Cooper Lighting LUMARK Impact Wall Medium User manual

These instructions do not claim to cover all details or variations in the equipment, procedure, or process described, nor to provide directions for meeting every possible contingency during installation,
operation or maintenance. When additional information is desired to satisfy a problem not covered sufficiently for user’s purpose, please contact your nearest representative.
NOTE: Specifications and dimensions subject to change without notice.
Impact Wall Medium
Door Accessories
Sheet 1 of 1
7/22/08 IMI-698
INSTALLATION INSTRUCTIONS
IMPORTANT : READ CAREFULLY BEFORE INSTALLING FIXTURE. RETAIN FOR FUTURE REFERENCE
GENERAL: Upon receipt of the fixture, thoroughly inspect for any freight
damage which should be brought to the attention of the delivery carrier.
Compare the catalog description listed on the packing slip with the
fixture label on the housing to assure you have received the correct
material.
SAFETY: This fixture must be wired in accordance with the National
Electrical Code and applicable local codes and ordinances. Proper
grounding is required to insure personal safety. Carefully observe
grounding procedure under installation section.
WARNING: Risk of Fire/Shock. If not qualified, consult an electrician.
Risk of Electric Shock. Disconnect power at fuse or circuit breaker
panel or fuse box before installing or servicing.
Customer First Center 1121 Highway 74 South Peachtree City, GA 30269 770.486.4800 FAX [phone] ADH081510
NOTE: This instruction sheet is applicable for both Trapezoid and
Cylinder shapes. Cylinder shape is used for illustration.
VANDAL SHIELD ASSEMBLY:
1. Install four [4] shield tabs onto holes in the door with four [4]
10-24 X 3/8" screws. Do not tighten the screws all the way.
2. Insert four [4] 10-24 X 1 1/2" screws through the vandal shield
and the spacers as shown in FIG 1. Line up the screws with
spacer with shield tabs and tighten it securely. Repeat the
process with all four [4] screws.
3. Fully Tighten the four [4] tabs onto the door.
WIRE GUARD ASSEMBLY:
1. Line up the wire guard with four [4] holes in the door as shown
in FIG 2.
2. Insert four [4] 10-24 X 3/8" screws through the hooks in wire
guard. Tighten the screws until the wire guard is secured onto
the door.
Four (4)
ShieldTabs
Four (4)
1/4" Spacers
One (1)
Polycarbonate
Shield
Four (4)
10-24 X 1 1/2"
Phillips Pan Head
Stainless Steel Screws
Four (4)
10-24 X 3/8"
Phillips Pan Head
Stainless Steel Screws
FIG. 1
Four (4)
10-24 X 3/8"
Phillips Pan Head
Stainless Steel Screws
One (1)
Wire Guard
FIG. 2
