COP Security 15-IL3810 User manual

High Performance Infrared Illuminator
User manual
15-IL3810 / 15-IL3830 / 15-IL3860 /
15-IL3812 /15-IL38L10 / 15-IL38L40

1
◆Description
zAccurate constant circuit drive develops excellent performance of LEDs
zUsing high power LEDs, high efficacy and long service life
zAmbient brightness display
zBrightness Adjustable (5 step)
zDelay time Adjustable (2-30 sec)
zExternal trigger mode (NO or NC) Selectable (Trigger in and Trigger out)
zLight on and light off：ambient brightness adjustable
zSilica gel waterproof circle and water stop line ensure excellent waterproof performance
zDigital light sensor more accurately responses ambient brightness and improve accuracy of
automatic light control
zHigh efficient twice optical lens processing achieves 90% of the luminous efficiency
zNew design, slim body, easy and simple installation
zSupplied with paint steel wall mount bracket
zImproved performance of cameras to get better pictures at night time
zIndoor and outdoor use
zIR Remote control
z2 year warranty
◆ Specification
ITEM 15-IL38xx 15-IL38Lxx
Quantity of LED 3W high power LEDs
20 pcs high power Laser LEDs 20 pcs
Wavelength 850nm 850nm
Beam angle 10 -120 degrees 10 - 40 degrees
IR distance 60 - 300m (196 -984 ft) 150 - 350m (492 - 1148 ft)
Day/night switch Auto on/off
Voltage AC / DC24V
Power consumption 40 W 42 W
Front panel Vandal PC
Housing aluminum
Bracket Wall mount bracket
Working temperature -20°C ~ + 50⁰C (-4 to 122°F)
Protection level IP68 and IK10
Color Black
Dimension 200 x 150 x 57 mm
(Don’t include bracket)
Net weight 1.8kg
(Don’t include bracket)

2
15◆-IL38xx Beam Pattern and Achievable Distance
Model Beam angle IR distance-850nm
15-IL3810 10° 300m (984ft)
15-IL3830 30° 200m (656ft)
15-IL3860 60° 100m (328ft)
15-IL3812 120° 60m (196ft)
※ The distance and performance depend on the cameras/lens and environmental conditions.
15◆-IL38Lxx Beam Pattern and Achievable Distance
Model Beam angle IR distance-850nm
15-IL38L10 10° 350m (1148ft)
15-IL38L40 40° 150m (492ft)
※ The distance and performance depend on the cameras/lens and environmental conditions.
◆ Packing list
1. ILLUMINATOR x1
2. BRACKET x1
3. WALL MOUNT BRACKET x1
4. REMOTE CONTROLLER x1
5. MANUAL x1

3
◆DIMENSION
◆Operation
1. Function Display
2. IR Receiver / Light Sensor
3. AC/DC 24V INPUT (RED)
4. M/S (Master Mode / Slave Mode) (YELLOW)
Master Mode：M/S Open，The trigger in no effect，Light on/off control by Light sensor
Slave Mode：M/S Short，Light sensor no effect，Light on/off control by Trigger IN
5. TRIGGER IN (BLACK)
6. TRIGGER OUT (WHITE)

4
1. C：“Call”Display all setting
2. M：“Memory”Storage setting
3. LIGHT ON：Light ON ambient brightness (02~60)
4. LIGHT OFF：Light OFF ambient brightness (06~80)
5. BRIGHTNESS：IR Light brightness setting (01~05)
6. DELAY：Light off delay time setting (02’s~30’s)
7. IN：“TRIGGER IN”Trigger in N.C. or N.O. select
8. OUT：“TRIGGER OUT”Trigger out N.C. or N.O. select

5
◆Set Up
Adjust vertical angle
◆Optional Bracketry 15-B038BD
15-B038BT
15-CD04BSI 15-CD05BSI
