Cornwell Tools CTBMM747SBK User manual

CTBMM747SBR / CTBMM747SBK / CTBMM747SBL
CTBMM747SNY / CTBMM747SRG / CTBMM747SRD 1 06/27/08
ASSEMBLY INSTRUCTIONS
CTBMM747SBK, BL, BR, NY, RD, RG
7 Drawer Side Cabinet
Hardware information: Hex bolt M10x45 2 On top connecting plate Hex bolt M10x55 2 On bottom connecting plate Locknut M10 4 on two connecting plates Washer D10x1.5 (Outside D20) 8 on two connecting plates (Above hardware available in kit, RS747SBK)
M10x45 bolt
M10x55 bolt
M10 nut
upper connecting tube
bottom connecting plate
M10 nut

CTBMM747SBR / CTBMM747SBK / CTBMM747SBL
CTBMM747SNY / CTBMM747SRG / CTBMM747SRD 2 06/27/08
CTBMM747SBK, BL, BR, NY, RD, RG
7 Drawer Side Cabinet
TROUBLESHOOTING
Troubleshooting Points for the CTBMM747 Series:
Problem: Drawers appear not to fit, do not slide in accurately
and bump the cart sides.
Solution: The roller bearing slides must be fully engaged into
the mounting slots on all drawers. They potentially could fall
out of position during shipment. Check the side of the cart to
determine which slide is out of position.
Remove the drawer that is out of position. The drawer is
removed by the two clips on the actual roller bearing slide.
Simply push the roller bearing slide back down into position.
Insert the drawer back onto the roller bearing slides.
SERVICE CART WEIGHT CAPACITY
Total Net Load. . . . . . . . . . . . . . . . . . . . . . . . .500 LBS
Top Compartment . . . . . . . . . . . . . . . . . . . . .100 LBS
Top Six Drawers . . . . . . . . . . . . . . . . . . 75 LBS each
Bottom Drawer. . . . . . . . . . . . . . . . . . . . . . . 150 LBS
Lid/Work Surface . . . . . . . . . . . . . . . . . . . . . 100 LBS
PLEASE NOTE: Loading cart beyond rated
capacity may cause structural damage to the cart
as well as personal and /or property damage.
Problem: Back Lock/Unlock Switch does not engage
the drawer.
Solution: The inside Lock/Unlock slide potentially could fall
out of its groove during shipment. Unscrew the four screws
that are holding the Lock/Unlock slide in place.
Once the screws are removed, simply place the latch back
onto the slide and tighten the four screws back down.
Mounting Slots

CTBMM747SBR / CTBMM747SBK / CTBMM747SBL
CTBMM747SNY / CTBMM747SRG / CTBMM747SRD 3 06/27/08
PARTS LIST
CTBMM747SBK, BL, BR, NY, RD, RG
7 Drawer Side Cabinet

CTBMM747SBR / CTBMM747SBK / CTBMM747SBL
CTBMM747SNY / CTBMM747SRG / CTBMM747SRD 4 06/27/08
PARTS LIST
CTBMM747SBK, BL, BR, NY, RD, RG
7 Drawer Side Cabinet
2 RS747STCPBK Top Connecting Plate Black 1
RS747STCPBL Top Connecting Plate Blue 1
RS747STCPBR Top Connecting Plate Burgundy 1
RS747STCPNY Top Connecting Plate Yellow 1
RS747STCPRD Top Connecting Plate Red 1
RS747STCPRG Top Connecting Plate Orange 1
4 RSMM747SRM Rubber Mat For Lid 1
5 RSMM747SGP Gas Piston 1
6 RS747SLMBK Locking Mechanism Black 1
RS747SLMBL Locking Mechanism Blue
RS747SLMBR Locking Mechanism Burgundy
RS747SLMNY Locking Mechanism Yellow
RS747SLMRD Locking Mechanism Red
RS747SLMRG Locking Mechanism Orange
7 RSLKN Lock with Keys 1
8 RSMM700LGBK Black Leg / each 4
RSMM700LGBL Blue Leg / each
RSMM700LGBR Burgundy Leg / each
RSMM700LGNY Yellow Leg / each
RSMM700LGRD Red Leg / each
RSMM700LGRG Orange Leg / each
9 RSMM700BPLF Left Front Bumper 1
RSMM700BPLR Left Rear Bumper 1
RSMM700BPRF Right Front Bumper 1
RSMM700BPRR Right Rear Bumper 1
12 CTBMM747SLD2BK Black 2" Drawer 3
CTBMM747SLD2BL Blue 2" Drawer 3
CTBMM747SLD2BR Burgundy 2" Drawer 3
CTBMM747SLD2NY Yellow 2" Drawer 3
CTBMM747SLD2RD Red 2" Drawer 3
CTBMM747SLD2RG Orange 2" Drawer 3
13 CTBMM747SLD3BK Black 3" drawer 3
CTBMM747SLD3BL Blue 3" drawer 3
CTBMM747SLD3BR Burgundy 3" drawer 3
CTBMM747SLD3NY Yellow 3" drawer 3
CTBMM747SLD3RD Red 3" drawer 3
CTBMM747SLD3RG Orange 3" drawer 3
14 CTBMM747SLD12BK Black 11.5" drawer 1
CTBMM747SLD12BL Blue 11.5" drawer 1
CTBMM747SLD12BR Burgundy 11.5" drawer 1
CTBMM747SLD12NY Yellow 11.5" drawer 1
CTBMM747SLD12RD Red 11.5" drawer 1
CTBMM747SLD12RG Orange 11.5" drawer 1
16 CTBMM747SSBK Black Bottom shelf tray 1
CTBMM747SSBL Blue Bottom shelf tray 1
CTBMM747SSBR Burgundy Bottom shelf tray 1
CTBMM747SSNY Yellow Bottom shelf tray 1
CTBMM747SSRD Red Bottom shelf tray 1
CTBMM747SSRG Orange Bottom shelf tray 1
17 RSMM747SDH Drawer Handle Including Hardware / each 7
18 RSMM747SSC 6"x2" Swivel Non-locking Caster / each 3
19 RSMM747SL Ball Bearing Slides 100# 22"/pair 8
20 RS747SPBHRBK Black Right Prybar Holder
(Including Hardware) 1
RS747SPBHRBL Blue Right Prybar Holder
(Including Hardware) 1
RS747SPBHRBR Burgundy Right Prybar Holder
(Including Hardware) 1
RS747SPBHRNY Yellow Right Prybar Holder
(Including Hardware) 1
RS747SPBHRRD Red Right Prybar Holder
(Including Hardware) 1
RS747SPBHRRG Orange Right Prybar Holder
(Including Hardware) 1
21 RS747SBCPBK Bottom Connecting Plate Black 1
RS747SBCPBL Bottom Connecting Plate Blue 1
RS747SBCPBR Bottom Connecting Plate Brown 1
RS747SBCPNY Bottom Connecting Plate Yellow 1
RS747SBCPRD Bottom Connecting Plate Red 1
RS747SBCPRG Bottom Connecting Plate Orange 1
22 RS747SPBHLBK Black Left Prybar Holder
(Including Hardware) 1
RS747SPBHLBL Blue Left Prybar Holder
(Including Hardware) 1
RS747SPBHLBR Burgundy Left Prybar Holder
(Including Hardware) 1
RS747SPBHLNY Yellow Left Prybar Holder
(Including Hardware) 1
RS747SPBHLRD Red Left Prybar Holder
(Including Hardware) 1
RS747SPBHLRG Orange Left Prybar Holder
(Including Hardware) 1
23 RSMM747SDL3 EVA Liner For Drawers (set of 3) *
24 RSMM747STL EVA Liner For Top Compartment 1
* 7 per cart but sold in sets of 3
Item # Item #Part # Part ## Req'd # Req'dDescription Description
Also available:
RSLKN2 Set Of Two Locks Keyed Alike
(for use on CTBMM747 and CTBMM747S)
RSSCPK Service Cart Polishing Kit
RSBKP Black Touch Up Paint (1oz.)
RSCTBBLU Blue Touch Up Paint (1oz.)
RSCTBBR Burgundy Touch Up Paint (1oz.)
RSYP Yellow Touch Up Paint (1oz.)
RSRDP Red Touch Up Paint (1oz.)
RSCORNORP Orange Touch Up Paint (1oz.)
RS747SCLP Logo Plate
RSMM747CHK Caster Hardware Kit
(16 bolts, nuts, washers)
