Cooper Lighting Shaper 260-A SERIES User manual

260-A SERIES
Surface Luminaire
Starter Collection
Luminous Cylinder
Specifications and dimensions subject to change without notice.
Consult your representative for additional options and finishes.
shaperlighting.com
Catalog # Type
Date
Project
Comments
Prepared by
260-A Luminous Cylinder features a direct downlight component.
SPECIFICATION FEATURES
Material
Solid aluminum with a matte
white acrylic cylinder.
Finish
Standard: Natural Aluminum
(NA) [Sustainable Design].
Premium: Matte White (MW),
Lacquered Satin Aluminum
(SAL), Clear Anodized Aluminum
(CAL) or Custom Color (CC).
Optics
Refer to
www.shaperlighting.com for
complete photometrics.
Ballast
Integral electronic HPF, multi-volt
120/277V (347V Canada),
thermally protected with end-of-
life circuitry to accommodate the
specified lamp wattage.
Lamp/Socket
One (1) 18W (GX24q-2) or 26W
(GX24q-3) 4-pin triple CFL lamp
or 75W A-19 lamp. CFL socket
injection molded plastic. INC
socket fired ceramic rated for
660W-250V. Lamps furnished by
others.
Installation
Supplied with a universal
circular strap for a standard 4"
J-box or plaster ring.
Options
Damp Location (DL): All Painted
Finishes only, Perforated Band
(PFB), Remote Emergency Ballast
- Supplied by others (REM), MRI
applications, (INC only) - Contact
factory. Energy Star Rating-
Consult Factory.
Labels
U.L. and C.U.L. approved for
indoor and damp location. See
options for damp location
finishing requirements.
Modifications
Shaper's skilled craftspeople
with their depth of experience
offer the designer the flexibility
to modify standard surface
luminaires for project specific
solutions. Contact the factory
regarding scale options, unique
finishes, mounting, additional
materials/colors, or decorative
detailing.
DESCRIPTION
MAGNETIC
RESONANCE
IMAGING (MRI)
ENERGY
STAR
SUSTAINABLE
DESIGN
Refer to the Icon Legend
Link on shaperlighting.com.
Lighting fixtures for MRI facilities are
specialized and unique, requiring non-
ferrous construction. Fluorescent fixtures
cannot be used due to the ferrous parts in
ballasts and lampholders. Modified incan-
descent fixtures meet the requirements.
Shaper now offers a wide variety
of fixtures that can be provided
with an Energy Star Rating.
Shaper has a long-standing history of
offering environmentally-friendly fixtures.
The copper and bronze alloys used in our
exterior luminaires feature up to 98% re-
cycled content, contribute less undesirable
air emissions compared to painted alumi-
num and are easy to recycle.
Shaper’s exclusive Starter Collection fixtures
are featured throughout the Shaper product
line. The concept of offering highly styled,
affordable fixtures was introduced over
fourteen years ago and has become one of
our fastest growing lines. The design
premise, basic construction, clean lines
and unadorned shapes are highly desirable
in modern architectural environments.
STARTER
COLLECTION
Shaper’s Quick Ship program
features over thirty-four fixtures
with finish options such as Satin
Chrome, Natural Aluminum and
Satin Brass and a wide variety of
lamp selections. All products ship
in five days from receipt of order.
QUICK SHIP (QS)
ADS042711
2008-09-04 09:49:44
Sample Number: 260-A-CFL/1/18-277V-CAL
Finish
Standard
NA Natural Aluminum=
Premium
CAL Clear Anodized
Aluminum
=
CC Custom Color=
MW Matte White=
SAL Lacquered Satin
Aluminum
=
Options
DL Damp Location=
REM Remote
Emergency
Battery 2
3
=
PFB Perforated Band=
Voltage
120V
277V 1
347V 1
Series
260-A Cylinder Surface=
Lamp
CFL/1/18
CFL/1/26
INC/1/75
1Available with CFL only.
Notes:
2S
3Interior applications only.
upplied by others.
ORDERING INFORMATION

Specifications and dimensions subject to change without notice.
Shaper Lighting •1141 Marina Way South •Richmond, CA 94804 •ph 510.234.2370 •fax [phone]
260 461-A461 652 653
COMPANION PRODUCTS
260-A SERIES SURFACE LUMINAIRE
9"
10-1/2"
5" ø
260-A STANDARD
6" ø
PERF BAND (PFB)
260-A OPTION
DIMENSIONS
