COOPER LIGHTING
PDS
by Portfolio™
• Low iridescent, clear reflector
• White painted self flange
• Torsion springs pull reflector
to ceiling
• One piece folded metal
socket cap
• Universal voltage ballast
• 120V & 277V Advance Mark
10 dimming
• Universal 4-pin socket
• Galvanized steel frame with
1/2” plaster lip
• Accommodates ceilings up
to 2” thick
• Bar hangers lock to T-bar
with screwdrivers or pliers
• Galvanized J-box with
multiple KO’s, listed for
twelve #12AWG 90C
conductors
• cUL listed
• “EM” fixtures use internally
mounted test
switch/indicator light
PD8
Open/Lens/Louver
Horizontal
CFL
HORIZONTAL 8" OPEN, CFL
Top View
Turbo Louver
Dimensions Length Width Height Cutout
Standard Housing 18-1/8" 13-1/2" 6-3/8" 9"
EM Housing 18-1/8" 13" 6-3/8"
Dimensions Length Width Height Cutout
Standard Housing 18-1/8" 13-1/2" 5-7/8" 9"
EM Housing 18-1/8" 13" 5-7/8"
HORIZONTAL 8" LOUVER, CFL
HORIZONTAL 8" LENS, CFL
8
8
8
HW142EEM=1-26/32/42W TTT or 1-26W DTT
HW242EEM=2-26/32/42W TTT or 1-26W DTT
8HEMC=8" Horizontal Clear
8HEMBB=8" Horizontal Black Baffle
8HEMWB=8" Horizontal White Baffle
PD8
Frame Socket Adapter/Battery Pack Reflector
Example: PD8 HW142EEM 8HEMBB
HW142=1-26/32/42W TTT
or 1-26W DTT
HW242=2-26/32/42W TTT
or 2-26W DTT
E=120-277V, 50/60Hz Electronic Ballast
3E=347V, 60Hz Electronic Ballast
1D=120V Dimming, Advance Mark 10
2D=277V Dimming, Advance Mark 10
1D26=120V Dimming, Advance Mark 10*
2D26=277V Dimming, Advance Mark 10*
8HC=8" Horizontal Clear
8HBB=8" Horizontal Black Baffle
8HWB=8" Horizontal White Baffle
PD8
STANDARD (Frame, socket adapter and reflector ship separately.)
Frame Socket Adapter Reflector
Example: PD8 HW1421D 8HC
HW142=1-26/32/42W TTT
or 1-26W DTT
HW242=2-26/32/42W TTT
or 1-26W DTT
E=120-277V, 50/60Hz Electronic Ballast
3E=347V, 60Hz Electronic Ballast
1D=120V Dimming, Advance Mark 10
2D=277V Dimming, Advance Mark 10
1D26=120V Dimming, Advance Mark 10*
2D26=277V Dimming, Advance Mark 10*
8HRC =8" Turbo Reflector
PD8
STANDARD (Frame, socket adapter and reflector ship separately.)
Frame Socket Adapter Reflector
Example: PD8 HW1421D 8HRC
EMERGENCY (Frame and socket adapter/battery pack ship together. Reflector ships separately.)
HLW242EEM=2-26/32/42W
TTT or 1-26W DTT
8HL1EMC=8" Horizontal Prismatic Acrylic
Lens, Clear
8HL1EMBB=8" Horizontal Prismatic
Acrylic Lens, Black Baffle
8HL1EMWB=8" Horizontal Prismatic
Acrylic Lens, White Baffle
8HL2EMC=8" Horizontal Prismatic Glass
Lens, Clear
8HL2EMBB=8" Horizontal Prismatic Glass
Lens, Black Baffle
8HL2EMWB=8" Horizontal Prismatic
Glass Lens, White Baffle
8HL4EMC=8" Horizontal Glass Fresnel
Lens, Clear
8HL4EMBB=8" Horizontal Glass Fresnel
Lens, Black Baffle
8HL4EMWB=8" Horizontal Glass Fresnel
Lens, White Baffle
8HREMC=8" Radial Louver, Clear
PD8=(Wet
Location
Listed)
Frame Socket Adapter/Battery Pack Reflector
Example: PD8 HW242EEM 8HL4EMBB
HW142=
1-26/32/42W TTT
or 1-26W DTT
HW242=
2-26/32/42W TTT
or 1-26W DTT
E=120-277V, 50/60Hz Electronic Ballast
3E=347V, 60Hz Electronic Ballast
1D=120V Dimming, Advance Mark 10
2D=277V Dimming, Advance Mark 10
1D26=120V Dimming, Advance Mark 10*
2D26=277V Dimming, Advance Mark 10*
8HL1C=8" Prismatic Acrylic Lens with Clear Reflector
8HL1BB=8" Prismatic Acrylic Lens with Black Baffle
8HL1WB=8" Prismatic Acrylic Lens with White Baffle
8HL2C=8" Prismatic Glass Lens with Clear Reflector
8HL2BB=8" Prismatic Glass Lens with Black Baffle
8HL2WB=8" Prismatic Glass Lens with White Baffle
8HL4C=8"Fresnel Lens with Clear Reflector
8HL4BB=8"Fresnel Lens with Black Baffle
8HL4WB=8"Fresnel Lens with White Baffle
PD8=(Wet
Location
Listed)
STANDARD (Frame, socket adapter and reflector ship separately.)
Frame Socket Adapter Reflector
Example: PD8 HW1423E 8HL1C
EMERGENCY (Frame and socket adapter/battery pack ship together. Reflector ships separately.)
Other Standard, Dimming
and EM ballasts available.
Consult factory.
*1D26, 2D26 Only necessary with a 2-26 DTT. For every other configuration specify 1D or 2D.
Other Standard, Dimming and EM
ballasts available. Consult factory.
Other Standard, Dimming and EM ballasts available.
Consult factory.
W
E
T
L
O
C
A
T
I
O
N
Aperture: 8 1/2"; Cutout: 9"; OD: 9 7/8"
