Cooper Notification E70H Series User manual

273 Branchport Ave.
Long Branch, N.J. 07740
[phone]
www.coopernotification.com
1PN P85326B Copyright 2015 Cooper Wheelock, Inc. dba Cooper Notication
Use this product according to this instruction manual. Please keep this instruc-
tion manual for future reference.
GENERAL
The Wheelock Series E70H/E90H High Fidelity Low Profile Speakers are UL
Listed under UL Standard 1480 for Speaker Appliances and ULC Listed under
Standard CAN/ULC-S541-07 for Speaker Appliances. They are designed for
multiple power requirements with high dBA output at each power tap. All mod-
els offer a choice of field selectable taps, 1/8W to 2W, for either 25.0 VRMS or
70.0 VRMS audio systems. The Low Profile design incorporates a high efficiency
speaker for maximum output at minimum power across a frequency range
of 300-8000Hz. The Series E70H/90 appliances also incorporate a Speaker
Mounting Plate attached to the speaker for ease of installation. All models
are Listed for indoor use only with the backboxes specified in these instruc-
tions (see wiring and mounting information). 1/8W tap setting for Private
Mode only. E70H/E90H series speakers are UL rated to meet the NFPA 72
requirement for 520Hz signals in sleeping areas when used in conjunction
with Wheelock Safepath products (see SP40S manual for more details)
NOTE: All Canadian Installations should be in accordance with the Canadian
Standard for the Installation of Fire Alarm Systems - CAN/ULC-S524-01 and
Canadian Electrical Code, Part 1. Final acceptance is subject to Authorities
Having Jurisdiction.
WARNING: The speaker appliance is a “fire alarm device - do not paint”.
WARNING: Please read these instructions carefully. Failure to comply with
any of the following instructions, cautions and warnings could result in
improper application, installation and/or operation of these products in an
emergency situation, which could result in property damage and serious
injury or death to you and/or others.
SPECIFICATIONS
Table 1A: UL Listed Models and Ratings
Speaker
Model Voltage
(VRMS)
dBA at 10 Feet
(Rated Watts)
1/8 1/4 1/2 1 2
E70H 25/70 72 75 78 81 83
E90H 25/70 72 75 78 81 82
Table 1B: ULC Listed Models and Ratings
Speaker
Model Anechoic dBA Per
CAN/ULC-S541-07 (Rated Watts)
Mounting
Options
1/4 1/2 1 2
E70H 74 77 80 83 85 A,B
E90H 73 76 79 82 85 A
Table 2: ULC Directional Characteristics
25/70V -3dBA +/- 19 degrees horizontal; +/- 35 degrees vertical
-6dBA +/- 40 degrees horizontal; +/- 45 degrees vertical
NOTES
1. Models are Listed for indoor use with a temperature range of +32°F to
+120°F (0°C to +49°C) and maximum humidity of 93% RH. The effect of
shipping and storage temperatures shall not adversely affect the perfor-
mance of the appliance when it is stored in the original cartons and is not
subjected to misuse or abuse.
2. The maximum supervision voltage is 33 volts DC.
3. Frequency range of speakers is 300-8000Hz.
CAUTION: Always operate audio amplifiers and speakers within their speci-
fied ratings. Excessive input may distort sound quality and may damage
audio equipment. Do not exceed 100% of speaker input voltage per UL 1480.
Improper input voltage can damage speaker. If distortion is heard, check for
clipping of the audio appliance with an oscilloscope and reduce the amplifier
input level or gain level to eliminate any clipping.
WIRING AND MOUNTING INFORMATION
CAUTION: The following figures show the maximum number of field wires
(conductors) that can enter the backbox used with each mounting option. If
these limits are exceeded, there may be insufficient space in the backbox to
accommodate the field wires and stresses from the wires could damage the
product. Check that the installed product will have sufficient clearance and
wiring room prior to installing backboxes and conduit, especially if sheathed
multiconductor cable or 3/4-inch (1.9-cm) conduit fittings are used.
Although the limits shown for each mounting option comply with the National
Electrical Code (NEC), Cooper Notification recommends use of the largest
backbox option shown and the use of approved stranded field wires, whenever
possible, to provide additional wiring room for easy installation and minimum
stress on the product from wiring.
NOTE: Surface backbox (SBB) in Figure B is compatible with wiremold and
conduit, mounting holes are for single-gang, double-gang, 4-inch (10.16-cm)
sq. (10.16-cm), 3-1/2-inch (8.9-cm) and 4-inch (10.16-cm) octagon or round
backboxes.
SURFACE MOUNTING
B
#8-32
SCREWS
BACKBOX
(SBB)
SURFACE
SPEAKER
MOUNTING
PLATE
SQUARE
SCREWS
#6-19
(NON-STROBE SPEAKER)
GRILLE
MAXIMUM NUMBER OF CONDUCTORS
AWG #18 AWG #16 AWG #14 AWG#12
4 4 4 4
4" SQ. X 1-1/2"
A
FLUSH MOUNTING
4" SQ. X 2-1/8"
BACKBOX
#8-32
SCREWS
EXTENSION RING *
#6-19
SCREWS
(NON-STROBE SPEAKER)
ROUND GRILLE
SQUARE OR
SPEAKER
MOUNTING
PLATE
MAXIMUM NUMBER OF CONDUCTORS
AWG #18 AWG #16 AWG #14 AWG#12
4 4 4 4
NOTE: E90H has a round grille. E70H is shown.
• This model has in-out wiring terminals that accept two #12 to #18 American
Wire Gauge (AWG) wires at each screw terminal. Strip leads 3/8 inches (.96
cm) and connect to screw terminals.
• Break all in-out wire runs on supervised circuits to ensure integrity of circuit
supervision as shown in Figure 1. The polarity shown in the wiring diagrams
is for operation of the appliances.
Figure 1 Figure 2
GROUNDING: Connect ground wire to backbox. Install signaling appliance to
backbox using mounting screws provided
INSTALLATION INSTRUCTIONS
SERIES E70H/E90H HIGH FIDELITY
LOW-PROFILE SPEAKERS

2PN P85326B Copyright 2015 Cooper Wheelock, Inc. dba Cooper Notication
__
WARNING: Check electrical ratings specified in tables 1 and 2 (as ap-
propriate) to ensure proper input. Check to ensure that wiring at facp is
correct. Improper electrical input can damage the product or cause it to
malfunction, which could result in property damage and serious injury or
death to you and/or others.
A B C D E F G H
A B C DE F GH
Figure 3: Jumper plug is used to
select tap settings
which = dBA loudness.
Figure 4: Tap Settings
(Factory setting is 70V
@ 1/2W (Tap F))
1. Each doubling of rated Watts increases sound output by 3 dBA. Field
selectable input terminals are provided on each unit. The following wattage
selections are available: 1/8W, 1/4W, 1/2W, 1W and 2W.
2. Each letter corresponds to a plug position of the header located on the
printed circuit board. Select voltage and wattage as shown in Table 3
below.
3. A 1.5µF blocking capacitor for DC supervision of audio lines by the FACP
is factory wired in series with the speaker input.
NOTE: Use needle nose pliers to pull and properly insert the jumper plug to
the desired tap setting.
Table 3: Speaker Voltage and Wattage Connection Chart
Position 25V 70V
A 2 ------
B 1 ------
C 1/2 ------
D 1/4 2
E 1/8 1
F ------ 1/2
G ------ 1/4
H ------ 1/8
MOUNTING PROCEDURES
1. These models can be flush mounted to a 4-inch (10.16) square by 2-1/8-
inch (5.52-cm) deep backbox with a 4-inch (10.16-cm) sq. 1-1/2-inch
(3.81-cm) extension ring (Figure A) or surface mounted to a surface back-
box (Figure B). Mounting hardware for each mounting option is supplied.
2. Conduit entrances to the backbox should be selected to provide sufficient
wiring clearance for the installed product. Do not pass additional wires
(used for other than the signaling appliance) through the backbox. Such
additional wires could result in insufficient wiring space for the signaling
appliance.
3. When terminating field wires, do not use more lead length than required.
Excess lead length could result in insufficient wiring space for the signaling
appliance.
4. Use care and proper techniques to position the field wires in the backbox
so that they use minimum space and produce minimum stress on the
product. This is especially important for stiff, heavy gauge wires and wires
with thick insulation or sheathing.
5. These models have an integrated speaker mounting plate which must be
oriented correctly when it is mounted to the backbox. Turn the speaker
mounting plate so that the arrows above the word “Top” point to the top
side of the speaker mounting plate.
6. Mount the speaker mounting plate to the backbox. Next slide the grille
over the speaker mounting plate and attach with (2) screws.
WARNING: The E70H/E90H speaker appliance is a “re alarm device - do
not paint.”
If this appliance is required to produce a distinctive three-pulse Temporal
Pattern Fire Alarm Evacuation Signal (for total evacuation) in accordance
with NFPA 72, the appliance must be used with a fire alarm control unit that
can generate the temporal pattern signal. Refer to manufacturer’s installation
manual for details.
CAUTION: Check the installation instructions of the manufacturers of other
equipment used in the system for any guidelines or restrictions on wiring and/
or locating Notification Appliance Circuits (NAC) and notification appliances.
Some system communication circuits and/or audio circuits, for example, may
require special precautions to ensure electrical noise immunity (e.g., audio
crosstalk).
NOTE: This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, includ-
ing interference that may cause undesired operation.
