Cooper Lighting Sure-Lites UMX Series User manual

Catalog #
Project
Comments
Prepared by
Type
Date
SPECIFICATION FEATURES
10/02/2008 9:07:48 AM
Consult your representative for additional options and finishes.
Specifications and Dimensions subject to change without notice.
ADX041112
DESCRIPTION
The Sure-Lites watertight, corrosion resistant exit with tough polycarbonate
lens is designed for use where rain, moisture, dust or corrosives are
present. Economical long-life fluorescent lamps provide highly visible
signage and downlighting. The vibration resistant lamps make the UMX
perfect for heavy industrial applications (NEMA 4X Listed).
Electronic
- Dual Voltage Input
120/277 VAC, 60 Hz
- Line-latching
- Solid-state Voltage
Limited Charger
- Solid-state Switching
- Brownout Circuit
- Low-Voltage Disconnect
- Overload/Short Circuit
Protection
- Sealed Test Switch/Power
Indicator Light
Housing Construction
- NEMA 4X corrosion
resistant fiberglass
housing
- Industrial grey color
- Vented enclosure
Housing Construction Cont.
- Tough, high contrast
polycarbonate lens
- Rubber booted momentary
test switch and gasketed
charge indicator lamp
- Surface mount only
- Fully gasketed housing
- Wet Location Listed for
operation in ambient
temperatures above
32 degrees F.
Battery
- 6 Volt Sealed Lead Calcium
or Sealed Nickel Cadmium
- Maintenance-Free, Long-Life
- Full Recharge Time
24 hrs. (max.)
Code Compliance
- UL 924 Wet Location Listed
- Life Safety NFPA 101
- NEC/OSHA
- Most State and Local Codes
Warranty
- Exit: 1-year
- Battery: 5-year pro-rata
(Lead Calcium); 15-year
pro-rata (Nickel Cadmium)
Lamp Data
- AC: Two F6T5 fluorescent lamps
- DC: Two 6V, 6W DC lamps
- Long-life, low energy
consumption
- Available with emergency
lighting heads mounted on
enclosure - consult Cooper
Lighting Representative
UMX
SERIES
WET LOCATION EXITS
SELF-POWERED
EMERGENCY FLUORESCENT
LAMPS
Exit Lighting
11 3/4" [298mm] 7 1/2" [191mm]
11 3/4"
[298mm]
E N E R G Y D A TA
Charge Mode (Fully Discharged Battery)
Sealed Lead Calcium Battery
Fluorescent Exits - 6W Lamps
Input Power:
120V= 41W
277V= 43W
Input Current (Max.):
120V= .51A
277V= .22A
Power Factor:
120V= >.66
277V= >.69
T.H.D.:
120V= <14%
277V= <14%
Standby Mode (Fully Charged Battery)
Sealed Lead Calcium Battery
Input Power consumption is reduced by
approximately 18 Watts in the standby
operating mode.
Sealed Nickel Cadmium Battery
Fluorescent Exits - 6W Lamps
Input Power:
120V= 29W
277V= 29W
Input Current (Max.):
120V= .42A
277V= .17A
Power Factor
120V= >.57
277V= >.62
T.H.D.:
120V= <9%
277V= <38%
Sample Number: UMX203
Options
DH Dual Heads=
Accessories
Protective Housing
WG7 Wire Guard
=
VS2 Polycarbonate Vandal Shield
=
VS2WP Polycarbonate Vandal Shield -
Weather Proof
=
Letter Color / Arrow
Direction
8Red Letters / Right Arrow=
7Red Letters / No Arrow=
6Red Letters / Left Arrow=
5Red Letters / Double Arrow=
4Green Letters / Right Arrow=
3Green Letters / No Arrow=
2Green Letters / Left Arrow=
1Green Letters / Double
Arrow
=
Series
UMX Self-Powered Wet
Location with
Fluorescent
Lamps
=
Battery
20 Self-Powered, Lead
Calcium
=
22 Self-Powered, Nickel
Cadmium
=
10 Lead Calcium Battery
w/Remote Capability
=
COOPER LIGHTING - SURE-LITES®

Sure-Lites • Customer First Center • 1121 Highway 74 South • Peachtree City, GA 30269 • TEL [phone] • FAX [phone]/2008 9:07:48 AM
Specifications and Dimensions subject to change without notice.
ADX041112
WATTAGE RATINGS
TECHNICAL DATA
UMX EXITS
UMX201 – UMX208 Lead Calcium=18W for 1 1/2 hrs.; 15W for 2 hrs.
UMX101 – UMX108 Lead Calcium=27W for 1 1/2 hrs.; 24W for 2 hrs.
UMX221 – UMX228 Nickel Cadmium=15W for 1 1/2 hrs.; 12W for 2 hrs.
L a m p s
Two F6T5 fluorescent lamps
provide long life and normal
mode illumination of the
lens. Two 6V, 6W DC lamps
illuminate the face panel in
the emergency mode.
Housing Construction
The Sure-Lites UMX Series
incorporates a rugged
enclosure of moisture and
corrosion resistant industrial
grey fiberglass with a durable
polycarbonate lens. Housing
is fully gasketed. A breather
vent permits ventilation of
internal pressure from gases
released by charging batteries.
UMX Series Exits are suitable
for surface mounting onl y. Wet
Location Listed for operation in
ambient temperatures above
32°F. Optional Thermal Heater
available to facilitate use
in unheated areas where
battery performance would
be diminished due to low
temperature operation.
Line-Latched
Sure Lites’ line-latched
electronic circuitry makes
installation easy and
economical. A labor efficient
AC activated load switch
prevents the lamps from turnin g
on during installation to a
non-energized AC circuit.
Line-latching eliminates the
need for a contractor’s return
to a job site to connect the
batteries when the buildin g’s
main power is turned on.
Solid-State Charger
Supplied with a 120/277 VAC,
voltage regulated solid-state
charger. Immediately upon
restoration of AC current after
a power failure, the charger
provides a high charge rate.
The charge circuit reacts to the
condition of the battery and
alters the rate of charge in
order to maintain peak battery
capacity and maximize battery
life. Solid-state construction
recharges the battery following
a power failure in accordance
with UL 924.
Overload and Short
Circuit Protection
The solid-state overload
monitoring device in the DC
circuit disconnects the lamp
load from the battery should
excessive wattage demands
be made and automatically
resets when the overload or
short circuit is removed. This
overload current protective
feature eliminates the need
for fuses or circuit breakers
for the DC load.
Brownout Circuit
The brownout circuit on Sure-
Lites’ exits monitors the flow
of AC current to the exit and
activates the emergency
lighting system when a
predetermined reduction of
AC power occurs. This dip
in voltage will cause most
ballasted fixtures to extinguish
causing loss of normal lighting
even though a total power
failure has not occurred.
Solid-State Transfer
The UMX Exit incorporates
solid-state switching which
eliminates corroded and pitted
contacts or mechanical failures
associated with relays. The
switching circuit is designed to
detect a loss of AC voltage and
automatically energizes the
lamps. Upon restoration of
AC power, the emergency
lamps will switch off and the
charger will automatically
recharge the battery.
Te s t S w i t c h / P o w e r I n d i c a t o r
L i g h t
Conveniently located rubber
booted Test Switch allows for
manual verification of proper
operation of the transfer circuit
and emergency lamps. A sealed
light emitting diode (Power
Indicator Light) provides visual
assurance that the AC power
is on.
Sealed Lead Calcium Battery
The fully sealed, long-life,
maintenance-free, lead calcium
battery is ideal for emergency
lighting applications. These
batteries typically provide 8 to
10 years of life and may be
operated in any position.
Sealed Nickel
C a d m i u m B a t t e r y
Sure-Lites’ sealed nickel
cadmium batteries are
maintenance-free with a life
expectancy of 15 years. The
sealed rechargeable nickel
cadmium battery offers high
discharge rates and stable
performance over a wide range
of temperatures. The specially
designed resealable vent
automatically controls cell
pressure, assuring safety and
reliability. This battery is best
suited for harsh ambient
temperatures because the
electrolyte is not active in the
electrochemical process.
W a r r a n t y
All Sure-Lites’ products are
backed by a firm one-year
warranty against defets in
material and workmanship
(excluding lamps). Maintenance-
free, long-life, sealed lead
calcium batteries carry a
five-year, pro-rata warrant y.
Maintenance-free, long-life,
sealed nickel cadmium batteries
carry a fifteen-year pro-rata
warranty.
