Coolaroo HAMPTON 3M ROUND User manual

CANTILEVER UMBRELLA
HAMPTON
3M ROUND  3.5M ROUND | 3M SQUARE
2x3M RECTANGLE | 3x4M RECTANGLE
ASSEMBLY GUIDE AND
OPERATING INSTRUCTIONS

WARNING
When assembling and using this product, safety precautions should always be followed to
reduce the risk of personal injury and damage toequipment.
Please read all instructions before assembly and use.
Two or more people are recommended for safe assembly.
Keep all children and pets away from assembly area.
Install on level ground.
Check all nuts and bolts for tightness before use and regularly during use.
This isa non-permanent structure, do not use in extreme weather conditions including
heavy rain or high winds.
Do not leave the umbrella unattended whenopen.
heaters or BBQs.
CARE AND MAINTENANCE
When not in use, close the umbrella, fasten canopy and store in a
dry place. If the canopy is wet, allow to dry naturally when
opened up before storing.
If necessary, clean the fabric with a hose.
Components subject to turning and sliding can be treated with a
non-staining lubricant spray (silicon-based).
The diagrams in this manual are for illustration purposes only, to assist with
assembly and operation. They may dier from the umbrella's actual appearance.

ASSEMBLY GUIDE
HAMPTON CANTILEVER UMBRELLA
3M SQUARE
510466
3m
3m
2.7m 2.1m
2x3M RECTANGLE
510473
3m
2m
2.8m 2.1m
3x4M RECTANGLE
510497
3m
4m
3m 2.3m
3.5M ROUND
510480
3.5m
2.7m 2.1m
3M ROUND
510459
3m
2.7m 2.1m

STEP 2
Attach the swivel base (c) to the water base (k) using screws (e) and washers (g).
Use allen key (I) to tighten.
k
g
e (M8x25)
c
i
STEP 1
Take all of the parts out of box 1 and 2 to ensure they are all present before
starting construction.
Box 1
a) Umbrella frame and cover
b) Lower pole
c) 360 degree swivel
d) Plastic cover
e) Bolts x4 (M8x25)
f) Bolts x4 (M8x14)
g) Washers x8
h) Crank handle
i) Allen key
j) Locking screw x2
Box 2
k) Fillable base
(M8x25)
e.
f.
d.
c.
b.
a.
k.
j.
i.
h.
g.
(M8x14)
(Ø16xØ8.2x2)

STEP 4
Fill base (k) with water or sand. Place plastic cover (d) over lower pole (b).
d
STEP 3
Attach the lower pole (b) to the swivel base using screws (f) and washers (g).
Use allen key (I) to tighten.
b
f
g
i

STEP 6 - TO OPERATE
inserting and winding the crank handle (h).
h
STEP 5
Place umbrella frame and cover(a) over lower pole (b) so it slides inside the plastic
cover (d).
a
①
b②
③
j

STEP 8 - ROTATING THE CANOPY
Use the foot pedal on the swivel base (c) to rotate the canopy in a clockwise, or anti
clockwise direction. The canopy can be rotated 360 degrees in either direction.
360°
①
②
STEP 7
To open the canopy, wind the crank handle (h) in a clockwise direction. To close the
canopy, wind the crank handle in an anti clockwise direction.
h
Close
Open

STEP 9 - CLOSING THE UMBRELLA
To close the umbrella, wind the canopy down with the crank handle in the anti
clockwise direction. Move the easy glide handle to the bottom position and wrap the
Velcro®straps around the canopy.
f.
Ensure canopy is closed when not in use. Close in windy conditions or when a storm approaches.
STEP 10 - INSTALL THE COVER
With the cover open, use the stay poles to position the cover over the closed
umbrella. Use the Velcro®to close and secure the cover over the umbrella.

PRODUCT WARRANTY AND
AND LIMITATION OF LIABILITY
ACN 082 263 778 (Gale). Gale provides the following
warranty in relation to Coolaroo products (“Product”).
and remedies imposed by Australian Consumer Law, NZ
Consumer Guarantees Act 1993, and state and federal
legislation that cannot be excluded. Nothing in this warranty
is to be interpreted as excluding, restricting or modifying
any applicable legislation to the supply of goods and
WARRANTY
Gale warrants that, subject to the exclusions and limitations
below, all parts of the manufacture and assembly of the
Product will be free from defects in materials and
workmanship, for a period of 2 years for the frame and 7
years for the canopy, from the date of purchase.
If a defect appears in the Product before the end of the
in materials or workmanship, Gale will, in its sole
discretion, either:
a) replace or repair the Product or the defective part of the
Product free of charge; or
b) refund the purchase price of the Product.
Gale reserves the right to replace defective parts of the
Product with parts and components of similar quality, grade
and composition where an identical part or component is
not available.
The warranty will not apply where:
a)
other than Gale or its authorised agent;
b) the alleged defect in the Product is within acceptable
industry variances;
c) Gale cannot establish any fault in the Product;
d) the defect in the Product has arisen due to the
customer’s failure to install and use the Product in
accordance with the instructions provided;
e) the defect in the Product has arisen due to the
customer’s request to customise the Product;
f) the Product has been subject to abnormal conditions,
humidity, pressure, stress or similar.
The warranty does not extend to:
a) damage or defects caused by normal wear and tear,
b) water or sun damage; or
c) any other damage caused by the customer placing other
equipment, furniture or material in close proximity to the
Product.
Gale makes no express warranties or representations other
than set out in this warranty.
The repair or replacement of the Product or part of the
Product is the absolute limit of Gale’s liability under this
express warranty.
WARRANTY CLAIMS
1) Upon purchasing the Product, the customer must
register their warranty by completing the Coolaroo
online warranty registration at www.coolaroo.com.
Alternatively, the customer can contact Coolaroo
Customer Service on 1800 331 521 (AU) or 0800 555 171
(NZ) for assistance.
2) If a fault covered by warranty occurs, the customer must
contact Gale using the contact details provided.
3) Any warranty claim must be accompanied by proof of
purchase and details of the alleged defect.
4) The customer must bear the cost of the transport of the
Product toand from Gale or the authorised agent tomake
the warranty claim, and all insurance of the Product.
AUSTRALIAN CONSUMER LAW
contracting out of any applicable provisions of the
Competition and Consumer Act 2010 or the Fair Trading
Acts in each of the States and Territories of Australia, except
to the extent permitted by those Acts where applicable.
This warranty is not transferable, and applies only to the
initial purchaser of the installed Product.
In addition to the above warranty, Australian Consumer law
and other state and territory legislation may imply
warranties or conditions or impose liability on Gale in
relation to the Product or its supply which cannot, or can
only to a limited implied warranties or conditions and such
liability, and for the warranty described above:
a) all warranties and conditions (whether express or
implied, statutory or otherwise) relating to the Product
or its supply are expressly excluded; and
b)
any person (including the purchaser of the Product) in
any way relating to or arising from the Product or its use
(including loss or damage arising from the negligence of,
or contributed to by, Gale).
If liability for breach by Gale of a warranty or condition or any
other liability imposed on Gale by legislation which cannot be
excluded may be limited, Gale’s liability is limited to the
extent permitted by law, and if liability may be limited in any
one of a number of ways, Gale’s liability is limited in any one of
the permitted ways chosen by Gale in its absolute discretion.
The Purchaser acknowledges that the Purchaser does not
rely on the skill or judgment of Gale as to whether or not the
damage, cost or expense directly or indirectly incurred or
Purchaser’s failure to:
1) adequately provide or display safety markings or safety
information on or with the Products;
2) comply with any law about the Products or their use;
3) take any reasonable precaution to bring to the attention
of any potential users of the Products any dangers
associated with Products;
4) any negligence or breach of duty by the Purchaser or any
breach by the Purchaser of these terms.

WARNING: SHADE DOES NOT
PROVIDE 100% PROTECTION
Coolaroo umbrella fabric is tested to meet UPF50+ and the highest
Always combine shade with clothing, sunscreen,
a hat and sunglasses.
Slop Slap Seek SlideSlip
PROTECT YOURSELF IN FIVE WAYS
FROM SKIN CANCER

coolaroo.com

145 Woodlands Drive, Braeside,
Victoria 3195 Australia
Coolaroo and Xceltex are registered
Made in China
THANK YOU
FOR PURCHASING A
COOLAROO PRODUCT
While this umbrella will go a long way in providing protection from the sun,
you should always apply all of the Sun Smart tips for optimal protection
from UV rays. To prevent sun damage we recommend following the Sun
Smart steps: slip on clothing, slop on sunscreen, slap on a hat, slide on
sunglasses and seek shade under your premium Coolaroo umbrella.
To register your product, go to coolaroo.com. The product code can be
found printed above the barcode on the product packaging, alternatively
coolaroo.com
PRODUCT CODES:
Hampton 3m Round Umbrella
Hampton 3.5m Round Umbrella
Hampton 3m Square Umbrella
Hampton 2x3m Rectangle Umbrella
Hampton 3x4m Rectangle Umbrella
For help with product assembly or for any other questions
you may have, contact our Customer Service Department.
Australia toll free: 1800 331 521
New Zealand toll free: 0800 555 171
510459
510480
510466
510473
510497
