Cooper Lighting Shaper 600 User manual

600 SERIES
Interior Wall Luminaire
Luminous Square Vanity
Specifications and dimensions subject to change without notice.
Consult your representative for additional options and finishes.
shaperlighting.com
600 Luminous Square Vanity Luminaire. ADA complaint.
SPECIFICATION FEATURES
Material
Painted or plated cold-rolled
steel, brass, copper or aluminum
end caps and an aluminum body
with a extruded matte white
acrylic diffuser.
Finish
Standard: Natural Aluminum
(NA). [Sustainable Design]
Premium: Matte White (MW),
Lacquered Satin Aluminum
(SAL), Satin Stainless Steel
(SSS), Satin Chrome (SC),
Polished Chrome (PC), Satin
Brass (SB), Polished Brass (PB),
Satin Copper (SCP), Polished
Copper (PCP), Satin Nickel (SN),
Polished Nickel (PN), Lacquered
Satin Chrome (SCL), Lacquered
Satin Nickel (SNL) or Custom
Color (CC).
Optics
Refer to
www.shaperlighting.com for
complete photometrics.
Ballast
Integral electronic HPF, multi-volt
120/277V (347V Canada),
thermally protected with end-of-
life circuitry to accommodate the
specified lamp wattage.
Lamp/Socket
24":Two (2) 14WT5 linear
fluorescent lamps.
36":Two (2) 21WT5 linear
fluorescent lamps. Fluorescent
socket injection molded plastic.
Lamps furnished by others.
Installation
Supplied with a universal
mounting back for a standard 3"
plaster ring or switch-box. 36"
Luminaire has additional
mounting holes to ensure secure
attachment. Horizontal or vertical
mount.
Options
Dimming Ballast - Contact
factory for ballast options (DM),
Remote Emergency Battery -
Supplied by others (REM), Damp
Location (DL): All Painted
Finishes, Lacquered Satin
Chrome (SCL) and Lacquered
Satin Nickel (SNL) finishes only.
Energy Star Rating - Consult
factory.
Labels
U.L. and C.U.L approved for
indoor and damp location. See
options for damp location
finishing requirements.
Modifications
Shaper's skilled craftspeople
with their depth of experience
offer the designer the flexibility
to modify standard wall
luminaires for project specific
solutions. Contact the factory
regarding scale options, unique
finishes, mounting, additional
materials/colors, or decorative
detailing.
DESCRIPTION
Catalog # Type
Date
Project
Comments
Prepared by
Shaper offers a large selection of ADA
interior and exterior wall luminaires.
ADA requires all fixtures below 68" to
have a maximum projection of 4".
AMERICAN DISABILITIES
ACT (ADA)
SUSTAINABLE
DESIGN
Refer to the Icon Legend
Link on shaperlighting.com.
Shaper has a long-standing history
of offering environmentally-friendly
fixtures. The copper and bronze alloys
used in our exterior luminaires feature
up to 98% recycled content, contribute
less undesirable air emissions compared
to painted aluminum and are easy to
recycle.
Shaper’s Quick Ship program features
over thirty-four fixtures with finish
options such as Satin Chrome, Natural
Aluminum and Satin Brass and a wide
variety of lamp selections. All products
ship in five days from receipt of order.
QUICK
SHIP (QS)
ENERGY
STAR
Shaper now offers a wide variety of
fixtures that can be provided with an
Energy Star rating.
ADS042648
2008-09-11 10:50:44
Sample Number: 600-24-T5/2/14-277V-PCP
Voltage
120V
277V
347V
Finish
Standard
NA Natural Aluminum=
Premium
CC Custom Color=
MW Matte White=
PB Polished Brass=
PC Polished Chrome=
PCP Polished Copper=
PN Polished Nickel=
SAL Lacquered Satin Aluminum=
SB Satin Brass=
SC Satin Chrome=
SCP Satin Copper
=
SCL Lacquered Satin Chrome=
SN Satin Nickel=
SNL Lacquered Satin Nickel=
SSS Satin Stainless Steel=
Options
DL Damp Location=
DM CFL Dimming
Ballast 3
=
REM Remote
Emergency
Battery 4
=
Series
600 Luminous
Square
Vanity
=
Size
24"
36"
Lamp
T5/2/14 1
T5/2/21 2
1Available in 24".
Notes:
2Available in 36".
3Consult the factory for available options.
4Supplied by others.
ORDERING INFORMATION

Specifications and dimensions subject to change without notice.
Shaper Lighting •1141 Marina Way South •Richmond, CA 94804 •ph 510.234.2370 •fax [phone]
600 SERIES INTERIOR WALL LUMINAIRE
3"
4"4"
36"
4"
3"
4"
4"
24"
4"
3"
24" STANDARD 36" STANDARD
DIMENSIONS
ADS042648
2008-09-11 10:50:44
