1215-TTR SERIES
High Performance
Pendant Luminaire
Indirect/Direct
Shallow Bowl with
Two Trim Options
Specifications and dimensions subject to change without notice.
Consult your representative for additional options and finishes.
shaperlighting.com
The 1215 Shallow Direct/Indirect High Performance Luminous
Pendant features a DoubleTrim Ring (2TR) or aTraditionalTrim Ring
(TTR) and is available in three diameters with multiple mounting
options.
SPECIFICATION FEATURES
Material/Mounting
Painted and plated cold rolled
steel or natural aluminum with a
matte white acrylic bowl. Single
Stem (Standard): 5/8" stem with
a standard hang height of 28"
(OA) for the 26" dia., 32" (OA) for
the 36" dia. and 42" (OA) for the
44" dia. Minimum overall hang
height is 18" (OA). Maximum
overall hang height for one-piece
stem assembly is 8' (OA). 9' to
30' (OA) stems are supplied in
multiple sections and require
field assembly. Supplied with a
swivel canopy which will
accommodate up to 45°
adjustment. pattern) - SC (Satin
Chrome) stem(s).
Finish
Standard: Matte White (MW).
Premium: Natural Aluminum
(NA) [Sustainable Design], Satin
Chrome (SC), Polished Chrome
(PC), Satin Nickel (SN), Polished
Nickel (PN), Satin Brass (SB),
Polished Brass (PB), Oxidized
Brass (OBRS), Lacquered Satin
Aluminum (SAL), Satin Copper
(SCP), Polished Copper (PCP),
Oxidized Copper (OCP), Gun
Metal (GNM) or Custom Paint
Color (CC). Regressed solid edge
(between rings) will be satin
finish with all polished finishes
with the 2TR. Custom Decorative
Metals: (Specify a Color and
Pattern) Colors - Clear (CLR),
Cabernet (CBT), Sapphire (SPE),
Sage (SGE), Brass (BRS), Copper
(CPR), Black Pearl (BPL), Slate
Green (SGN), Champagne (CMP),
Chocolate (CLE), Indigo (IDO),
Royal Blue (RBE), or Pewter
(PWR). Patterns - Coral (COL),
Seashell (SHL) or Smooth (SMT).
Note: Select a standard or
premium finish for the stem(s)
and canopy. Example: SGE (Sage
color finish) - SMT (Smooth
pattern) - SC (Satin Chrome)
stem(s) and canopy. Minimum
quantity is 5 for one
color/pattern. Contact the factory
for lead time.
Optics
Dedicated CFL lamp optics with a
"kick reflector" formed out of
94% reflective specular anodized
aluminum.Three or four
individualT6 metal halide or
halogen dedicated optic systems.
The main reflector is formed with
94% reflective specular anodized
aluminum and the upper
reflector is formed out of 94%
reflective semi-specular anodized
aluminum.
Ballast
Integral CFL electronic HPF,
multi-volt 120/277V (347V
Canada), thermally protected
with end-of-life circuitry to
accommodate the specified lamp
wattage. Metal Halide ballast is
electronic HPF, multi-volt
(120V/277V) for the specified
lamp wattage. 347V MH ballast -
contact factory.
Lamp/Socket
26" -Three (3) or six (6) 27W
(2G11) high lumen CFL lamps,
three (3) 32W (GX24q-3) or 42W
(GX24q-4) 4-pin triple CFL lamps,
or three (3) 39W or 70WT6 CDM
metal halide lamps, or three (3)
150WT4 (DC Bay) clear linear
halogen lamps. One (1) 22W
(2GX13)T5 circular lamp (bowl
illumination).
36"-Three (3) or six (6) 27W, 39W,
40W, 50W or 55W (2G11) high
lumen CFL lamps, three (3) 32W
(GX24q-3), 42W (GX24q-4) 4-pin
triple or 57W (GX24q-5) or 70W
(GX24q-6) 4-pin triple HO CFL
lamps or three (3) 39W, 70W or
150WT6 CDM metal halide
lamps or three (3)150WT4 (DC
Bay) clear linear halogen lamps.
One (1) 40W (2GX13)T5 circular
lamp (bowl illumination).
44" - Four (4) or eight (8) 27W,
39W, 40W, 50W or 55W (2G11)
high lumen CFL lamps, four (4)
57W (GX24q-5) or 70W (GX24q-
6) 4-pin triple HO CFL lamps or
four (4) 70W or 150WT6 CDM
metal halide lamps, or four (4)
150WT4 DC Bay) clear linear
halogen lamps. One (1) 40W
(2GX13)T5 circular lamp (bowl
illumination). CFL sockets
injection molded plastic. Metal
halide socket ceramic pulse-
rated, 4KV. Lamps furnished by
others.
Installation
Installation requires 1/4-20 UNC-
2A AllThread rod. AllThread
(supplied by others) through a
standard J-box to an integral
support canopy support system.
The 1/4-20 UNC-2A AllThread
rod must be attached to the
building structure to support the
fixture's weight.
Options
Dimming Ballast - Except 27W, &
DM bowl illumination as a MOD
withT5 55W only, contact factory
for ballast options (DM), Sloped
Ceiling Adaptor - Specify up to
45° (SCA),Triple Stem (3S),
Single Stem with Aircraft Cable
(1SAC), Aircraft Cable with White
SJ Cord (SJWAC), Aircraft Cable
with Clear SJ Cord (SJCAC),
Quad Pod - 44"only (QP),Tri-Pod -
26" & 36" only (TP), Hand-Painted
Faux Alabaster Bowl (FB), Hand
Painted Faux Linen Bowl (LNB),
Remote Emergency Battery
(REM), Separate Switching -
contact factory (SSW), Factory
Fuse (FF) & Quartz Restrike -
contact factory, Downlight (D),
Damp Location (DL): All Painted
Finishes, Lacquered Satin
Chrome (SCL) and Lacquered
Satin Nickel (SNL) finishes only.
Contact factory for multi-bowl
and alternative mounting
options.
DESCRIPTION
Catalog # Type
Date
Project
Comments
Prepared by
ADS051191
2008-09-19 09:20:59
New Custom
Decorative Metals Finish
SUSTAINABLE
DESIGN
Shaper has a long-standing history
of offering environmentally-friendly
fixtures. The copper and bronze alloys
used in our exterior luminaires feature
up to 98% recycled content, contribute
less undesirable air emissions compared
to painted aluminum and are easy to
recycle.
Shaper offers a line of products that
offer optically-engineered, high
performance optics for compact
fluorescent, metal halide and halogen
sources.
HIGH PERFORMANCE
OPTICS
Refer to the Icon Legend
Link on shaperlighting.com.

Specifications and dimensions subject to change without notice.
Shaper Lighting •1141 Marina Way South •Richmond, CA 94804 •ph 510.234.2370 •fax [phone]
Sample Number: 1215-TTR-26-CFL-3-27-120V-PC-26
Options
1S Single Stem=
1SAC Single Stem
Aircraft Cable
=
3S Three Stem=
SJCAC Aircraft Cable
w/ Clear SJ Cord
=
SJWAC Aircraft Cable
w/ White SJ Cord
=
DL Damp Location=
DM CFL Dimming Ballast 3
=
FF Factory Fuse=
REM Remote
Emergency Battery
=
SCA Sloped Ceiling Adapter=
SSW Separate Switching=
Finish
Standard
MW Matte White=
Premium
CC Custom Color=
NA Natural Aluminum=
OBRS Oxidized Brass=
PB Polished Brass 1
=
PC Polished Chrome 1
=
PCP Polished Copper 1
=
PN Polished Nickel 1
=
SAL Lacquered
Satin Aluminum
=
SB Satin Brass=
SC Satin Chrome=
SCL Lacquered
Satin Chrome
=
SCP Satin Copper=
SN Satin Nickel=
SNL Lacquered
Satin Nickel
=
Custom Decorative Metals
CLR Clear=
CBT Cabernet=
SPE Sapphire=
SGE Sage=
BRS Brass=
CPR Copper=
BPL Black Pearl=
SGN Slate Green=
CMP Champagne=
CLE Chocolate=
IDO Indigo=
RBE Royal Blue=
PWR Pewter=
Pattern
4COL Coral=
SHL Seashell=
SMT Smooth=
Lamp
Series
Stem and Canopy Finish 5
Standard
MW Matte White=
Premium
CC Custom Color=
NA Natural Aluminum=
OBRS Oxidized Brass=
PB Polished Brass 1
=
PC Polished Chrome 1
=
PCP Polished Copper 1
=
PN Polished Nickel 1
=
SAL Lacquered
Satin Aluminum
=
SB Satin Brass=
SC Satin Chrome=
SCP Satin Copper=
SN Satin Nickel=
Size
26"
36"
44"
Suspension Height
26'' (OA) - 26'' dia.
30'' (OA) - 36'' dia.
38'' (OA) - 44'' dia.
or Specify
Voltage
120V
277V
347V
1
Notes:
23 T5 22 & 40W - dimming ballast are
Available in 26" Only.
4
Available with Custom Decorative Metal Finish only.
5
Color
Interior applications only.
Select a standard or premium finish for the stem(s) and canopy.
Supplied by others.
LNB =Hand Painted Faux
Linen Bowl
Example: SGE (Sage color) - SMT (Smooth pattern) -
6
6
2
26"
CFL/3/27
CFL/6/27
CFL/3/32
CFL3/42
MH/3/39
MH/3/70
HAL/3/150
36"
CFL/3/27
CFL/3/39
CFL/3/40
CFL/3/50
CFL/3/55
CFL/6/27
CFL/6/39
CFL/6/40
CFL/6/50
CFL/6/55
CFL/3/32
CFL/3/42
CFL/3/57
CFL/3/70
MH/3/39
MH/3/70
MH/3/150
HAL/3/150
44"
CFL/4/27
CFL/4/39
CFL/4/40
CFL/4/50
CFL/4/55
CFL/8/27
CFL/8/39
CFL/8/40
CFL/8/50
CFL/8/55
CFL/4/57
CFL/4/70
MH/4/70
MH/4/150
HAL/4/150
not available. If bowl illumination requires dimming, contact the factory for aT5-55W MOD.
for the double trim rings stem(s) and canopy. Minimum quantity is 5 for one color/pattern. Contact the factory for lead-time.
1215-2TR
1215-TTR
ORDERING INFORMATION
Labels
U.L. and C.U.L approved for indoor and
damp location. See options for damp
location finishing requirements.
Modifications
Shaper's skilled craftspeople with their depth
of experience offer the designer the flexibility
to modify standard high performance
pendant luminaires for project-specific
solutions. Contact the factory regarding scale
options, unique finishes, mounting,
additional materials/colors, or decorative
detailing.
ADS051191
2008-09-19 09:20:59
1215-TTR SERIES HP PENDANTS
28"
53/4"
32"
42"
63/4" 83/4"
1215 - 36” TRADITIONAL
TRIM RING (TTR) STANDARD
1215 - 26” TRADITIONAL TRIM
RING (TTR) STANDARD
1215 - 44” TRADITIONAL
TRIM RING (TTR) STANDARD
DIMENSIONS

Specifications and dimensions subject to change without notice.
Consult your representative for additional options and finishes.
ADS051191
2008-09-19 09:20:59
1215-TTR SERIES HP PENDANTS
28"
5-3/4"
42"
8-3/4"
28"
5-3/4"
28"
5-3/4"
28"
5-3/4"
1215-TTR - SUSPENSION OPTIONS STANDARD
SUSPENSION OPTIONS
Triple Stem (3S): 5" canopy with a 1 1/2" swivel ball. One 5/8" stem with a standard hang height of 24" (OA), minimum 18" (OA).
Maximum overall hang height for one piece stem assembly is 5' (OA). For 8' to 30' (OA) the stems are supplied in multiple sections.
Specify SCA for sloped ceilings up to 45°.
Single Stem Aircraft Cable (1SAC):Three or four 3/8" stems with a standard hang height of 24" (OA), minimum 18" (OA). Maximum
overall hang height is 8' (OA). Contact factory for lengths above 8'. Specify SCA for sloped ceilings up to 45°.
Aircraft Cable with SJ Cord (SJAC): One 5/8" stem and 3/32" cables with a standard hang height of 24" (OA), minimum 18" (OA).
Tri-Pod (TP): 3/32" cables with a standard hang height of 24" (OA), minimum 18" (OA). Maximum overall hang height is 25' (OA).
Contact factory for lengths above 25'. Specify SCA for sloped ceilings up to 45°. 26" & 36" dia. only.
Quad-Pod (QP): 3/32" cables with a standard hang height of 24" (OA), minimum 18" (OA). Maximum overall hang height is 25' (OA).
Contact factory for lengths above 25'. Specify SCA for sloped ceilings up to 45°. 44" dia. only.
1215-TTR - SUSPENSION OPTIONS STANDARD
1215-TTR 1215-TTR
1215-TTR QUAD-POD (QP) - 44"
1215-TTR SINGLE STEM
AIRCRAFT CABLE (1SAC)
1215-TTR AIRCRAFT
CABLE SJ CORD (SJAC)
INSTALLATION
Contractor to provide appropriate structural support for fixture weight. Refer to the installation drawings for details. Integral safety
cable provided. Refer to specification sheets at shaperlighting.com for additional and/or enlarged luminaire drawings.
TRIPLE STEM (3S) TRI-POD (TP) - 26" & 36"
1215-TTR - SUSPENSION OPTIONS STANDARD

293494-S
610 648-4648 649
693-4-S693 693-S
Specifications and dimensions subject to change without notice.
Consult your representative for additional options and finishes.
HIGH LUMEN CF TRIPLE/HEX HO CF T6 MH/HAL
44"
36"
26"
44"
36"
26"
44"
36"
26"
1215-TTR - OPTIC DRAWINGS STANDARD
ADS051191
2008-09-19 09:20:59
1215-TTR SERIES HP PENDANTS
1215-TTR - DOUBLETRIM RING
1215-TTR - PLAN VIEW STANDARD
COMPANION PRODUCTS
