LEGRAND WP2 LED User manual

WP2 LED WEATHERPROOF LED BATTENS
Tel [phone]
Tel [phone]
Fax [phone]
www.hpmlegrand.com.au
TITLE
1
A
2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
B
C
D
E
F
G
H
I
K
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
A
B
C
D
E
F
G
H
I
K
REVISIONS "A" ORIGINAL ISSUENO ALTERATIONS WITHOUT DESIGN OFFICE APPROVAL
2FT LED WP BATTEN
WITH GRP V3236F CASE
THIRDANGLE PROJECTION
LIFECYCLE STATE
Released
DESIGN PAN 01/08/2013
DESIGN REVIEW melvinder singh 01 Jun 15
PD REVIEW Paul Barron 02 Jun 15
CTO REVIEW Dennis Galvin 03 Jun 15
MATERIAL COATING SCALE SHEET CAT NO. FILE NO. REVISION
SEE PARTS SEE PARTS 0.50 A1 TBA AG05041AA B.4
FILE NAME ASSY_2FT_LED_GRP_AG05041AD UNLESS OTHERWISE STATED ALL DIMENSIONS IN MM SHEET2 OF 2
DO NOT SCALE
LEGRANDAUSTRALIA PTY. LTD. ALL
RIGHTSRESERVED. THIS DRAWING
MAYNOT BE REPRODUCED OR
TRANSMITTEDIN ANY FORM OR BY
ANYMEANS, IN PART OR IN WHOLE
WITHOUTTHE WRITTEN PERMISSION
OFLEGRAND AUSTRALIA PTY. LTD.
GENERALTOLERANCES UNLESS SPECIFIED
LINEAR
STEPSIZE
<3
>3- 6incl
>6- 30incl
>30-120incl
>120
ANGULAR
Item Item Name Dwg/Art No Qty
1 SUB ASSY - GEARTRAY AF04783AE 1
2 SUB ASSY CASING AG04781AB 1
REV.B PAN 150601
MAJOR MOD TO GEARTRAY
(230.0 - MOUNTING HOLES)
(670.0)
(100.4)
(166.8)
230 mm - MOUNTING HOLES
Tel [phone]
Tel [phone]
Fax [phone]
www.hpmlegrand.com.au
TITLE
1
A
2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
B
C
D
E
F
G
H
I
K
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
A
B
C
D
E
F
G
H
I
K
REVISIONS "A" ORIGINAL ISSUENO ALTERATIONS WITHOUT DESIGN OFFICE APPROVAL
4FT LED WP BATTEN
WITH GRP V3236F CASE
THIRDANGLE PROJECTION
LIFECYCLE STATE
Released
DESIGN PRADEEP 27/05/2014
DESIGN REVIEW melvinder singh 01 Jun 15
PD REVIEW Paul Barron 02 Jun 15
CTO REVIEW Dennis Galvin 03 Jun 15
MATERIAL COATING SCALE SHEET CAT NO. FILE NO. REVISION
SEE PARTS SEE PARTS 0.50 A1 TBA AG05041AE B.6
FILE NAME ASSY_4FT_LED_GRP_AG05041AE UNLESS OTHERWISE STATED ALL DIMENSIONS IN MM SHEET 2 OF 2
DO NOT SCALE
LEGRANDAUSTRALIA PTY. LTD. ALL
RIGHTSRESERVED. THIS DRAWING
MAYNOT BE REPRODUCED OR
TRANSMITTEDIN ANY FORM OR BY
ANYMEANS, IN PART OR IN WHOLE
WITHOUTTHE WRITTEN PERMISSION
OFLEGRAND AUSTRALIA PTY. LTD.
GENERALTOLERANCES UNLESS SPECIFIED
LINEAR
STEPSIZE
<3
>3- 6incl
>6- 30incl
>30-120incl
>120
ANGULAR
Item Item Name Dwg/Art No Qty
1 SUB ASSY - GEARTRAY AF04783AF 1
2 SUB ASSY CASE AG04781AC 1
REV.B PAN 150601
MAJOR MOD TO GEARTRAY
(166.8)
(100.4)
(1275.0)
(812.0 - MOUNTING HOLES)
812 mm - MOUNTING HOLES
All models
Supply Voltage 230 - 240 V a.c. 50 Hz
Power Factor >0.9
Colour Temperature 4000 K
IP Rating IP65
Specifications
Installation
■Disconnect mains supply before installing, servicing or maintaining the luminaire.
■Attach the stainless steel clips to the body of the luminaire and attach the row
of clips on one side of the luminaire to the diffuser (clip must be attached to the
protruding side of the diffuser).
■The gear tray should be detached to assist with installation by twisting the quarter
turn fasteners.
■Drill out mounting holes.
■Use the supplied screw set to ensure IP65 is maintained.
■Fit the power cable through the supplied IP65 gland.
■Make the electrical connection at the terminal block:
•N – Neutral
•A – Active
•E – Earth
■For DALI models connect the data cable to the two terminals labelled "DA".
■For Emergency models, an additional Switched Active terminal is provided
to allow the luminaire to be switched ON and OFF in mains mode.
For non-maintained operation, do not connect the switched active terminal.
■For Galaxy models, see the illustration for the correct orientation of the
antenna.
■Clip and secure the lanyards to the gear tray.
■Secure the gear tray to the base.
■Close the diffuser and ensure diffuser clips are locked in place..
ANTENNA POSITION FOR 4FT BATTEN
ANTENNA POSITION FOR 2FT BATTEN
Note: Antenna illustration is for Galaxy models.
Ceiling Mount (as supplied) Wall Mount
Wall Mount
For wall mount undo the antenna and install
as shown.
For wall mount the antenna bracket should be bend 90 degrees as shown (no need to undo the antenna).
Ceiling Mount (as supplied)

Installation positions / Antenna orientation and IP rating
Disclaimer:
1. This product must be installed and used as per these instructions.
2. This product must be installed by a licenced electrician.
3. Legrand reserves the right to modify the specifications of this product at any time.
4. This product should only be cleaned with a damp cloth. Cleaning agents and solvents should not be used.
5. The IP rating of this product is only valid when all applicable seals, glands and their appropriate cables
are installed correctly.
6. This product has no user serviceable parts and no attempt should be made to repair this product.
For repair please contact Legrand.
7. Extended exposure to UV rays (such as exposure to direct sunlight) may cause discolouration of this product.
8. Severe electromagnetic interference from other products may cause malfunction of this product.
9. This product is not suitable for marine environments such as areas subject to salt spray and/or mist.
10. This product is not suitable for installation in hazardous and/or corrosive areas.
11.The material in this product may vary in colour from batch to batch. Colour matching from one batch to
another cannot be guaranteed.
12.This product should not be cleaned with a hose.
13.This product has been designed to operate in ambient temperatures 10°C to 40°C.
14. This product utilises intellectual property in the form of registered designs, trademarks, and/or patents. Such intellectual
property remains the property of Legrand in all cases.
There are two types of movement sensor models:
For all of these models, the user can change the following settings:
1. Detection area
Detection area can be reduced by selecting the combination on
the DIP switches to fit precisely for each specific application.
2. Hold Time
Hold-time means the time period you would like to keep the
lamp on 100% after the person has left the detection area.
3. Daylight Sensor
The daylight threshold can be set on DIP switches,
to fit a particular application.
For example, when set to 50 Lux, the movement sensor will only operate when the ambient light level is below 50 lux.
When set to Disable, the movement sensor will operate all the time.
>Indicates default settings.
I - Detection range 100%
II – Detection range 75%
III – Detection range 50%
IV – Detection range 25%
V – Detection range 10%
I – 30 minutes
II – 20 minutes
III – 6 minutes
IV – 90S
V – 30S
VI – 10S
I – Photocell disabled
II – 50 lux daylight operation
III – 30 lux daylight operation
IV – 10 lux twilight operation
V – 5 lux darkness operation only
For movement sensor models only
ON/OFF models These units turn on when movement is detected and turn off
after a certain time period has elapsed with no movement.
Auto occupancy models
These units turn on when movement is detected and dim
down to 10% brightness after a certain time period has
elapsed with no movement.
LE08945AE 05/2021
Key: = Switch up = Switch down
