Cooper Lighting Nimbus I 601-IP User manual

NOTES: For complete product data, refer to the Neo-Ray Specification Binder. Specifications and dimensions subject to change without notice. Products may be
modified for use in international markets. Please contact your Cooper Lighting Sales Representative for availability and ordering information.
713
COOPER LIGHTING
NIMBUS I
601-IP
Armstrong®Techzone™
Compatible
SEMI-INDIRECT
SUSPENDED
Construction: Housing is die formed perforated
cold rolled steel forming an 8-3/4” x1-5/8”
architectural profile. Standard 4’-0” and 8’-0” fixture
lengths are modular and can inter-connect to create
continuous runs.
End Caps: End caps are precision die-cast
aluminum mechanically attached without exposed
fasteners. Two distinct styles are available.
Reflector: Side and center reflectors are formed,
semi-specular anodized aluminum.
Electrical: Fixtures use UL listed Class P, T5
program rapid start electronic ballasts. Power factor
of 97% with less than 10% THD. Fixtures and
electrical components certified to UL and CUL
standards.
Finish: Low-gloss white powder coated acrylic
finish.
Mounting: Aircraft cable or a rigid steel pendant
mounts directly to all ceiling types. Standard
mounting includes dual aircraft cable.
8-3/4" [222mm]
1-5/8"
[41mm]
• Minimalist fixture profile –
8.75” wide by 1.625” high.
• Optimized T5 optics for wide
light distribution. and high
efficiency.
• Die formed modular housing
lengths – 4’ and 8’.
• Incremental mounting on the
ceiling grid - 4’ and 8’
centers.
• Precision die cast end caps,
standard or tapered.
• Dual aircraft cable hangers
for superior leveling.
Ordering Information:
Sample number: 601-IP-SP-2T5-1C-120-AC48-T1-24-ET
Series
601-IP=Nimbus I
Optics Up
S=Specular
Optics Down
P=Perforated N=None
Number of Lamps (not included)
2=2 Lamps (T5HO, T8)
Lamp Type (Length)
T5=28W (4’ Unit) T5HO=54W (4’ Unit)
Number of Circuits 1
1=1 Circuit 2=2 Circuit (Side by Side)
Wiring 1
C=Standard Circuit B=Battery Pack D=Dimming
E=Emergency/Nightlight T=Nightlight
*Slim line ballast only (small case)
Voltage 1
1=120V 2=277V 3=347V U=Universal
Suspension
D=Dual Cable (Standard) A=Aircraft Cable (single)
P=Rigid Pendant 2(single stem)
Power Feed 1
C=Straight Cord K=Curly Cord P=Rigid Pendant
Suspension Length
FC=Fixed Cable
12”, 15”, 18”, 21”, 24” or 27” (+/- 1/2” adjustment)
AC=Adjustable Cable
48”, 120”, 240”, 300”, or 360”
(infinite adjustment along entire length of cable)
-Rigid Pendant
12”, 15”, 18”, 21”, 24” or 27”
Ceiling Type
T1=1” T-Bar ST=Structure TS=Slotted T-Bar
T9=9/16” T-Bar JB=4” Octagonal J-Box
TZ=Armstrong®Techzone™
Run Length
04=4’ Section 20=1-4’, 2-8’ Sections
08=8’ Section 24=3-8’ Sections
12=1-8’ Section, 1-4’ Section 24+=Must be a combination of
16=2-8’ Sections 4’ and 8’ sections
End Cap
ET=Tapered ES=Straight
1 Due to various constraints, some options may not be combined with others.
2 Available with 7° or earthquake 45° swivel canopy assembly.
= Slim Line Ballast only.
S
S
STANDARD LUMINAIRE LENGTHS
MODULAR ROW CONFIGURATION
• Standard length sections join easily to create rows.
• Sections align with T-grid.
• All sections prewired for through-wiring with quick connectors.
NEO-RAY™
