828 COOPER LIGHTING
PORTFOLIO™
HOUSING
C8518=(2) 18W DTT Lamp
C8526=(2) 26W DTT Lamp
OPTIONS
CP=Chicago Plenum
2C=(2) Ballasts for Hi-Low
Switching*
2CMS=2 Circuit Master
Satellite (2 housings,
order 2 trims)*
EM =Emergency module
with remote test switch
ACCESSORIES
FK5=Field Installed Fuse Kit, 5 Amp
BALLAST
E=120V - 277V 50/60 Hz
Electronic
3E=347V 50/60 Hz
Electronic
1D=120V Dimming,
Lutron®Compact SE
2D=277V Dimming,
Lutron®Compact SE
Shallow Plenum downlight
utilizes two horizontally
mounted compact fluorescent
lamps. Accommodates
various reflector types.
8" Horizontal Lamp, Shallow
2-18 DTT
2-26 DTT
TRIM
Ordering Example
Housing, Trim, Accessories and Lamps ordered as separate line items.
Housing Trim Accessories
C8518E 8551LI HB26
Cross Blade
Downlight
Cross Blade
Wall Wash
Lens Downlight TRIM
8581=Self Flanged
FINISH
LI=Low Iridescent Clear
H=Haze
G=Gold
WH=Wheat
WMH=Warm Haze
W=Gloss White
GP=Graphite
GPH=Graphite Haze
K=Cognac
KH=Cognac Haze
BB=Black Baffle
WB=White Baffle
OPTIONS
WF=White
Painted Flange
(Self Flanged
only)
OPTIONS
WF=White
Painted Flange
(Self Flanged
only)
LENS
1=Prismatic Acrylic
2=Diffuse Acrylic
3=Clear Polycarbonate
1G=Prismatic Glass
2G=Diffuse Glass
3G=Clear Glass
4G=Fresnel Glass
8"
8-3/8"
9-3/4"
8-3/8"
9-3/4"
8-3/8"
9-3/4"
TRIM
8551=Self Flanged
8552=Self Flanged, White
FINISH
LI=Low Iridescent Clear
H=Haze
WMH=Warm Haze
G=Gold
WH=Wheat
W=Gloss White
GP=Graphite
GPH=Graphite Haze
K=Cognac
KH=Cognac Haze
TRIM
8511=Self Flanged
FINISH
LI=Low Iridescent Clear
H=Haze
WMH=Warm Haze
G=Gold
WH=Wheat
W=Gloss White
GP=Graphite
GPH=Graphite Haze
K=Cognac
KH=Cognac Haze
Dimensions Length Width Height Cutout
Standard Housing 24-7/16" 12-3/16" 4-7/8"
9-1/8"Emergency 24-7/16" 12-3/16" 4-7/8"
Chicago Plenum 24-7/16" 13-29/32" 4-7/8"
HOUSING
SHALLOW HORIZONTAL CFL 8"
W
E
T
L
O
C
A
T
I
O
N
C8518
C8526
