248 SERIES
Surface Luminaire
Luminous Bowl with Trim
Specifications and dimensions subject to change without notice.
Consult your representative for additional options and finishes.
shaperlighting.com
248 Luminous Bowl features a decorative trim, two bowl depths and
is available in two sizes.
SPECIFICATION FEATURES
Material
Cold rolled steel trim and
mounting pan with a matte white
acrylic Elliptical (EL) or Deep
Bowl (DB).
Finish (Trim and Mounting
Pan)
Standard: Matte White (MW).
Premium: Satin Chrome (SC),
Polished Chrome (PC), Satin
Brass (SB), Polished Brass (PB),
Satin Copper (SCP), Polished
Copper (PCP), Satin Nickel (SN),
Polished Nickel (PN), Satin Nickel
(SN), Oxidized Brass (OBRS),
Lacquered Satin Chrome (SCL),
Lacquered Satin Nickel (SNL) or
Custom Color (CC).
Optics
Refer to
www.shaperlighting.com for
complete photometrics.
Ballast
Integral electronic HPF, multi-volt
120/277V (347V Canada),
thermally protected with end-of-
life circuitry to accommodate the
specified lamp wattage.
Lamp/Socket
16":Two (2) 13W (2GX7) 4-pin
low wattage CFL lamps, two (2)
26W (G24q-3) 4-pin quad CFL
lamps or two (2) 40W A-19
incandescent lamps.
20":Two (2) 26W (G24q-3) 4-pin
quad CFL lamps, four (4) 27W
(2G11) 4-pin high lumen CFL
lamps or two (2) 60W A-19
incandescent lamps. CFL socket
injection molded plastic. INC
socket fired ceramic rated for
660W-250V. Lamps furnished by
others.
Installation
Supplied with a universal
circular strap for a standard 4"
J-box or plaster ring.
Options
Hand Painted Faux Alabaster
Bowl (FB), Hand Painted Faux
Linen Bowl (LNB), CFL Dimming
Ballast - (26W only) Contact the
factory for ballast options (DM),
Traditional Finial (TF), Integral
Emergency Battery - (20") (IEM),
Modified Integral Battery - (16")
(MEM), Damp Location (DL): All
Painted Finishes, Lacquered
Satin Chrome (SCL) and
Lacquered Satin Nickel (SNL)
finishes only. MRI Applications
(INC only) - Contact Factory.
Energy Star Rating - Consult
Factory.
Labels
U.L. and C.U.L. approved for
indoor and damp location. See
options for damp location
finishing requirements.
Modifications
Shaper's skilled craftspeople
with their depth of experience
offer the designer the flexibility
to modify standard surface
luminaires for project specific
solutions. Contact the factory
regarding scale options, unique
finishes, mounting, additional
materials/colors, or decorative
detailing.
DESCRIPTION
Catalog # Type
Date
Project
Comments
Prepared by
ENERGY
STAR
Refer to the Icon Legend
Link on shaperlighting.com.
Shaper now offers a wide variety
of fixtures that can be provided
with an Energy Star Rating.
QUICK
SHIP
(QS)
MAGNETIC
RESONANCE
IMAGING (MRI)
Lighting fixtures for MRI facilities are
specialized and unique, requiring non-
ferrous construction. Fluorescent fixtures
cannot be used due to the ferrous parts in
ballasts and lampholders. Modified incan-
descent fixtures meet the requirements.
Shaper’s Quick Ship program features
over thirty-four fixtures with finish
options such as Satin Chrome, Natural
Aluminum and Satin Brass, and a wide
variety of lamp selections. All products
ship in five days from receipt of order.
ADS042710
2008-09-03 08:26:48
Sample Number: 248-DB-16-CFL/2/26-277V-PCP
Voltage
120V
277V
347V
Finish
Standard
MW Matte White=
Premium
CC Custom Color=
OBRS Oxidized Brass=
PB Polished Brass=
PC Polished Chrome=
PCP Polished Copper=
PN Polished Nickel=
SB Satin Brass=
SC Satin Chrome=
SCL Lacquered Satin
Chrome
=
SCP Satin Copper=
SN Satin Nickel=
SNL Lacquered Satin Nickel=
Options
DL Damp Location=
DM CFL Dimming
Ballast 3, 4, 5
6
=
IEM Integral
Emergency
Ballast 2
=
MEM Modified
Integral
Emergency
Battery 1
=
FB Hand Painted
Faux Alabaster
Bowl
=
TF Traditional
Finial
=
LNB Hand Painted
Faux Linen Bowl
=
Lamp
CFL/2/13 1
1
CFL/2/26
CFL/4/27
INC/2/40
INC/2/60
2
2
Series
248 Bowl Surface
w/ Trim Ring
=
Bowl
EL Elliptical=
DB Deep Bowl=
Size
16"
20"
1Available in 16".
Notes:
2Available in 20".
3Not available in 13W.
4Not available in 27W.
5C
6Interior applications only.
onsult the factory for available options.
ORDERING INFORMATION

Specifications and dimensions subject to change without notice.
Shaper Lighting •1141 Marina Way South •Richmond, CA 94804 •ph 510.234.2370 •fax [phone]
COMPANION PRODUCTS
445-RP 449 648
TRADITIONAL
FINIAL (TF)
MODIFIED INTEGRAL
EMERGENCY BATTERY (MEM)
5-3/8"
248 - 20" ø ELLIPTICAL
BOWL (EL) STANDARD
248 TRIM OPTIONS
19-3/8" ø
4-3/4"
248 - 16" ø ELLIPTICAL
BOWL (EL) STANDARD
8-3/8"
248 - 20" ø DEEP
BOWL (DB) STANDARD
19-3/8" ø
6-5/8"
248 - 16" ø DEEP
BOWL (DB) STANDARD
12-3/4" ø
20-1/2" ø 18" ø
16" ø 13" ø
4-1/4"
2-5/8"
6 7/8"
19-3/8" ø
DIMENSIONS
ADS042710
2008-09-03 08:26:48
248 SERIES SURFACE LUMINAIRE
