2
PN P85325A
Figure 1
Figure 2
Refer to Sync Module instruction sheets DSM (P83177) or Wheelock’s Power Supplies for additional information.
This model has in-out wiring terminals that accept two #12 to #18 American Wire Gauge (AWG) wires at each screw terminal. Strip leadsŘ
3/8 inches (.095 cm) and connect to screw terminals.
Break all in-out wire runs on supervised circuits to ensure integrity of circuit supervision as shown in Figure 2. The polarity shown in the wiring diagramsŘ
is for operation of the appliances.
AB CDEF GH
A B C D E F G H
Figure 3: Jumper plug is used to select tap settings which = dBA loudness.
Figure 4: Tap Settings (Factory setting is 70V @ 1/2W (Tap F))
Each doubling of rated Watts increases sound output by 3 dBA. Field selectable input terminals are provided on each unit. The following1.
wattage selections are available: 1/8W, 1/4W, 1/2W, 1W and 2W.
Each letter corresponds to a plug position of the header located on the printed circuit board. Select voltage and wattage as shown in2.
Table 3 below.
A 1.5μF blocking capacitor for DC supervision of audio lines by the FACP is factory wired in series with the speaker input.3.
GROUNDING: Connect ground wire to backbox. Install signaling appliance to backbox using mounting screws provided.
Figure 5 Expected Light Ouptut
Table 5:Speaker Voltage and Wattage Connection Chart
Position 25V 70V
A 2 ------
B 1 ------
C 1/2 ------
D 1/4 2
E 1/8 1
F ------ 1/2
G ------ 1/4
H ------ 1/8
CANDELA
P O IN T E R
INSERT
SCREWDRIVER
30
95
15
75
CANDELA
PO INTER
IN S E R T
SCREW DRIVER
177 115
Figure 6
NOTE: The E60H-24MCC comes pre-set at 15cd.
NOTE: The E60H-24MCCH comes pre-set at 177cd.
WARNING: The candela select switch must be field set to the required candela intensity before installation. When changing the
setting of the candela select switch, make certain that it “clicks” in place. After changing the candela setting, the appliance must
be retested to verify proper operation. Improper setting of the candela select switch, may result in operation at the wrong candela,
which could result in property damage and serious injury or death to you and/or others.
MOUNTING PROCEDURES
All models can be flush mounted to a 4-inch square by 2-1/8-inch (10.16-cm by 5.4 cm) deep backbox with a 4-inch 1-1/2-inch (10.16-1.
cm by 3.8-cm) sq. extension ring (Figure A). Mounting hardware is supplied.
Conduit entrances to the backbox should be selected to provide sufficient wiring clearance for the installed product. Do not pass ad-2.
ditional wires (used for other than the signaling appliance) through the backbox. Such additional wires could result in insufficient wiring
space for the signaling appliance.
When terminating field wires, do not use more lead length than required. Excess lead length could result in insufficient wiring space for3.
the signaling appliance.
Use care and proper techniques to position the field wires in the backbox so that they use minimum space and produce minimum stress4.
on the product. This is especially important for stiff, heavy gauge wires and wires with thick insulation or sheathing.
The speaker strobe has an integrated speaker mounting plate which must be oriented correctly before mounting the unit to the back box.5.
See Figure B for correct strobe orientation.
To move selector switch, insert screwdriver into slot shown on the bottom side of the strobe. The setting is indicated by a pointer and can6.
be seen on the bottom side of the lens. See Figure 5.
First mount the mounting plate to the backbox and fasten it with two screws. Next, snap the grille to the mounting plate. Make sure that7.
the grille is secure and does not move.
To remove the grille, insert a small flat screwdriver into the slots on either side of grille to disengage the snaps. See Figure 7.8.
Hold flat screwdriver near the tip and insert the tip about 1/8-inch (.13 cm) into one of the slots in the grille as shown.9.
Pull straight down as shown to pop off grille.10.
CAUTION: Prying, turning or pivoting with screwdriver in order to remove the grille may result in damage to ceiling.
NOTE: Non-strobe grille shown.
WARNING: The E60H speaker strobe appliance is a “fire alarm device - do
not paint.”
WARNING: When installing strobes in an open office or other areas con-
taining partitions or other viewing obstructions, special attention should
be given to the location of the strobes so that their operating effect can
be seen by all intended viewers, with the intensity, number, and type of
strobes being sufficient to make sure that the intended viewer is alerted
by proper illumination, regardless of the viewer’s orientation. Failure to do
so could result in property damage and serious injury or death to you and/
or others.
The E60H-24MCCH’s 177cd setting is Listed for use in sleeping or non-sleeping areas when installed in accordance with appropriate NFPA
Standards and the Authority Having Jurisdiction.
WARNING: A small possibility exists that the use of multiple strobes within a person’s field of view, under certain circumstances, might
induce a photo-sensitive response in persons with epilepsy. Strobe reflections in a glass or mirrored surface might also induce such
a response. To minimize this possible hazard, cooper wheelock strongly recommends that the strobes installed should not present a
composite flash rate in the field of view which exceeds five (5) hz at the operating voltage of the strobes. Cooper wheelock also strongly
recommends that the intensity and composite flash rate of installed strobes comply with levels established by applicable laws, stan-
dards, regulations, codes and guidelines.
If this appliance is required to produce a distinctive three-pulse Temporal Pattern Fire Alarm Evacuation Signal (for total evacuation) in ac-
cordance with NFPA 72, the appliance must be used with a fire alarm control unit that can generate the temporal pattern signal. Refer to
manufacturer’s installation manual for details.
NOTE: NFPA 72/ANSI 117.1 conforms to ADAAG Equivalent Facilitation Guidelines in using fewer, higher intensity strobes within the same protected area.
CAUTION: Check the installation instructions of the manufacturers of other equipment used in the system for any guidelines or restrictions on
wiring and/or locating Notification Appliance Circuits (NAC) and notification appliances. Some system communication circuits and/or audio
circuits, for example, may require special precautions to assure electrical noise immunity (e.g., audio crosstalk).
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encour-
aged to try to correct the interference by one or more of the following measures: 1) Reorient or relocate the receiving antenna, 2) Increase the
separation between the equipment and receiver, 3) Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected, and 4) Consult the dealer or an experienced radio/TV technician for help.
ANY MATERIAL EXTRAPOLATED FROM THIS DOCUMENT OR FROM COOPER WHEELOCK MANUALS OR OTHER DOCUMENTS DE-
SCRIBING THE PRODUCT FOR USE IN PROMOTIONAL OR ADVERTISING CLAIMS, OR FOR ANY OTHER USE, INCLUDING DESCRIPTION
OF THE PRODUCT’S APPLICATION, OPERATION, INSTALLATION AND TESTING IS USED AT THE SOLE RISK OF THE USER AND COOPER
WHEELOCK WILL NOT HAVE ANY LIABILITY FOR SUCH USE.
5/12
Figure 7: Grille Removal
