Cooper 10907c User manual

ROLLATOR

Model No: 10907C

Maximum User Weight: 130kg

SETTING THE HANDLE HEIGHT ON THE ROLLATOR

WARNING: Before using this product, please read these instructions

carefully.

Coopers 3 and 4 wheel Rollators have the exclusive purpose

of providing a means in which a disabled user who is unsteady

on their legs or tire easily, can have better mobility and security

in walking. They can be used either as part of a rehabilitation

programme e.g. when the user is recovering from an injury or

operation; and as a long term walking and resting aid e.g. when

the user has permanent difculty with walking. Coopers 3 and 4

wheel Rollators are suitable for use outdoors or indoors

Caution: Use on loose, uneven and or rough terrain e.g. gravel,

sand or grass may affect the safe performace and functionality of the

rollator.

CONTINUED

PLEASE NOTE:

These are our recommendations but should be checked with your

physiotherapist.

When the handle height is adjusted correctly the user should be

able to maintain an upright posture with the elbow slightly exed. In

this way, a user’s body weight is taken through the rollator frame by

pushing down on the frame when walking.

CONTINUED

WARNING

For your safety and before each use, please perform the daily checks as

described in the maintenance section and in addition

1. Ensure the rollator is securely locked open before use. i.e seat pad is

fully down and the RED locking mechanism is fully locked.

2. Do not exceed the maximum user weight for the walker.

3. Do not overload the basket or carry heavy bags on the handles as this

can affect the stability of the walker.

4. Do not use the rollator as a wheelchair

5. Ensure that the brakes are parked i.e. brake handles pushed fully

down with an audible click (see g 1) before sitting upon the seat pad.

6. Do not stand on the seat of the rollator

WALKING WITH THE ROLLATOR

1. Place rollator ahead of you with brakes parked. i.e. brake handles

pushed fully down with an audible click (see g 1)

2. Do not walk forward until you have tested your balance and you feel

strong enough to walk

3. When ready disengage the brakes i.e. brake handles pulled up with an

audible click (see g 2)

4. Gently roll the walker ahead of you as you walk. Keep the rollator close

enough to you that it is supportive.

5. If your steps are uneven, it’s best to shorten your longer step rather than

try to lengthen your shorter step. The shorter step is usually the step where

you have less balance.

6. Use the brakes i.e squeeze the brake handles (see g 3) to temporarily

halt forward movement, or to slow and control the frame, and or reduce the

speed of your step.

Caution Some very smooth surfaces .e.g. marble, tile or certain oor

coverings may cause the rollator wheels to slide even with the brakes

applied.

ROLLATOR

CONTINUED

7. To turn around: stay within the width of the rollator even if you are slightly

behind it. Roll the walker around you without twisting your back – you should

always be facing the front of the walker. The brakes can also be used in

maneuvering the rollator; when turning, the user can apply the brake on the

side being turned towards in order to achieve a tighter turning radius.

Fig. 1 Fig. 2 Fig. 3

ROLLATOR

CONTINUED

GETTING OUT OF A CHAIR

Sunrise Medical recommends wherever possible, the use of a chair with a

high seat height and arms to assist you with standing up and sitting down

more easily.

1. Have the rolllator ahead of you with brakes parked. i.e. brake handles

pushed fully down with an audible click (see g 1)

2. Move forward and sit as close to the edge of the chair as you feel

comfortable.

3. Keep your feet as far under you as possible.

4. Try to position your toes below the edge of the chair.

5. Place both hands on the arms/seat of your chair OR one hand on the

chair and one hand on the rollator

Caution Do not tip the rollator by placing too much weight on one side

as you start to stand.

6. Lean forward until you feel some of your weight on your feet.

7. Use your legs to stand as much as possible – your arms should only lift

what your legs cannot. Use your arms mostly to help keep your balance as

you stand.

8. Do not walk forward until you have tested your balance and you feel

strong enough to walk.

9. When ready disengage the brakes. i.e. brake handles pulled up with an

audible click (see g 2)

ROLLATOR

GETTING INTO A CHAIR

1. Stand directly in front of the chair, facing away from it. The back of your

legs should be almost touching the seat of the chair. Do not try to sit until

you are balanced and standing still.

2. Move the rollator just away from you, so that you can bend slightly

forward as you sit down.

3. Engage the brakes. i.e. brake handles pushed fully down with an

audible click (see g 1)

4. Reach behind for the chair with both hands (preferred) or with one hand

and one hand on the rollator.

CAUTION: Do not tip the rollator by placing too much weight one side as

you start to sit.

5. Slowly start to lower yourself using your legs as much as you can.

6. If you drop into the chair, next time try leaning a little more forward as you

sit and bend your knees to lower yourself to the chair more gently.

CONTINUED

ROLLATOR

ASSEMBLY INSTRUCTIONS

To open the rollator, hold the seat in one

hand and push down. The rollator will now

spread its wheels and open.

Lock the frame open by pushing down

the RED locking lever on the righthand

side below the seat. Ensure it has fully

engaged with the frame. Image 1

This rollator is supplied fully assembled with the exception of the

handles, basket and tray.

Fit the handles

Position the rst handle to the height required, line up the hole for the

boltand the appropriate hole in the handle and insert the bolt from the

inside of the frame.

Slide the curved washer onto the bolt and t the locking wheel,

ensuring the hexagonal bolt head is located in the cut out of the

tube to stop it from rotating. Tighten the locking wheel and check the

handle is secure. Repeat for the other handle.

CONTINUED

CINS/LHRL/ISS5

ROLLATOR

To fold the rollator, pull up the RED

locking lever to release, image 2 (below

the seat on the right hand side) apply the

pull towards you and the rollator will fold.

When the rollator is unfolded for use lock the frame open by pushing

down the RED locking lever on the righthand side below the seat.

Ensure it has fully engaged with the frame. Image 1

Image 1

Image 2

BRAKES

CINS/LHRL/ISS5 CONTINUED

To adjust, loosen the lock nut, turn the adjuster anti-clockwise to

tighten the brake and retighten the lock nut.

Check the brakes are operating correctly before use.

If you have any problems adjusting the brakes please contact

your local Sunrise Medical dealer to correctly adjust them for

you. (Fees may be charged for this service).

ROLLATOR

To adjust the brakes there are two adjusters on each side of the

rollator, one in front of the brake handle and the second at the other

before the cables feeds down the body tube.

To release the parking brakes, pull up on the loop handles.

To apply the parking brakes, push down on the loop handles.

When in motion, the brakes are operated by squeezing the loop

handles, each rear wheel being operated independently by the

appropriate handle.

Before using the walker, check the brakes operate and are correctly

adjusted.

BASKET

TRAY

Maximum safe working load for basket is 5kg (11lbs). Do not

exceed this weight. The basket is fitted by attaching the two

hooks over the seat bar.

The clear plastic tray ts on the top of the seat and the four lugs on

the underside of the tray locate in the four holes in the top of the seat.

Warning: Ensure the tray is securely located before use, especially

if carrying hot drinks.

CLEANING & MAINTENANCE

It is recommended that the walker is cleaned regularly with a soft cloth and

soapy water.

Dry with a soft cloth.

Do not use any abrasive cleaners or bleach.

Maintenance is minimal but regular inspection is necessary to ensure continued

safe function and performance of the rollator is achieved.

Check daily before use:

Brake cables are not frayed, and that the brakes are correctly adjusted.

Wheels rotate easily, front wheels should rotate and swivel

Perform regular checks for security of all fasteners and xings and that no other

adjustable or removable parts are loose or worn.

Replace or adjust parts where necessary.

SPARE/REPAIR PARTS AVAILABLE

1. Brake handles (pair) AL120-00

2. Brake cables (pair) RA053-1

3. Handle adjustment kit TI020-T3

4. Frame locking mechanism RA024-3

5. Basket RA032

6. Seat RA029

7. Wheel (one) RA051

ROLLATOR

WARRANTY

LIFE EXPECTANCY

All Coopers products are warranted for 12 months from the date of purchase

against manufacturing or design defects.

The warranty is subject to the following conditions:

• It does not apply to wear and tear, inappropriate or incorrect use, or non-

observance of User Instructions.

• Defective set up by the user or third parties or negligent or careless

treatment.

• Use of unsuitable or unapproved spares or unauthorised alteration.

•The warranty does not extend to consequential costs resulting from fault

clearance, loss of earnings or expenses

THIS IN NO WAY AFFECTS YOUR STATUTORY RIGHTS.

We estimate a life expectancy of 2 years for this product, provided that:

• It is used in strict accordance with the intended use as set out in this

document.

• All service and maintenance requirements are met.

The estimated life expectancy can be exceeded if the product is carefully used

and properly maintained.

The life expectancy can also be considerably reduced by extreme or incorrect

usage.

The fact that we estimate a life expectancy for this product does not constitute

an additional warranty.

Conforms to

The Medical Device Directive 93/42/EEC 1993

ROLLATOR

Notes................................................................................................................

..........................................................................................................................

.........................................................................................................................

ROLLATOR

Notes................................................................................................................

..........................................................................................................................

.........................................................................................................................

ROLLATOR

Sunrise Medical Limited

Thorns Road, Brierley Hill, West Midlands, DY5 2LD England Conforms to

The Medical Device Directive 93/42/EEC 1993

Tel + 44 (0) 845 605 6688 Fax + 44 (0) 845 605 6689

Iss5 DEC 2013
