Cooper Lighting Sure-Lites LPX Series User manual

642
EXIT SIGN Commercial
COOPER LIGHTING
COOPER LIGHTING - SURE-LITES®
• Dual-voltage Input 120/277
VAC, 60Hz, isolation
transformer
• Injection molded
polycarbonate housing
• LED lamping
• Premium Nickel Cadmium
battery (Self Powered)
• Fully charged in 24 hours
(Self-Powered Exits)
• Ceiling, wall, or end
mountable
• Snap-fit canopy included
• Snap-out or snap-in chevron
directional indicators
• Knockout provided on
housing for surface
attachment
• Universal exits can be field
configured as single face or
double face
• Self-powered Exit features
line-latching, solid-state
voltage limited charger, solid-
state switching, brownout
circuit, low-voltage
disconnect, overload/short-
circuit protection, test switch/
power indicator light
• Self-Diagnostic Exits meet
Energy Star and UL Damp
Location
• Optional 2C (Two circuit,
FTBR) available in 120/277
VAC in standard and
emergency operation
(AC Only Exits)• UL 924
Listed, Life Safety NFPA 101,
CSA Certified, NEC/OSHA,
most state and local codes,
suitable for floor proximity
installation
• Patent No. 5,735,498 and
5,678,336
LPX SERIES
Polycarbonate
AC Only
Self-Powered
EXIT LIGHTING
DIMENSIONS
Energy Data – Self-Powered Exits
Charge Mode (Fully Discharged Battery): Sealed Nickel Cadmium Battery
Input Power: Input Current (Max.): Power Factor: T.H.D.:
120V 277V 120V 277V 120V 277V 120V 277V
LED Exits
LED Exits -Red Letters 2.8W 2.9W .03A .02A > .81 > .77 < 32% < 46%
LED Exits Green 6.0W 6.4W .09A .04A > .58 > .56 < 42% < 45%
LED Exits-Red Letters SD 1.7W 1.7W .03A .01A >.63 >.64 <43% <48%
Premium
Premium Deep Green 4.0W 4.0W .08A .04A > .41 > .41 < 48% < 49%
Premium Deep Green SD 3.1W 3.0W .08A .04A >.34 >.36 <63% <67%
Face Options
0=Universal
Battery
Blank=No Battery (LPX6)
Blank=Nickel Cadmium Battery (LPX7)
ORDERING INFORMATION
SAMPLE NUMBER: LPX70RWH
Family
LPX=Polycarbonate
Exit
Series
6=AC only with LED
7=Self-Powered with
LED
Letter
Colors
R=Red
G=Green
(White
Only)
DG=Premium
Deep
Green
Housing
Finishes
WH=White
BK=Black
Options
2C=Two Circuit
Option
(FTBR)
(LPX6 Only)
SD=Self
Diagnostics
(Red and
Deep Green,
White
Housing
Only. LPX7
Only)
Accessories
(Order Separately)
CCX18PKWH=18”
Pendant Kit, White
CCX18PKHTWH=18”
Hang True Pendant Kit,
White
CCX18PKBK=18”
Pendant Kit, Black
CCX18PKHTBK=18”
Hang True Pendant Kit,
Black
WG10=Surface, Wire
Guard
WGS11=Ceiling, End
Wire Guard
VS1=Polycarbonate
Vandal Shield
VS1WP=Polycarbonate
Vandal Shield
Weather Proof
6" [152mm] 4 1/2"
[114mm]
13" [330mm]
7 1/2"
[190mm]
3/4"
[19mm]
2 1/8"
[54mm]
Energy Data – AC Only Exits
Input Power: Input Current (Max.): Power Factor: T.H.D.:
120V 277V 120V 277V 120V 277V 120V 277V
LED Exits
LED Exits -Red Letters 2.4W 2.5W .03A .02A > .78 > .73 < 33% < 48%
LED Exits -Green Letters 5.6W 5.9W .08A .04A > .55 > .53 < 43% < 45%
Premium
Premium Deep Green 2.6W 2.6W .08A .04A > .28 > .28 < 51% < 53%
DESCRIPTION
The LPX Series LED Exit is an
economical, yet attractive,
alternative to metal exits. Its
contemporary round corner
styling, designer white finish,
and consistent family
appearance enables it to blend
with any decor. The tough
injection molded polycarbonate
materials resist discoloration.
All components, including
canopy and chevron directional
indicators, are of snap-fit
construction to facilitate
installation. The under 5-minute
installation time of the LPX
Series Exit makes it the fastest
installed exit on the market
today. All LPX Series Exits are
available in universal
configurations.
LPX
