Copernicus CS7-CLR User manual

CS7-CLR - Version A - Released September 22, 2020 - Copernicus Educational Products Inc.
Assembly Guide
CS7-CLR 2020 A
Check out our other products online at
www.copernicused.com
ŸThis product is meant to be assembled by an adult.
ŸIn its unassembled state, small parts present a hazard.
ŸTo be used under direct supervision of an adult.
WARNING
For assistance, please contact us:
1-800-267-8494
Email [email protected]
Have your packing slip ready for reference
Clear Dry-Erase Single Room Divider
CS7-CLR
Clear Acrylic Dry-Erase
Panel Frame (1)
Bottom Stretcher (2)
2” Twin Wheel Caster (4)
Upper Leg (2)
Lower Leg (2)
Loop Hook (2)
Need Tech Support?
Have a Question?
Email our Tech Support Service www.copernicused.com
Check out some of our
other great products!

CS7-CLR - Version A - Released September 22, 2020 - Copernicus Educational Products Inc.
Dear Educator,
Thank you for purchasing one of our products.
I hope the assembly of your Clear Dry-Erase Single Room Divider went well.
If you have any questions, or concerns, or ideas for how we can improve, please call us at 1-800-267-8494,
where someone will be happy to help.
Enjoy using your new product, and happy teaching,
Quality schools are the
result of quality teachers
going above and beyond
the call of duty.
VICKI CARUANA
In everyone’s life at some
time our inner fire goes
out. It is then burst into
flame by an encounter
with another human
being. We should all be
thankful for those people
who rekindle the inner
spirit.
ALBERT SCHWEITZER
My idea of education is
to unsettle the minds of
the young and inflame
their intellects.
ROBERT MAYNARD
HUTCHINS
Nothing has a better
effect upon children than
praise.
SIR PHILLIP SIDNEY
Kaylyn Belcourt
President
For assistance, please contact us:
1-800-267-8494
Email [email protected]
Have your packing slip ready for reference
CS7-CLR
Assembly Guide
CS7-CLR 2020 A
Check out our other products online at
www.copernicused.com
Clear Dry-Erase Single Room Divider

CS7-CLR - Version A - Released September 22, 2020 - Copernicus Educational Products Inc.
Hardware
Actual Size
Contents - Box 1
Before beginning, you should have:
Additional tools required:
Clear Dry-Erase Single Room Divider - Parts
In Box 1
Adjustable wrench Rubber Mallet
Allen Key
(Not to Scale)
1x
M6 x 45mm
4x
A
M6 x 35mm
8x
B
M6 Hex Nut
4x
C
Lock Washer
12x
D
Clear Acrylic Dry-Erase Panel Frame
1x
Lower Leg
2x
Bottom Stretcher
2x
Upper Leg
2x
2” Twin Wheel Caster
4x
Loop Hook
2x
CS7-CLR

CS7-CLR - Version A - Released September 22, 2020 - Copernicus Educational Products Inc.
lThis symbol denotes a 2 Person Task. For safety, please ensure that there are two people
working on steps displaying this symbol
lWatch for this symbol throughout the Assembly Instructions. Wherever you see it, pay close
attention. The symbol denotes a step needing extra attention to ensure it is done correctly.
lThe Star symbol highlights an advisory note
2 Person
Watch for These Helpful Symbols
Before You Begin
As You Assemble the Unit
lLayout and identify all of the included parts
lThe hardware has been packed by step
lRead the assembly instructions over once to familiarize yourself with them
lPlease note that in its unassembled state, this product contains parts that can be a hazard
to small children; it should be assembled by an adult.
lFollow the steps in sequence
lBefore beginning each step, find the part(s) that you need for that step
lPay attention to the labeling on the parts, they are there to help direct you at certain stages
lThe title of each step states what you will be doing. Review the text and the pictures as you
build the unit.
After Assembly; Before Use
Tips for Assembly - Using this Manual
CS7-CLR
“The beautiful thing about learning is that no one can take it away from you.” - B. B. King
To validate your warranty submit the ON-LINE form at www.copernicused.com
Validate Your Warranty On-Line
Frame & Tub
Warranty
2
Year
Acrylic
Warranty
Life
Time
lRemove the plastic film from the acrylic panel before writing on it
Don’t forget to check out our tips for your acrylic panel at:
www.copernicused.com/help/tips

CS7-CLR - Version A - Released September 22, 2020 - Copernicus Educational Products Inc.
1
Install 2” Casters
You will need: (Not to Scale)
Actual Size:
2
Bolt Lower Legs To Upper Legs
You will need: (Not to Scale)
Actual Size:
Press Casters firmly into the Base:
ŸCasters will click into place
ŸIf necessary, tap the caster in
using a rubber mallet.
Lock Washer
x 4
M6 x 45mm
x 4
A
M6 Hex Nut
x 4
CD
Build x 2
A
D
C
2” Twin Wheel Caster
x 4
Upper Leg
2x
Lower Leg
2x
Build x 2
Hole indents on Upper Leg
should face same side as Lower Leg.

CS7-CLR - Version A - Released September 22, 2020 - Copernicus Educational Products Inc.
3
Install Stretchers
You will need: (Not to Scale)
Actual Size:
M6 x 35mm
x 4
B
Lock Washer
x 4
D
B
D
Bottom Stretcher
2x
BD
B
D
B
D
4
Install Clear Acrylic Dry-Erase Panel
Frame Onto Base
You will need: (Not to Scale)
Actual Size: B D
M6 x 35mm
x 4
Lock Washer
x 4
Hole indents should face
outside of the unit.
Select your panel height
ŸJunior/intermediate - higher position
ŸEarly childhood/primary - lower position
BD
B
D
Hole indents
should face
outside of the unit.

CS7-CLR - Version A - Released September 22, 2020 - Copernicus Educational Products Inc.
5
Install Loop Hooks & Chart Hooks
You will need: (Not to Scale)
Actual Size:
Loop Hook
2x
To avoid scratching the
paint place an empty
plastic bag over the frame,
install hooks, then remove
6
Remove Protective Film from Panel
You will need: (Not to Scale)
Actual Size:
