Corindus CorPath GRX User manual

2. Bedside
touchscreen
will outline
steps for
guide catheter
removal
3. If “Exchange
Guide” was hit
accidentally,
hit “Cancel”
and return to
master screen
5. Disconnect
sheath
retainer from
sheath
6. Rotate
proximal end
of sheath
retainer away
from user
7. Ensure
sheath port is
no longer captured by sheath retainer before pulling guide
support track back
10. Open lid on
Y-connector
holder and lift
Y-connector
and guide
catheter out
of single-use
cassette.
11. Care must
be taken to
not pull guide
catheter from coronary ostium during removal
12. Manipulate guide catheter as needed or exchange
manually
1. Press
“Exchange
Guide” on
bedside
touchscreen
4. Turn track
clamp
counter-
clockwise into
the “unlocked”
position
8. While holding
sheath and
guide catheter
in place, pull
guide support
track back
into single-use
cassette
9. Pull back on
proximal end
of track as
shown above
CORPATH GRX GUIDE CATHETER EXCHANGE TECHNIQUE
REMOVE GUIDE

2. Position
drive gear &
Y-connector in
Y-connector
holder
3. Use ne tune
controls (in
red) to adjust
robotic drive
position if
necessary
rather than pulling guide catheter into position
4. Close gate on Y-connector holder
1. Bedside
touchscreen
will outline
steps for
guide catheter
re-insertion
RE-INSERT GUIDE
7. Attach guide
support track
to introducer
sheath by
locking the
sheath retainer
around the
sheath port
8. Rotate
proximal end
of the sheath
retainer towards user
5. Secure sheath
and guide
catheter with
left hand
6. Gently pull
guide support
track out
from cassette
so that it
completely
encapsulates
guide catheter
© 2017 Corindus, Inc. |309 Waverley Oaks Road, Suite105 |Waltham MA 02452 |[email protected] |www.corindus.com PN 162-06326 Rev A
10. Master
screen will
appear to
prompt you
to your next
step "Load/
Exchange
Devices"
9. Turn lever on
track clamp
clockwise
180  into
the “locked”
position
CORPATH GRX GUIDE CATHETER EXCHANGE TECHNIQUE
