632
EXIT SIGNS Architectural
COOPER LIGHTING - SURE-LITES®
COOPER LIGHTING
• Dual-voltage Input, 120/277
VAC 60Hz
• 18 gauge steel housing
with conduit knockouts
• Extruded trim plate in
Brushed or Polished
Aluminum, Polished Brass,
White, Black and Bronze
• Injection molded high-
impact acrylic panel
• Clear, mirror, or white
background
• LED Lamping: Super-
bright, long life LEDs
provide uniform
illumination
• Sealed nickel cadmium,
maintenance free, long life
battery (Self Powered only)
• Full Recharge Time,
24 hrs. (max.)
• Recessed housing
available for ceiling or wall
mounting
• Convenient 1/2" knockouts
provided in top and end of
surface mounted housing
• Self-powered Exits feature
solid-state voltage charger,
solid-state switching,
brownout circuit, test
switch/power indicator
light
• UL 924 Listed, Life Safety
NFPA 101, NEC/OSHA,
most state and local codes
DESCRIPTION
The Sure-Lites ES Series
Exits are designed for
architectural excellence and
minimal presence. The
crystal clear wedge shaped
panel allows architectural
details to shine through
while providing excellent
light distribution and exit
visibility. Long life, energy-
efficient LED lamps reduce
energy costs and eliminate
routine lamp maintenance.
ORDERING INFORMATION-COMPLETE UNITS RECESSED / SURFACE
SAMPLE NUMBER: ES7170WHRDAC
Family
ES=Edgelit
Exit Series
Series
6=LED Lamps,
AC Only
7=LED Lamps,
Self-Powered
Face Options
1=Single Face
2=Double Face
Battery
Blank=AC Unit
70=Nickel Cadmium
(Self-powered Only)
Trim Finish
Blank=Brushed
Aluminum
BL=Black
PS=Polished
Brass
BZ=Bronze
PA=Polished
Aluminum
WH=White
Letter/
Background Color
R=Red/Clear (Single
Face Only)
RM=Red/Mirror
RW=Red/White
G=Green/Clear
(Single Face Only)
GM=Green/Mirror
Chevron
Direction
Blank=No
Chevrons
AL=Chevron
Left
AR=Chevron
Right
DA=Double
Chevrons
ARL=Chevron
Right/Left
(Double
Face Only)
Mounting
Options
C=Ceiling
E=End (Surface Only)
W=Wall
P=Pendant (Surface
Only)
Voltage
Blank=Dual-voltage,
120/277V
ORDERING INFORMATION - RECESSED TRIM
SAMPLE NUMBER: EST71WHRDAC
Family
EST=Trim and
Panel
(Recessed Only)
Series
6=LED Lamps, AC Only
7=LED Lamps, Self-Powered
Face Options
1=Single Face
2=Double Face
Trim Finish
Blank=Brushed
Aluminum
BL=Black
PS=Polished
Brass
BZ=Bronze
PA=Polished
Aluminum
WH=White
Voltage
Blank=Dual
Voltage,
120/277V
Letter/
Background Color
R=Red/Clear (Single
Face Only)
RM=Red/Mirror
RW=Red/White
G=Green
GM=Green/Mirror
GW=Green/White
Chevron
Direction
Blank=No
Chevrons
AL=Chevron
Left
AR=Chevron
Right
DA=Double
Chevrons
ARL=Chevron Right/Left
(Double Face Only)
Mounting
Options
C=Ceiling
W=Wall
ORDERING INFORMATION - RECESSED HOUSING
SAMPLE NUMBER: ESH71
Family
ESH=Housing
(Recessed
Only)
Series
6= AC Only
7=Self-Powered
Face Options
1=Single Face (Self-powered Only)
2=Double Face (Self-powered Only)
Energy Data
Input Power: Input Current (Max.): Power Factor: T.H.D.:
120V 277V 120V 277V 120V 277V 120V 277V
LED Exits
LED Exits, Red Letters, AC Only 6.7W 6.7W .06 .03 .8 .8 20% 20%
LED Exits, Red Letters, Self-Powered 7.0W 7.0W .06 .03 .8 .8 20% 20%
LED Exits, Green Letters, AC Only 1.6W 1.6W .02 .01 .6 .6 55% 82%
LED Exits, Green Letters, Self-Powered 2.0W 2.1W .02 .01 .7 .7 45% 68%
Mounting
Blank=Recessed
S=Surface Unit
16 3/4"
(425mm) 2"
1"
14"
35/8"
(356mm) (25.4mm)
(
6" Letters 7 1/2"
(191mm)
(51mm)
(92mm)
23/4"
(70mm)
DIMENSIONS
CEILING MOUNT RECESSED
WALL MOUNT RECESSED
16 3/4"
14"
11/4"
35/8"
(92mm)
(356mm)
41/4"
(108mm)
6" Letters 7 1/2"
(191mm)
13/4"
(44mm)
31/2"
(89mm)
(32mm)
(425mm)
73/4"
(197mm)
16 3/4"
5/8"
2"
14"
41/4"
73/4"
(197mm)
14"
16 "
(356mm)
35/8"
(92mm)
35/8"
(92mm)
(356mm)
(15.9mm)
6" Letters 7 1/2"
(191mm)
6" Letters 7 1/2"
(191mm)
(425mm)
(108mm)
(51mm)
(425mm)
(406mm)
16 3/4"
CEILING MOUNT SURFACE
WALL MOUNT SURFACE
ES SERIES
Edge-Lit
AC Only
Self-Powered
Recessed and Surface
EXIT LIGHTING ES
