
2
g
12
STEP 9
Adjust the vertical angle of the umbrella,
by sliding the easy glide handle up the
pole and locking into desired position.
STEP 10
The umbrella can be rotated 360° by
stepping on the foot pedal on the base.
1
2
2
1
n
o

Exposure to ultraviolet (UV) radiation from the sun is the
major cause of skin cancer. In some countries the UV radiation
is strong enough to cause sunburn in just 11 minutes on a
ne summers day. To prevent sun damage we recommend
following the Sun Smart steps: slip on clothing, slop on
sunscreen, slap on a hat, slide on sunglasses and seek shade.
THANK YOU
FOR PURCHASING A
COOLAROO PRODUCT
When not in use, close the umbrella, place a protective cover over it
and store in a dry place. If the canopy is wet, allow to dry naturally
opened up before storing.
If necessary, clean the fabric with a hose.
Components subject to turning and sliding can be treated with a
non-staining lubricant spray (silicon-based).
CARE & MAINTENANCE
For help with product assembly
or for any other questions
you may have, contact our
Customer Service Department.
Australia Toll Free: 1800 331 521
New Zealand Toll Free: 0800 555 171
United States Ph: [phone]
Middle East Ph: [phone]
China Ph: [phone]
WARNING
When assembling and using this product, safety precautions should always be followed to reduce the
risk of personal injury and damage to equipment. Please read all instructions before assembly and use.
At least two or more people are recommended for safe assembly.
Keep all children and pets away from assembly area.
Install on level ground.
Check all nuts and bolts for tightness before and regularly during usage.
The base must be weighted down, ll with water to prevent tipping.
This is a non-permanent structure, do not use in extreme weather conditions including
heavy rain or high winds.
Do not leave the umbrella open unattended.
Do not place the product near an open ame; or too close to any heat source.
The best under the sun
Coolaroo is the leader in shade fabric technology.
Our extensive range of attractive shade solutions
is carefully manufactured to protect your home,
garden and family from the harsh sun.
coolaroo.com.au
Gale Pacic Limited
145 Woodlands Drive,
Braeside, Victoria, 3195 Australia
Coolaroo is a registered trademark
of Gale Pacic Limited
Attention: The schematics in this manual are for assembly and operation illustration only.
They may dier from the umbrella’s actual appearance.
To register your product go to coolaroo.com.au. The product code can be found
printed above the barcode on the product packaging, alternatively you can nd it
on the relevant coolaroo.com.au product page.
430542/1505
ASSEMBLY GUIDE
CANTILEVER UMBRELLA
BANKSIA
5YR
Warranty
A
G
A
I
N
S
T
U
V
D
E
G
R
A
D
A
T
I
O
N
5
Y
E
A
R
F
A
B
R
I
C
W
A
R
R
A
N
T
Y
122 Cremorne Street,
Cremorne , Victoria 3121
t 03 9427 1286
f 03 9427 1286
w creativeresults.com.au
© Creative Results
Date 23/06/15 4:50 PM
Job / Version 13295 Coolaroo Cantilever Umbrella Instructions - Banksia A5 3d FINAL
Flat Size 443mm x 210mm
Finished Size 148mm x 210mm
Product Code 430542/1505
Barcode No.
Barcode Size
Print Process 4CP
Finished Artist
Anthony
Head of Creative
Account Manager
Client
Every effort has been made by
Creative Results to ensure this
artwork is correct. It is, however,
the client’s final responsibility
to check and sign off artwork
proofs or PDFs.
Creative Results will not be
responsible for any errors
approved by the client.
PROCESS
4C

Exposure to ultraviolet (UV) radiation from the sun is the
major cause of skin cancer. In some countries the UV radiation
is strong enough to cause sunburn in just 11 minutes on a
ne summers day. To prevent sun damage we recommend
following the Sun Smart steps: slip on clothing, slop on
sunscreen, slap on a hat, slide on sunglasses and seek shade.
THANK YOU
FOR PURCHASING A
COOLAROO PRODUCT
When not in use, close the umbrella, place a protective cover over it
and store in a dry place. If the canopy is wet, allow to dry naturally
opened up before storing.
If necessary, clean the fabric with a hose.
Components subject to turning and sliding can be treated with a
non-staining lubricant spray (silicon-based).
CARE & MAINTENANCE
For help with product assembly
or for any other questions
you may have, contact our
Customer Service Department.
Australia Toll Free: 1800 331 521
New Zealand Toll Free: 0800 555 171
United States Ph: [phone]
Middle East Ph: [phone]
China Ph: [phone]
WARNING
When assembling and using this product, safety precautions should always be followed to reduce the
risk of personal injury and damage to equipment. Please read all instructions before assembly and use.
At least two or more people are recommended for safe assembly.
Keep all children and pets away from assembly area.
Install on level ground.
Check all nuts and bolts for tightness before and regularly during usage.
The base must be weighted down, ll with water to prevent tipping.
This is a non-permanent structure, do not use in extreme weather conditions including
heavy rain or high winds.
Do not leave the umbrella open unattended.
Do not place the product near an open ame; or too close to any heat source.
The best under the sun
Coolaroo is the leader in shade fabric technology.
Our extensive range of attractive shade solutions
is carefully manufactured to protect your home,
garden and family from the harsh sun.
coolaroo.com.au
Gale Pacic Limited
145 Woodlands Drive,
Braeside, Victoria, 3195 Australia
Coolaroo is a registered trademark
of Gale Pacic Limited
Attention: The schematics in this manual are for assembly and operation illustration only.
They may dier from the umbrella’s actual appearance.
To register your product go to coolaroo.com.au. The product code can be found
printed above the barcode on the product packaging, alternatively you can nd it
on the relevant coolaroo.com.au product page.
430542/1505
ASSEMBLY GUIDE
CANTILEVER UMBRELLA
BANKSIA
5YR
Warranty
A
G
A
I
N
S
T
U
V
D
E
G
R
A
D
A
T
I
O
N
5
Y
E
A
R
F
A
B
R
I
C
W
A
R
R
A
N
T
Y
122 Cremorne Street,
Cremorne , Victoria 3121
t 03 9427 1286
f 03 9427 1286
w creativeresults.com.au
© Creative Results
Date 23/06/15 4:50 PM
Job / Version 13295 Coolaroo Cantilever Umbrella Instructions - Banksia A5 3d FINAL
Flat Size 443mm x 210mm
Finished Size 148mm x 210mm
Product Code 430542/1505
Barcode No.
Barcode Size
Print Process 4CP
Finished Artist
Anthony
Head of Creative
Account Manager
Client
Every effort has been made by
Creative Results to ensure this
artwork is correct. It is, however,
the client’s final responsibility
to check and sign off artwork
proofs or PDFs.
Creative Results will not be
responsible for any errors
approved by the client.
PROCESS
4C
