ALL PRO
COOPER LIGHTING - SURE-LITES®
COOPER LIGHTING
ORDERING INFORMATION
SAMPLE NUMBER: AP2SQ
Accessories
(Order Separately)
WG-1= Wire Guard
VS1= Polycarbonate Vandal Shield
VS1WP= Polycarbonate Vandal Shield
Weather Resistant
Housing Finish
Blank=White
Model Number
AP2SQ
• Dual-voltage input
120/277VAC, 60Hz
• High impact white
thermoplastic housing
• Square, two head design
• Fully adjustable lamping
• Sealed Lead Calcium
battery
• Test Switch/Power Indicator
Light
• Quick connect AC power
connector facilitates
installation
• Suitable for wall or ceiling
mount applications
• UL 924 Listed, ETL Damp
Location, Life Safety NFPA
101, CSA Certified,
NEC/OSHA, most state and
local codes
AP2SQ SERIES
All Pro
EMERGENCY LIGHTING
DIMENSIONS
5”
[127mm]
12 1/8”
[308mm]
16”
[440mm]
DESCRIPTION
The AP2SQ All Pro Emergency
Series Emergency Lighting
Unit is the ideal choice when
simple installation is necessary.
Its styling and designer finish
enables it to blend with any
decor. The housing and
mounting plate employ snap-fit
construction; the reliable and
labor-saving quick connect AC
connector further improves the
installation time. The under
5-minute installation time of the
AP2SQ Emergency Lighting
Unit makes it one of the fastest
installed units on the market
today. Both lighting heads are
fully adjustable, insuring that
light can be positioned where it
is needed.
4”
[102mm]
2 3/8”
[60mm]
5”
[127mm]
6”
[152mm]
when
extended
ELECTRICAL RATINGS
Rated Wattage to 87 1/2% of Rated D.C. Voltage Lamp Information
Model DC Voltage 1 1/2 Hours 2 Hours Type Wattage Number
AP2SQ 6 10.8 7.2 Incandescent 5.4 29-121
AP2SQ
