Cooper Lighting Shaper 695-WP-DB Series User manual

EXTERIOR WALL
998
SHAPER™
COOPER LIGHTING
MATERIAL
Cast aluminum
construction with clear
tempered refractive glass
for MH incandescent or
1/8" white acrylic for
incandescent and CFL
lamps. Optional clear
tempered glass for full
cut-off.
Notes:
1 CFL and MH only.
2 Available with CFL only.
3 Premium TGIC polyester powder coat paint, 2.5 mil nominal thickness for superior protection against fade and wear.
4 MH only.
BALLAST
Integral electronic HPF,
multi-volt 120/277V (347V
Canada), thermally
protected with end-of-life
circuitry to accommodate
the specified lamp
wattage. Metal halide
ballasts are electronic
HPF, multi-volt 120/277V
for the specified lamp
wattage. 347V ballasts for
metal halide - Contact
factory.
LAMP/SOCKET
One (1) 26W, 32W
(GX24q-3) or 42W
(GX24q-4) 4-pin triple
tube CFL lamp or one (1)
50W, 70W or 100W ED-17
metal halide lamp or
one (1) 100W A-19 lamp.
CFL socket injection
molded plastic. INC
socket fired ceramic
rated for 660W-250V.
Metal halide socket
ceramic pulse-rated,
4KV. Lamps furnished
by others.
INSTALLATION
Supplied with a mounting
back for a standard 4"
J-box or stucco ring.
Optional rear (through
wall) feed conduit
mounting.
FINISH AND OPTIONS
See page 1020 for finish
details and options.
The 697-WP features a compact cast
Aluminum Hood Downlight.
697-WP SERIES
INC, CFL & MH
8"
6-3/8"
INC & CFL MH
6-3/8"
9"
R4" 6"
4-3/8"
12-7/8"
9"
R4"
6"
4-3/8"
14-1/2"
Sample Number: 697-WP-INC/1/100-120V-GM
Series
697-WP =
Hood Downlight
Lamp
CFL/1 (26/32/42W-Triple)
INC/1/100
MH/1/50
MH/1/70
MH/1/100
Voltage
120V
277V1
347V2
Finish3
BK, WH (standard),
BM, CC, DP, GM,
GRM, GY, SM
MATERIAL
Solid bronze construction
with a clear textured
refractive glass lense
for MH or white acrylic
lense for incandescent
and CFL lamps.
Notes:
1 CFL and MH only.
2 Available with CFL only.
3 Premium TGIC polyester powder coat paint, 2.5 mil nominal thickness for superior protection against fade and wear.
4 Bronze will weather to a dark bronze patina.
5 MH only.
BALLAST
Integral electronic HPF,
multi-volt 120/277V (347V
Canada), thermally
protected with end-of-life
circuitry to accommodate
specified lamp wattage.
Integral metal halide
ballast is electronic HPF,
multi-volt 120/277V for the
specified lamp wattage.
347V ballast for metal
halide - Contact factory.
LAMP/SOCKET
One (1) 26W, 32W
(GX24q-3) or 42W
(GX24q-4) 4-pin triple
tube CFL lamp or one (1)
60W A-19 lamp. CFL
socket injection molded
plastic. INC socket fired
ceramic rated for 660W-
250V. Metal halide
is ceramic pulse-rated,
4KV. Lamps furnished by
others.
INSTALLATION
Supplied with a universal
mounting back for a
standard 4" J-box or
plaster ring. Optional rear
(through wall) feed
conduit mounting.
FINISH AND OPTIONS
See page 1020 for finish
details and options.
695-WP Half Pyramid with Direct
Illumination and a Back Panel.
695-WP-DB
SERIES
20"
18" 9"
10"
1'-8"
Sample Number: 695-WP-DB-MH/1/70-277V-GM
Series
695-WP-DB =
Half Pyramid w/
Back Panel
Lamp
CFL/1 (26/32/42W-Triple)
INC/1/60
MH/1/50
MH/1/70
MH/1/100
Voltage
120V
277V1
347V2
Finish3, 4
NBZ (standard),
BK, BM, CC, DP,
GM, GRM, GY,
SCL, SM, WH
Options
C
PH
QR5
Options
C
QR4
TGL4
PH
