Coredy TA100 Specification sheet

Coredy TA100
Nano Travel Router/Access Point/ Repeater
V2.0
GET STARTED

Table of contents
Introduction.........................................................
Overview..............................................................
Environment Requirements...............................
Default Patameters.............................................
Mode Introduction..............................................
AP/Access Point Mode....................................
Repeater (Range Extender) Mode..................
Router Mode....................................................
Quick Installation................................................
AP (Access Point) Mode..................................
Repeater (Range Extender) Mode..................
Option 1. Using WPS..................................
Option 2. Using a Web Browser..................
Router Mode....................................................
Other Settings....................................................
WPS Connection Function..............................
Basic Settings..................................................
Login password settings..................................
Firmware Upgrade...........................................
Save/Load/Reset Settings...............................
Troubleshooting & Support...............................
WARRANTY.........................................................
CONTACT US......................................................
STATEMENT........................................................
1
1
3
5
5
5
6
7
8
8
12
13
16
21
27
27
28
29
30
31
32
36
36
37

-1-
Introduction
Overview
Coredy TA100 Nano Travel Router/Access
Point/Repeater has a ultra compact size,
mainly designed for travel. It could help
quickly create your own a secure a Wi-Fi
hotspot . TA100 could be powered by an
outlet via a charger (not incluced in the
package), a power bank, a power station or a
computer. And it provide up to 150Mbps
speed for video streaming, online gaming
and internet calls.
Package Contents
Coredy TA100 Nano Travel Router x 1
User Manual x 1

-2-
LED:
LED
ON: It is Power ON
OFF: It is Power OFF
Flashing:
In the WPS connecting mode
WPS: It is used to establish a secure Wi-Fi
connection between this TA100 and other
WPS capable devices, like Wireless Router,
AP, Cellphones and etc.
Reset: This button is used to restore the
TA100 to its factory default settings. With the
TA100 power on, using a paper clip or similar
LED
USB Cable
Router AP/Repeater
Router
AP/Repeater
Reset
LAN/ WAN
WPS
RESET
MODEL:CD565N1

-3-
Environment Requirements
small point to press and hold the Reset
button for 3~6 seconds, then release the
button and wait the TA100 to reboot to its
factory default settings.
Router AP/Repeater: You can select your
using mode physically.
LAN/WAN: Use this port to connect to your
Modem while in Router mode. In Access
Point mode, use it to receive network access
from your local network.
USB Cable: It is used to powering up the
TA100 Nano Router. It could be pluged into a
running computer, a powerbank or a power
outlet via a charger (not included in the
package) for power.
Place the TA100 in a well-ventilated place far
from any heater or heating vent.

-4-
Note: To minimize wireless interference,
place your Router/AP/Repeater in an open
space area, away from other Bluetooth
devices or radioactive devices such as
cordless phone, microwave, etc.
Place the TA100 in a location where it can be
connected to the various devices as well as
to a power source.
Avoid direct irradiation of any strong light
(such as sunlight)
Keep at least 2 inches (5 cm) of clear space
around the TA100.
Operating Temperature:0~40°C (32~104 °F )
Operating Humidity: 10%~90%RH, Non-
condensing.
Router
AP/Repeater
Keep away from

-5-
Default Patameters
Mode Introduction
AP/Access Point Mode
Create a wireless network from an Ethernet
connection. This mode is suitable for dorm
rooms or hotel rooms where there's already
a wired Router but you need a wireless
hotspot.
URL http://ap.setup
Default IP 192.168.10.1
Login Name admin
Password admin
Wireless SSID Travel Repeater

-6-
Repeater (Range Extender) Mode
Extend signal from an existing wireless
network, use a Different SSID or copy the
Same SSID of the existing Router’s
network.This mode is suitable to extend
wireless coverage, reaching devices that
were previously too far from your primary
Router to maintain a stable wireless
connection.
Note: It’s recommended to use an SSID
different from your Router.
Router
AP/Repeater
Power
INTERNET

-7-
Router Mode
Create an instant private wireless network
and share Internet to multiple Wi-Fi devices.
This mode is suitable for hotel rooms and
home networks.
Router
AP/Repeater
Power
INTERNET
Router
AP/Repeater
Power
INTERNET

-8-
Quick Installation
AP (Access Point) Mode
1. Power On
Note: Please be sure your TA100 is restored
to factory default settings before getting
start.
Switch the TA100 to the AP/Repeater
mode. Plug the USB of TA100 into an
outlet via a charger (not included in the
package), a Power Bank or a computer for
Power, the LED would be ON; and wait
about 12 seconds until the LED flash
once.
Router
AP/Repeater
Power
Router
AP/Repeater
Power Supply:
Max. Power Input:
5V~2A

-9-
2. Connect
Wired (Recommended.)
Disconnect your computer from all
wireless networks. Connect your
computer with the TA100 via an Ethernet
cable (not included in the package).
Or Wireless:
Click the Wireless Network icon on your
desktop. Select the Default SSID of the
TA100: Travel Repeater, then click
Connect.
Router
AP/Repeater
Power
LAN Port
David
Travel Repeater
!
!
Information sent over this network
might be visible to others.
Connect automatically Connect

-10-
3. Login the setup page
4. Click the AP button in the Wizard field.
Open a Web browser and type in
http://ap.setup or 192.168.10.1. in the
address bar, and press Enter button to go
to the login page. Then Enter the default
User Name and Password: admin (both
in lower case letters). Click Submit.
Note: If you could not login the setup
page, please refer to Q3 of
Troubleshooting on Page 33 for more
information.
Username admin
admin
English
Submit
Password
Language
Wizard
AP
Repeater User-PC

-11-
5. You can use the system’s original SSID,
or choose to rename the SSID as you
like. Then select a security type and set
a security key for your new wireless
network. Click Apply and then Reboot.
6. After the TA100 has reboot successfully,
plug your Router’s Network cable into
the TA100’s WAN/LAN port. Wait for the
LED flash once.
7. Now refresh your devices’ wireless
network options, and connect to your
new wireless Network (SSID) you have
just set, and enjoy.
Wireless AP Mode
SSID Travel Repeater
Auto
Channel
Security Type
Security Key
WPA2 PSK
Unmask
Apply Cancel

-12-
Repeater (Range Extender)
Mode (2 Options)
Note: Please be sure your TA100 is
restored to factory default settings before
getting start. Put your main Router in an
open space area, and keep TA100 NEXT
TO your Router during the installation
process.
Router
AP/Repeater
Power
INTERNET

-13-
Switch the TA100 to the AP/Repeater
mode. Plug the USB of TA100 into an
outlet via a charger (not included in the
package), a Power Bank or a computer for
Power, the LED would be ON; and wait
about 12 seconds until the LED flash
once.
Option 1. Using WPS (WiFi protected
Setup)
1. Power On
Router
AP/Repeater
Power
Router
AP/Repeater
Power Supply:
Max. Power Input:
5V~2A

-14-
Press the WPS button on your TA100 for
about 6 seconds. Then the LED will flash
in a few seconds.
2.
Then immediately push the WPS button
on your Router/AP. (For more information
about using WPS on your Router, please
refer to the Router manufacturer’s user
guide.)
3.
RESET
MODEL:CD565N1
RESET
MODEL:CD565N1
Power
WPS

-15-
When the TA100 have got connect to the
Router successfully, it will Reboot.
Note: The TA100’s new SSID will be
XXXX VAP when your Router’s SSID is
XXXXX.
If the TA100 can not pairing with your
Router successfully, please refer to
Option 2.
4.

-16-
Option 2. Using a Web Browser
Relocate.
In general, place your WiFi Repeater
about half way between your wireless
router/AP and wireless devices.
After moving to a new location, the
Repeater will automatically reconnect to
your router in approximately one minute.
Switch the TA100 to the AP/Repeater
mode. Plug the USB of TA100 into an
outlet via a charger (not included in the
package), a Powerbank or a computer for
Power, the LED would be ON; and wait
1. Power On
5.
The Repeater (Range Extender) shares your Router's Wi-Fi
password, but may have different wireless network names
if you customize the names during the configuration.
Ideal Repeater (Range Extender) Placement
YourNetworkName
and password
YourNetworkName or
CustomizeName
and password
Router
AP/Repeater
Power

-17-
Disconnect your computer from all
wireless networks. Connect your
computer with the TA100 via an Ethernet
cable (not included in the package).
Wired (Recommended)
about 12 seconds until the LED flash once.
2. Connect
Router
AP/Repeater
Power
LAN Port
Router
AP/Repeater
Power
Router
AP/Repeater
Power Supply:
Max. Power Input:
5V~2A

-18-
Or Wireless:
Click the Wireless Network icon on your
desktop. Select the Default SSID of the
TA100: Travel Repeater, then click
Connect.
Open a Web browser and type in
http://ap.setup or 192.168.10.1. in the
address bar, and press Enter button to go
to the login page. Then Enter the default
User Name and Password: admin (both in
lower case letters). Click Submit.
Note: If you could not find the login page
or login the setup page, please refer to
3. Login the setup page
Your Router Wireless Name
Travel Repeater
!
!
Information sent over this network
might be visible to others.
Connect automatically Connect
