Cooper Lighting Shaper 1220-TTR SERIES User manual

1220-TTR SERIES
High Performance
Pendant Luminaire
Indirect/Direct
Deep Bowl with
Two Trim Options
Specifications and dimensions subject to change without notice.
Consult your representative for additional options and finishes.
shaperlighting.com
The 1220 Deep Bowl Direct/Indirect High Performance Luminous
Pendant features aTraditionalTrim Ring (TTR) or a DoubleTrim Ring
(2TR) and is available in three diameters with multiple mounting
options.
SPECIFICATION FEATURES
Material/Mounting
Painted and plated cold rolled
steel or natural aluminum with a
matte acrylic bowl.
Single Stem (Standard): 5/8"
stem with a standard hang
height of 30" (OA) for the 26"
dia., 36" (OA) for the 36" dia. and
46" (OA) for the 44" dia.
Minimum overall hang height is
24" (OA). Maximum overall hang
height for one piece stem
assembly is 8' (OA). 9' to 30' (OA)
stems are supplied in multiple
sections and require field
assembly. Supplied with a swivel
canopy which will accommodate
up to 45° adjustment.
Finish
Standard: Matte White (MW).
Premium: Unlacquered Natural
Aluminum (NA) [Sustainable
Design], Satin Chrome (SC),
Polished Chrome (PC), Satin
Nickel (SN), Polished Nickel (PN),
Satin Brass (SB), Polished Brass
(PB), Oxidized Brass (OBRS),
Lacquered Satin Aluminum
(SAL), Satin Copper (SCP),
Polished Copper (PCP), Oxidized
Copper (OCP), Gun Metal (GNM)
or Custom Paint Color (CC).
Regressed solid edge (between
rings) will be satin finish with all
polished finishes with the 2TR.
Custom Decorative Metals:
(Specify a Color and Pattern)
Colors - Clear (CLR), Cabernet
(CBT), Sapphire (SPE), Sage
(SGE), Brass (BRS), Copper
(CPR), Black Pearl (BPL), Slate
Green (SGN), Champagne (CMP),
Chocolate (CLE), Indigo (IDO),
Royal Blue (RBE), or Pewter
(PWR). Patterns - Coral (COL),
Seashell (SHL) or Smooth (SMT).
Note: Select a standard or
premium finish for the stem(s)
and canopy. Example: SGE (Sage
color finish) - SMT (Smooth
pattern) - SC (Satin Chrome)
stem(s) and canopy. Minimum
quantity is 5 for one
color/pattern. Contact the factory
for lead time.
Optics
Refer to
www.shaperlighting.com for
complete photometrics.
Ballast
Integral CFL electronic HPF,
multi-volt 120/277V (347V
Canada), thermally protected
with end-of-life circuitry to
accommodate the specific lamp
wattage. Metal Halide ballast is
electronic HPF, multi-volt
(120V/277V) for the specified
lamp wattage. 347V MH ballast -
contact factory.
Lamp/Socket
26" -Three (3) or six (6) 27W
(2G11) 4-pin high lumen CFL
lamps, three (3) 32W (GX24q-3)
or 42W (GX24q-4) 4-pin triple,
60W (2G8) 4-pin triple HO CFL
lamps, three (3) 39W or 70WT6
CDM metal halide lamps or three
(3) 150WT4 (DC Bay) clear linear
halogen lamps. One (1) 22W
(2GX13)T5 circular lamp (bowl
illumination). 36" -Three (3) or
six (6) 27W, 39W, 40W, 50W, or
55W (2G11) 4-pin high lumen CFL
lamps, three (3) 42W (GX24q-4)
4-pin triple or 57W (GX24q-5),
60W (2G8), 70W (GX24q-6), 85W
(2G8) or 120W (2G8) 4-pin triple
HO CFL lamps or three (3) 39W,
70W or 150WT6 CDM metal
halide lamps or three (3) 150WT4
(DC Bay) clear linear halogen
lamps. One (1) 40W (2GX13)T5
circular lamp (bowl illumination).
44" - Four (4) or (8) 27W, 39W,
40W, 50W or 55W (2G11) high
lumen CFL lamps, four (4) 57W
(GX24q-5), 70W (GX24q-6), 4-pin
triple HO CFL lamps, four (4)
70W or 150WT6 CDM metal
halide lamps, one (1) 175W (ED-
17), 250W (ED-28) or 400W
(ED-28) metal halide lamp or four
(4) 150WT4 (DC Bay) clear linear
halogen lamps. One (1) 40W
(2GX13)T5 circular lamp (bowl
illumination). CFL sockets
injection molded plastic. Metal
halide socket ceramic pulse-
rated, 4KV. Lamps furnished by
others.
Installation
Installation requires 1/4-20 UNC-
2A AllThread rod. All Thread
(supplied by others) through a
standard J-box to an integral
support canopy support system.
The 1/4-20 UNC-2A AllThread
rod must be attached to the
building structure to support the
fixture's weight.
Options
Dimming Ballast - Except 27W,
contact factory for ballast
options (DM), Sloped Ceiling
Adaptor - Specify up to 45
degrees (SCA),Triple Stem (3S),
Single Stem with Aircraft Cable
(1SAC), Aircraft Cable with White
SJ Cord (SJWAC), Aircraft Cable
with Clear SJ Cord (SJCAC),
Quad Pod - 44" only (QP),Tri-Pod
- 26" and 36" only (TP), Hand
Painted Faux Alabaster Bowl
(FB), Remote Emergency Battery
(REM) consult factory, Separate
Switching (SSW), Factory Fuse
(FF), Downlight (D) - contact
factory. Contact factory for Multi-
bowl and alternative mounting
options.
Labels
U.L. and C.U.L. listed.
Modifications
Shaper's skilled craftspeople
with their depth of experience
offer the designer the flexibility
to modify standard high
performance pendant luminaires
for project specific solutions.
Contact the factory.
DESCRIPTION
Catalog # Type
Date
Project
Comments
Prepared by
ADS051193
2008-09-10 12:49:48
SUSTAINABLE
DESIGN
Shaper has a long-standing history
of offering environmentally-friendly
fixtures. The copper and bronze alloys
used in our exterior luminaires feature
up to 98% recycled content, contribute
less undesirable air emissions compared
to painted aluminum and are easy to
recycle.
Shaper offers a line of products that
offer optically-engineered, high
performance optics for compact
fluorescent, metal halide and halogen
sources.
HIGH PERFORMANCE
OPTICS
Refer to the Icon Legend
Link on shaperlighting.com.
New Custom
Decorative Metals Finish

Specifications and dimensions subject to change without notice.
Shaper Lighting •1141 Marina Way South •Richmond, CA 94804 •ph 510.234.2370 •fax [phone]
Sample Number: 1220-TTR-44-CFL/4/57 + T5/1/40-120V-SN-REM-46
Lamp (Bowl)
T5/1/22 1, 2
T5/1/40 3
Pattern 2
COL Coral=
SHL Seashell=
SMT Smooth=
Finish
Standard
MW Matte White=
Premium
CC Custom Color=
NA Natural Aluminum=
OBRS Oxidized Brass=
PB Polished Brass=
PC Polished Chrome=
PCP Polished Copper=
PN Polished Nickel=
SAL Lacquered Satin
Aluminum
=
SB Satin Brass=
SC Satin Chrome=
SCL Lacquered
Satin Chrome
=
SCP Satin Copper=
SN Satin Nickel=
SNL Lacquered
Satin Nickel
=
Custom Decorative
Metals
CLR Clear=
CBT Cabernet=
SPE Sapphire=
SGE Sage=
BRS Brass=
CPR Copper=
BPL Black Pearl=
SGN Slate Green=
CMP Champagne=
CLE Chocolate=
IDO Indigo=
RBE Royal Blue=
PWR Pewter=
Series
1220-2TR
1220-TTR
Options
1SAC Single Stem
Aircraft Cable
=
3S Three Stem=
QP Quad-Pod=
SJCAC Aircraft Cable w/
Clear SJ Cord
=
SJWAC Aircraft Cable w/
White SJ Cord
=
TP Tri-Pod 1
=
DDownlight=
DL Damp Location=
DM CFL Dimming Ballast 3
=
FF Factory Fuse=
REM Remote Emergency
Battery
=
SCA Sloped Ceiling Adapter=
SSW Separate Switching=
FB Hand Painted Faux
Alabaster Bowl
=
Size
26"
36"
44"
Voltage
120V
277V
347V
Stem and Canopy Finish 5
Standard
MW Matte White=
Premium
CC Custom Color=
NA Natural Aluminum=
OBRS Oxidized Brass=
PB Polished Brass=
PC Polished Chrome=
PCP Polished Copper=
PN Polished Nickel=
SAL Lacquered Satin
Aluminum
=
SB Satin Brass=
SC Satin Chrome=
SCP Satin Copper=
SN Satin Nickel=
Suspension Height
30'' (OA) - 26'' dia.
36'' (OA) - 36'' dia.
46'' (OA) - 44' dia.
or Specify
Notes:
Lamp
26”
CFL/3/27
CFL/3/32
CFL/3/42
CFL/6/27
MH/3/39
MH/3/70
HAL/3/150
36”
CFL/3/27
CFL/3/32
CFL/3/39
CFL/3/40
CFL/3/42
CFL/3/50
CFL/3/55
CFL/3/57
CFL/3/70
CFL/6/27
CFL/6/39
CFL/6/40
CFL/6/50
CFL/6/55
MH/3/39
MH/3/70
MH/3/150
HAL/3/150
CFL/4/27
CFL/4/39
CFL/4/40
CFL/4/50
CFL/4/55
CFL/4/57
CFL/4/70
CFL/8/27
CFL/8/39
CFL/8/40
CFL/8/50
CFL/8/55
MH/4/70
MH/4/150
HAL/4/150
44”
6
1
1
1
1
1
1
1
1
4
123 T5 22 & 40W - dimming ballast are
Available in 26" Only.
4
Available with Custom Decorative Metal Finish only.
5
Interior applications only.
Select a standard or premium finish for the stem(s) and canopy.
Supplied by others.
Example: SGE (Sage color) - SMT (Smooth pattern) -
6
not available. If bowl illumination requires dimming, contact the factory for aT5-55W MOD.
for the double trim rings stem(s) and canopy. Minimum quantity is 5 for one color/pattern. Contact the factory for lead-time.
ORDERING INFORMATION
ADS051193
2008-09-10 12:49:48
30"
10-1/2"
36"
13-1/2"
46"
16-1/2"
1220 - 26"TRADITIONAL 1220 - 36"TRADITIONAL 1220 - 44"TRADITIONAL
TRIM RING (TTR)
TRIM RING (TTR)TRIM RING (TTR)
DIMENSIONS
1220-TTR SERIES HP PENDANT

Specifications and dimensions subject to change without notice.
Consult your representative for additional options and finishes.
46"
16-1/2"
30"
10-1/2"
30"
10-1/2"
30"
10-1/2"
30"
10-1/2"
1220-TTR - SUSPENSION OPTIONS STANDARD
1220-TTR - TRIPLE STEM (3S) 1220-TTR - TRI-POD
HANGER - 26" & 36" (TP)
1220-TTR - QUAD-POD
HANGER - 44” (QP)
1220-TTR - AIRCRAFT CABLE
WITH SJ CORD (SJAC)
1220-TTR - SINGLE STEM
AIRCRAFT CABLE (1SAC)
Triple Stem (3S): stem with a standard hang height of 24" (OA), minimum 18" (OA). Maximum overall hang height
for one piece stem assembly is 5' (OA). Lengths from 5' to 25' a collector SCA for sloped ceilings up to 45°.
Single Stem Aircraft Cable (1SAC): standard hang height of 24" (OA), minimum 18" (OA). Maximum overall
hang height is 8' (OA). Contact factory for lengths above 8'. Specify SCA for sloped ceilings up to 45°.
Aircraft Cable with a White SJ Cord (SJWAC): 3/32" cables with a standard hang height of 24" (OA), minimum
18" (OA). Optional clear SJ cord (SJCAC).
Tri-Pod (TP): 3/32" cables with a standard hang height of 24" (OA), minimum 18" (OA). Maximum overall hang
height is 25' (OA). Contact factory for lengths above 25'. Specify SCA for sloped ceilings up to 45°. 26" & 36" dia. only.
Quad-Pod (QP): minimum 18" (OA). Maximum overall hang height is 25' (OA). Contact factory for lengths above 25'.
Specify SCA for sloped ceilings up to 45°. 44" dia. only.
Contractor to provide appropriate structural support for fixture weight. Refer to the installation drawings for details.
Integral safety cable provided (1SAC).
INSTALLATION
SUSPENSION OPTIONS
1220-TTR - SUSPENSION OPTIONS STANDARD 1220-TTR SERIES HP PENDANT
ADS051193
2008-09-10 12:49:48

Specifications and dimensions subject to change without notice.
Consult your representative for additional options and finishes.
293494-S
610 648-4648 649
693-4-S693 693-S
COMPANION PRODUCTS
HIGH LUMEN CFL TRIPLE/HEX HO CFL T6 MH/HAL STANDARD MH
44"
36"
26"
44"
36"
26"
44"
36"
26"
44"
1220-TTR - OPTIC DRAWINGS STANDARD
1220-TTR - TRADITIONALTRIM
1220-TTR - PLAN VIEW STANDARD
